Motorola ATS 3000

UHF1 Schematics, Board Overlays, and Parts Lists 9.2-59
6816985H01-F February 14, 2012
C73 2113944A17 CAP CER CHP 4.7PF 50V
+/- 0.25PF
C74 2113944A29 CAP CER CHP 22.0PF 50V 5%
C75 2113944A77 CAP,FXD,11PF,+5%,-5%,
50V-DC, 0402,C0G,-55DEG C
C76 2113944A77 CAP,FXD,11PF,+5%,-5%,
50V-DC ,0402,C0G,-55DEG C
C77 2113945B02 CAP CER CHP 10,000PF 25V
10%
C78 2113944A40 CAP CER CHP 100.0PF 50V
5%
C79 2113944A40 CAP CER CHP 100.0PF 50V
5%
C80 2113945B02 CAP CER CHP 10,000PF 25V
10%
C82 2113944A40 CAP CER CHP 100.0PF 50V
5%
C83 2113944A09 CAP CER CHP 2.2PF 50V
+/- 0.25PF
C84 2113944A09 CAP CER CHP 2.2PF 50V
+/- 0.25PF
C85 2113944A07 CAP CER CHP 1.8PF 50V
+/- 0.25PF
C86 2113944A07 CAP CER CHP 1.8PF 50V
+/- 0.25PF
C87 2113944A40 CAP CER CHP 100.0PF 50V
5%
C88 2113945B02 CAP CER CHP 10,000PF 25V
10%
C89 2113946F03 CAP CER CHP 4.7UF 6.3V 10%
C90 2113944A40 CAP CER CHP 100.0PF 50V
5%
C100 2113944C45 CAP CER CHP 100.0PF 50V
5%
C102 2113944A40 CAP CER CHP 100.0PF 50V
5%
C103 2113945B02 CAP CER CHP 10,000PF 25V
10%
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C104 2113944A40 CAP CER CHP 100.0PF 50V
5%
C108 2113945B02 CAP CER CHP 10,000PF 25V
10%
C109 2113945B02 CAP CER CHP 10,000PF 25V
10%
C110 2113945B02 CAP CER CHP 10,000PF 25V
10%
C111 NOT PLACED –
C112 2113944A40 CAP CER CHP 100.0PF 50V
5%
C122 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603,X7R,-55DEG
C130 2113945B02 CAP CER CHP 10,000PF 25V
10%
C131 2113945B02 CAP CER CHP 10,000PF 25V
10%
C133 2113944C39 CAP CER CHP 56.0PF 50V 5%
C135 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC, 0603,X7R,-55DEG
C139 2313960M26 CAP,FXD,1UF,+10%,-10%,
10V-DC, SM,-55DEG CMIN,
C140 2113944A40 CAP CER CHP 100.0PF 50V
5%
C141 2113944C45 CAP CER CHP 100.0PF 50V
5%
C142 2313960A76 CAP,FXD,1UF,+10%,-10%,
20V-DC,SM,-55DEG CMIN,
C143 2113945A10 CAP CER CHP 1500PF 50V
10%
C144 2113945A05 CAP CER CHP 470PF 50V 10%
C145 2113945B03 CAP,FXD,.015UF,+10%,-10%,
25V-DC,0402,X7R,-55
C146 2113945C31 CAP,FXD,.1UF,+10%,-
10%,50V-DC, 0603,X7R,-
55DEG
C147 2313960A76 CAP,FXD,1UF,+10%,-10%,
20V-DC, SM,-55DEG CMIN,
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C148 2113944A40 CAP CER CHP 100.0PF 50V
5%
C149 2113945B02 CAP CER CHP 10,000PF 25V
10%
C150 2113944A40 CAP CER CHP 100.0PF 50V
5%
C151 NOT PLACED –
C153 2113944C45 CAP CER CHP 100.0PF 50V
5%
C154 0613952G67 CER CHIP RES 0.0 +/-0.050
OHM
C156 2113944F60 CAP,FXD,56PF,+5%,-5%,
50V-DC, 0805,C0G,-55DEG C
C157 2116069H05 CHIP CAPACITOR-EPP PART
C158 2113951A36 CAP NPO 12.0PF +/-5% 250V
HI FREQ
C159 NOT PLACED –
C160 2103689A47 SL240J HIGH - Q CAPCITOR,
UCN033
C161 NOT PLACED –
C169 NOT PLACED –
C170 2113944C45 CAP CER CHP 100.0PF 50V
5%
C171 2113944C45 CAP CER CHP 100.0PF 50V
5%
C172 2113951C12 CAP,FXD,1.2PF,.05PF+/-,
250V-DC, 0603,C0G,-55DE
C173 2113944C13 CAP CER CHP 2.0PF 50V
+/- 0.25PF
C174 2113944C15 CAP CER CHP 2.4PF 50V
+/- 0.25PF
C175 2113944C70 CAP,FXD,5.1PF,.25PF+/-,
50V-DC, 0603,C0G,-55DEG
C176 2113944C29 CAP CER CHP 9.1PF 50V
+/- 0.5PF
C177 2113944C22 CAP CER CHP 4.7PF 50V
+/- 0.25PF
C178 2113944A18 CAP CER CHP 5.1PF 50V
+/- 0.5PF
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C179 2113944A40 CAP CER CHP 100.0PF 50V
5%
C182 2113944A40 CAP CER CHP 100.0PF 50V
5%
C185 2113945B02 CAP CER CHP 10,000PF 25V
10%
C186 NOT PLACED –
C187 2113944A40 CAP CER CHP 100.0PF 50V
5%
C188 2113944A40 CAP CER CHP 100.0PF 50V
5%
C189 2113944A40 CAP CER CHP 100.0PF 50V
5%
C191 NOT PLACED –
C192 2113944C21 CAP CER CHP 4.3PF 50V
+/- 0.25PF
C193 NOT PLACED –
C200 2113945A13 CAP CER CHP 4700PF 50V
10%
C201 2185419D06 CAP CER SUPER L/D 0.1UF
C202 2113945C27 CAP,FXD,.047UF,+10%,-10%,
50V-DC,0603,X7R,-55D
C203 2113945C27 CAP,FXD,.047UF,+10%,-10%,
50V-DC,0603,X7R,-55D
C204 2171115L01 CHIP MONOLITHIC CERAMIC
CAPACITOR
C206 2113946K02 CAP CER CHP 0.10UF 16V
C207 2113946K02 CAP CER CHP 0.10UF 16V
C208 2113946K02 CAP CER CHP 0.10UF 16V
C209 2113946K02 CAP CER CHP 0.10UF 16V
C210 2313960D07 CAP,FXD,10,+10,-10,16,
SM,-55MIN,125MAX,174,
C213 2113946K02 CAP CER CHP 0.10UF 16V
C214 2113945B02 CAP CER CHP 10,000PF 25V
10%
C215 2113944A40 CAP CER CHP 100.0PF 50V
5%
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
