Motorola ATS 3000

9.2-60 UHF1 Schematics, Board Overlays, and Parts Lists
February 14, 2012 6816985H01-F
C217 2113944A40 CAP CER CHP 100.0PF 50V
5%
C218 2113946K02 CAP CER CHP 0.10UF 16V
C219 2313960D07 CAP,FXD,10,+10,-10,16,SM,
-55MIN,125MAX,174,
C220 2113945B02 CAP CER CHP 10,000PF 25V
10%
C221 2113944A40 CAP CER CHP 100.0PF 50V
5%
C222 2313960D07 CAP,FXD,10,+10,-10,16,SM,
-55MIN,125MAX,174,
C226 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC, 0603,X7R,-55DEG
C227 2113944C45 CAP CER CHP 100.0PF 50V
5%
C228 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC, 0603,X7R,-55DEG
C229 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC, 0603,X7R,-55DEG
C230 2113946K02 CAP CER CHP 0.10UF 16V
C231 2113945A01 CAP CER CHP 220PF 50V 10,
C232 2113946K02 CAP CER CHP 0.10UF 16V
C233 2113946K02 CAP CER CHP 0.10UF 16V
C234 2113944A40 CAP CER CHP 100.0PF 50V
5%
C235 2113944A40 CAP CER CHP 100.0PF 50V
5%
C236 2185419D06 CAP CER SUPER L/D 0.1UF
C237 2185419D06 CAP CER SUPER L/D 0.1UF
C238 2185419D06 CAP CER SUPER L/D 0.1UF
C239 2185419D06 CAP CER SUPER L/D 0.1UF
C240 2185419D06 CAP CER SUPER L/D 0.1UF
C241 2113944A40 CAP CER CHP 100.0PF 50V
5%
C242 2113944A40 CAP CER CHP 100.0PF 50V
5%
C243 2113946K02 CAP CER CHP 0.10UF 16V
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C244 2113946B04 CAP CER CHP 0.10UF 10V
10%
C245 2113944A40 CAP CER CHP 100.0PF 50V
5%
C246 2113946N03 CAP CER CHP 2.2UF 16V
C247 2113945A09 CAP CER CHP 1000PF 50V
10%
C248 NOT PLACED –
C249 2113945A09 CAP CER CHP 1000PF 50V
10%
C251 2113944M16 CAP,FXD,8.2PF,.1PF+/-,
50V-DC, 0603,C0G,-55DEG
C252 2113944M17 CAP,FXD,9.1PF,.1PF+/-,
50V-DC, 0603,C0G,-55DEG
C253 2113944A11 CAP CER CHP 2.7PF 50V +/-
0.25PF
C254 2113946B04 CAP CER CHP 0.10UF 10V
10%
C255 2113944A40 CAP CER CHP 100.0PF 50V
5%
C256 2113944M18 CAP,FXD,10PF,+2.5%,-2.5%,
50V-DC,0603,C0G,-55D
C257 2113944M20 CAP,FXD,12PF,+2%,-2%,
50V-DC, 0603,C0G,-55DEG C
C258 2113944M17 CAP,FXD,9.1PF,.1PF+/-,
50V-DC, 0603,C0G,-55DEG
C259 2113944M35 CAP,FXD,51PF,+2%,-2%,
50V-DC, 0603,C0G,-55DEG C
C260 2113944A08 CAP CER CHP 2.0PF 50V
+/- 0.25PF
C261 2113944A40 CAP CER CHP 100.0PF 50V
5%
C262 2113946B04 CAP CER CHP 0.10UF 10V
10%
C263 2113944A40 CAP CER CHP 100.0PF 50V
5%
C264 2113944A19 CAP CER CHP 5.6PF 50V
+/- 0.5PF
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C265 2113944A40 CAP CER CHP 100.0PF 50V
5%
C266 2113944A40 CAP CER CHP 100.0PF 50V
5%
C267 2113944A81 CAP,FXD,24PF,+5%,-5%,
50V-DC,0402,C0G,-55DEG C
C268 2113944A27 CAP CER CHP 15.0PF 50V 5%
C269 2113946B04 CAP CER CHP 0.10UF 10V
10%
C271 2113944M15 CAP,FXD,7.5PF,.1PF+/-,
50V-DC, 0603,C0G,-55DEG
C272 2113944M15 CAP,FXD,7.5PF,.1PF+/-,
50V-DC, 0603,C0G,-55DEG
C273 2113944A14 CAP CER CHP 3.6PF 50V
+/- 0.25PF
C274 2113944M14 CAP,FXD,6.8PF,.1PF+/-,
50V-DC, 0603,C0G,-55DEG
C275 2113944M20 CAP,FXD,12PF,+2%,-2%,
50V-DC, 0603,C0G,-55DEG C
C276 2113944M16 CAP,FXD,8.2PF,.1PF+/-,
50V-DC, 0603,C0G,-55DEG
C277 2113944M35 CAP,FXD,51PF,+2%,-2%,
50V-DC, 0603,C0G,-55DEG C
C278 2113944A40 CAP CER CHP 100.0PF 50V
5%
C279 2113946B04 CAP CER CHP 0.10UF 10V
10%
C280 2113944A40 CAP CER CHP 100.0PF 50V
5%
C281 2113944A40 CAP CER CHP 100.0PF 50V
5%
C282 2113944A08 CAP CER CHP 2.0PF 50V
+/- 0.25PF
C283 2113946B04 CAP CER CHP 0.10UF 10V
10%
C284 2113944A40 CAP CER CHP 100.0PF 50V
5%
C285 2113944A05 CAP CER CHP 1.5PF 50V
+/- 0.25PF
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C286 2113944A40 CAP CER CHP 100.0PF 50V
5%
C287 2113944A40 CAP CER CHP 100.0PF 50V
5%
C288 2113944A21 CAP CER CHP 6.8PF 50V
+/- 0.5PF
C289 2113944A24 CAP CER CHP 9.1PF 50V
+/- 0.5PF
C290 2113944A22 CAP CER CHP 7.5PF 50V
+/- 0.5PF
C291 2113944A40 CAP CER CHP 100.0PF 50V
5%
C292 2113946B04 CAP CER CHP 0.10UF 10V
10%
C293 2113944A22 CAP CER CHP 7.5PF 50V
+/- 0.5PF
C294 2113944A28 CAP CER CHP 18.0PF 50V 5%
C295 2113944A40 CAP CER CHP 100.0PF 50V
5%
C400 2113944A40 CAP CER CHP 100.0PF 50V
5%
C401 2113946K02 CAP CER CHP 0.10UF 16V
C405 2113944A40 CAP CER CHP 100.0PF 50V
5%
C411 2113945A11 CAP CER CHP 2200PF 50V
10%
C412 NOT PLACED –
C416 2113946K02 CAP CER CHP 0.10UF 16V
C417 2113944A40 CAP CER CHP 100.0PF 50V
5%
C421 NOT PLACED –
C422 2113945B02 CAP CER CHP 10,000PF 25V
10%
C423 2113944C41 CAP CER CHP 68.0PF 50V 5%
C424 2113944A40 CAP CER CHP 100.0PF 50V
5%
C425 2113945H69 CAP,FXD,.1UF,+5%,-5%,
50V-DC, 1206,X7R,-55DEG C
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
