Motorola ATS 3000

9.2-56 UHF1 Schematics, Board Overlays, and Parts Lists
February 14, 2012 6816985H01-F
R613 0613952R08 CER CHIP RES 20K OHM 5
0402
R614 0613952R08 CER CHIP RES 20K OHM 5
0402
R615 0613952R25 CER CHIP RES 100K OHM 5%
0402
R616 0613952Q49 CER CHIP RES 100 OHM
5 0402
R617 NOT PLACED –
R620 0613952Q49 CER CHIP RES 100 OHM
5 0402
R621 0613952Q49 CER CHIP RES 100 OHM
5 0402
R622 0613952Q49 CER CHIP RES 100 OHM
5 0402
R625 0613952Q49 CER CHIP RES 100 OHM
5 0402
R626 0613952Q49 CER CHIP RES 100 OHM
5 0402
R633 NOT PLACED –
R634 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R635 NOT PLACED –
R636 0613952R01 CER CHIP RES 10K OHM 5%
0402
R637 0613952Q73 CER CHIP RES 1000 OHM
5 0402
R638 0613952Q73 CER CHIP RES 1000 OHM
5 0402
R639 0613952Q73 CER CHIP RES 1000 OHM
5 0402
R640 0613952Q73 CER CHIP RES 1000 OHM
5 0402
R641 0613952Q73 CER CHIP RES 1000 OHM
5 0402
R642 0613952Q73 CER CHIP RES 1000 OHM 5
0402
R643 0613952Q73 CER CHIP RES 1000 OHM 5
0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R644 0613952Q73 CER CHIP RES 1000 OHM 5
0402
R647 0613952R01 CER CHIP RES 10K OHM 5%
0402
R649 0613952R17 CER CHIP RES 47K OHM 5%
0402
R654 0613952R01 CER CHIP RES 10K OHM 5%
0402
R656 0613952R01 CER CHIP RES 10K OHM 5%
0402
R658 0613952P18 CER CHIP RES 150K OHM
1 0402
R666 0613952Q42 CER CHIP RES 51.0 OHM 5%
0402
R667 0613952Q63 CER CHIP RES 390 OHM
5 0402
R668 0613952Q45 CER CHIP RES 68.0 OHM
5 0402
R669 0613952Q49 CER CHIP RES 100 OHM
5 0402
R670 0613952Q49 CER CHIP RES 100 OHM
5 0402
R671 0613952Q63 CER CHIP RES 390 OHM
5 0402
R672 0613952R01 CER CHIP RES 10K OHM 5%
0402
R673 0613952R01 CER CHIP RES 10K OHM 5%
0402
R674 0613952Q49 CER CHIP RES 100 OHM
5 0402
R675 0613952Q67 CER CHIP RES 560 OHM
5 0402
R677 0613952R01 CER CHIP RES 10K OHM 5%
0402
R678 0613952Q49 CER CHIP RES 100 OHM
5 0402
R697 0613952Q49 CER CHIP RES 100 OHM
5 0402
R700 0613952Q80 CER CHIP RES 2000 OHM
5 0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R701 0613952R17 CER CHIP RES 47K OHM 5%
0402
R702 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R703 0613952R17 CER CHIP RES 47K OHM 5%
0402
R704 0613952Q49 CER CHIP RES 100 OHM 5
0402
R705 0613952R17 CER CHIP RES 47K OHM 5%
0402
R708 0613952R19 CER CHIP RES 56K OHM 5%
0402
R709 0613952H17 CER CHIP RES 4.7OHM 5%
R710 0688044N04 RES,METAL STRIP, 0.1
OHM,1%,0.125W,SMD,0805,7
R711 0613952G67 CER CHIP RES 0.0 +/-0.050
OHM
R712 0613952Q49 CER CHIP RES 100 OHM 5
0402
R714 0688044N04 RES,METAL STRIP, 0.1
OHM,1%, 0.125W,SMD,0805,7
R717 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R718 0613952G67 CER CHIP RES 0.0 +/-0.050
OHM
R722 0613952R08 CER CHIP RES 20K OHM 5
0402
R725 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R726 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R729 0613952R13 CER CHIP RES 33K OHM 5%
0402
R740 0613952Q63 CER CHIP RES 390 OHM 5
0402
R741 0613952R17 CER CHIP RES 47K OHM 5%
0402
R742 0613952R17 CER CHIP RES 47K OHM 5%
0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R743 NOT PLACED –
R744 NOT PLACED –
R745 0613952R56 CER CHIP RES 2.0M OHM 5
0402
R746 0613952R56 CER CHIP RES 2.0M OHM 5
0402
R747 0613952Q73 CER CHIP RES 1000 OHM
5 0402
R748 0613952R41 CER CHIP RES 470K OHM 5%
0402
R749 0613952R41 CER CHIP RES 470K OHM 5%
0402
R750 0613952Q63 CER CHIP RES 390 OHM
5 0402
R751 0613952Q63 CER CHIP RES 390 OHM
5 0402
R752 0613952Q81 CER CHIP RES 2200 OHM
5 0402
R753 0613952Q81 CER CHIP RES 2200 OHM
5 0402
R756 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R757 0613952R08 CER CHIP RES 20K OHM
5 0402
R758 0613952R19 CER CHIP RES 56K OHM 5%
0402
R759 0613952R01 CER CHIP RES 10K OHM 5%
0402
R760 0613952Q93 CER CHIP RES 6800 OHM
5 0402
R763 NOT PLACED –
R764 NOT PLACED –
R765 NOT PLACED –
R767 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R768 NOT PLACED –
R771 NOT PLACED –
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
