Motorola ATS 3000

9.2-58 UHF1 Schematics, Board Overlays, and Parts Lists
February 14, 2012 6816985H01-F
Notes:
1. For optimum performance, order replacement diodes, transistors, and circuit
modules by Motorola part number only.
2. When ordering crystals, specify carrier frequency, crystal frequency, crystal
type number, and Motorola part number.
3. Part value notations:
p=10
-12
n=10
-9
µ=10
-6
m=10
-3
k=10
3
M=10
6
4. ITEM refers to the component reference designator. SIDE refers to the
location of the component on the board; S1=Side 1, S2=Side 2.
PMLE2537G Main Circuit Board
Electrical Parts List
U701 5185143E77 IC, MAKO ASIC, CMOS PWR
MGMT
U702 5185941F22 IC,OPAMP,SGL,OPA237,SOT2
3, NOPB
U705 5114000B39 IC,BFR,1PER PKG,SM,
SOT-353, PB-FREE
U712 5188691V01 IC,MUX/
DEMUX,NC7SB3157P6X,
SM,SC70-6,1PER PKG
U713 5115453H01 RAIL TO RAIL OUTPUT, 8 PIN
BGA
U714 5115453H01 RAIL TO RAIL OUTPUT, 8 PIN
BGA
U800 5185941F04 IC, PATRIOT BRAVO, 1.2.2,
256BGA, PB-FREE
U801 5114000B39 IC,BFR,1PER PKG,SM,
SOT-353, PB-FREE
U802 5114000B39 IC,BFR,1PER PKG,SM,
SOT-353, PB-FREE
U803 5185956E69 IC,DRAM,64MB,60NS,IC 1.8V
64
U804 5185941F03 IC,SRAM,8M,512KX16,70NS,S
M,FBGA48,1.95V
U811 5185941F40 IC, 12 BIT DAC
VR500 4809788E21 DIODE, ZENER, SOD-323,
SMD, W18 COMPLIANT
VR501 4813977M19 DIODE,ZEN,MBZ5240,SM,SOT
-23, 10V,10MA,.225W,ZE
VR502 4809788E21 DIODE, ZENER, SOD-323,
SMD, W18 COMPLIANT
VR503 4809788E21 DIODE, ZENER, SOD-323,
SMD, W18 COMPLIANT
VR504 4809788E21 DIODE, ZENER, SOD-323,
SMD, W18 COMPLIANT
VR505 4809788E21 DIODE, ZENER, SOD-323,
SMD, W18 COMPLIANT
VR506 4809788E21 DIODE, ZENER, SOD-323,
SMD, W18 COMPLIANT
VR507 4809788E21 DIODE, ZENER, SOD-323,
SMD, W18 COMPLIANT
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
VR508 4813977A43 PB-FREE, NOT COMPLETELY
ENRICHED
VR509 4813977A43 PB-FREE, NOT COMPLETELY
ENRICHED
VR510 4813977A43 PB-FREE, NOT COMPLETELY
ENRICHED
VR511 4813977A43 PB-FREE, NOT COMPLETELY
ENRICHED
VR512 4813977A43 PB-FREE, NOT COMPLETELY
ENRICHED
VR513 4813977A43 PB-FREE, NOT COMPLETELY
ENRICHED
VR650 4813979P12 DIODE ARRAY,TRANSIENT
PROTECTION,SM,SOT-457,1
VR651 4813977A43 PB-FREE, NOT COMPLETELY
ENRICHED
VR652 4813977A43 PB-FREE, NOT COMPLETELY
ENRICHED
VR657 4809788E21 DIODE, ZENER, SOD-323,
SMD, W18 COMPLIANT
VR658 4813977C23 DIODE,ZEN,MMSZ5243,SM,
SOD-123,13V,10MA,.5W,ZE
VR659 4813979P10 DIODE ARRAY,TRANSIENT
PROTECTION,SM,SOT-457,5
VR662 4813979P10 DIODE ARRAY,TRANSIENT
PROTECTION,SM,SOT-457,5
VR663 4813977M18 DIODE,ZEN,MBZ5239,SM,
SOT-23, 9.1V,10MA,.225W,Z
VR678 4866544A01 DIODE ARRAY,ZEN,SR05.
TCT,SM,5V,5,LOW CAPA
VR701 4813977M11 DIODE,ZEN,MBZ5232,SM,
SOT-23, 5.6V,10MA,.225W,Z
Y200 4802245J68 OSC, REF 16.8 MHZ 1.5 PPM
Y701 4809995L05 XTAL QUARTZ 32.768KHZ
CC4V-T1
Y702 4864005H01 RESONATOR, CRYSTAL
24.576 MHZ
6003710K08 BATT COIN 3.3V LIION
1085674C03 PASTE/NC-SMQ230
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
PMLN4624A PEELABLE LABEL KIT
4285633D01 RETAINING CLIP
PCB 8416617H03 BOARD, PC, UHF BAND 1
(MAKO)
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
B500 0986237A02 CONNECTOR (CONTACT
BATTERY)
C2 2113944A79 CAP,FXD,16PF,+5%,-5%,
50V-DC, 0402,C0G,-55DEG C
C3 NOT PLACED –
C4 NOT PLACED –
C9 2113944A79 CAP,FXD,16PF,+5%,-5%,
50V-DC, 0402,C0G,-55DEG C
C20 2113944A40 CAP CER CHP 100.0PF 50V
5%
C33 2113944A40 CAP CER CHP 100.0PF 50V
5%
C35 2113944A34 CAP CER CHP 56.0PF 50V 5%
C41 2113944A22 CAP CER CHP 7.5PF 50V
+/- 0.5PF
C43 2113944A79 CAP,FXD,16PF,+5%,-5%,
50V-DC,0402,C0G, -55DEG C
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C44 2113946K02 CAP CER CHP 0.10UF 16V
C46 2113944A40 CAP CER CHP 100.0PF 50V
5%
C48 2113944A79 CAP,FXD,16PF,+5%,-5%,
50V-DC, 0402,C0G,-55DEG C
C51 2113944A23 CAP CER CHP 8.2PF 50V
+/- 0.5PF
C54 2113944M01 CAP,FXD,2PF,.1PF+/-,50V-DC,
0603,C0G,-55DEG CM
C55 2113945B02 CAP CER CHP 10,000PF 25V
10%
C57 2113944M12 CAP,FXD,5.6PF,.1PF+/-,
50V-DC,0603,C0G,-55DEG
C58 2113944M07 CAP,FXD,3.6PF,.1PF+/-,
50V-DC, 0603,C0G,-55DEG
C59 NOT PLACED –
C60 NOT PLACED –
C61 2113944A15 CAP CER CHP 3.9PF 50V
+/- 0.25PF
C62 2113944A29 CAP CER CHP 22.0PF 50V 5%
C63 2113944A15 CAP CER CHP 3.9PF 50V
+/- 0.25PF
C64 2113944A77 CAP,FXD,11PF,+5%,-5%,
50V-DC ,0402,C0G,-55DEG C
C65 2113944A77 CAP,FXD,11PF,+5%,-5%,
50V-DC, 0402,C0G,-55DEG C
C66 2113946K02 CAP CER CHP 0.10UF 16V
C67 2113946B04 CAP CER CHP 0.10UF 10V
10%
C68 NOT PLACED –
C69 2113944A23 CAP CER CHP 8.2PF 50V
+/- 0.5PF
C70 2113944A40 CAP CER CHP 100.0PF 50V
5%
C71 2113944A80 CAP,FXD,20PF,+5%,-5%,50V-
DC, 0402,C0G,-55DEG C
C72 2113944A17 CAP CER CHP 4.7PF 50V
+/- 0.25PF
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
