Motorola ATS 3000

UHF1 Schematics, Board Overlays, and Parts Lists 9.2-61
6816985H01-F February 14, 2012
C428 2113945B02 CAP CER CHP 10,000PF 25V
10%
C429 2113946K02 CAP CER CHP 0.10UF 16V
C430 2113946K02 CAP CER CHP 0.10UF 16V
C431 2113946K02 CAP CER CHP 0.10UF 16V
C432 2113946K02 CAP CER CHP 0.10UF 16V
C433 2113944C33 CAP CER CHP 18.0PF 50V 5%
C434 2113945C27 CAP,FXD,.047UF,+10%,-10%,
50V-DC,0603,X7R,-55D
C435 2113944A34 CAP CER CHP 56.0PF 50V 5%
C436 2113944A34 CAP CER CHP 56.0PF 50V 5%
C437 2113944C72 CAP,FXD,6.2PF,.25PF+/-,
50V-DC, 0603,C0G,-55DEG
C438 2113944C79 CAP,FXD,16PF,+5%,-5%,
50V-DC, 0603,C0G,-55DEG C
C440 2113945G96 CAP,FXD,.33UF,+10%,-10%,
50V-DC,0805,X7R,-55DE
C441 2313960M26 CAP,FXD,1UF,+10%,-10%,
10V-DC, SM,-55DEG CMIN,
C442 2113945B02 CAP CER CHP 10,000PF 25V
10%
C447 NOT PLACED –
C448 2113945C25 CAP,FXD,.033UF,+10%,-10%,
50V-DC,0603,X7R,-55D
C449 2113944A23 CAP CER CHP 8.2PF 50V
+/- 0.5PF
C461 2113946K02 CAP CER CHP 0.10UF 16V
C463 2113945C27 CAP,FXD,.047UF,+10%,-10%,
50V-DC,0603,X7R,-55D
C464 2113946K02 CAP CER CHP 0.10UF 16V
C465 2113946K02 CAP CER CHP 0.10UF 16V
C470 2113946K02 CAP CER CHP 0.10UF 16V
C472 2113946K02 CAP CER CHP 0.10UF 16V
C473 2113946K02 CAP CER CHP 0.10UF 16V
C475 NOT PLACED –
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C476 2113944C89 CAP,FXD,200PF,+5%,-5%,
50V-DC ,0603,C0G,-55DEG
C478 2113945C27 CAP,FXD,.047UF,+10%,-10%,
50V-DC,0603,X7R,-55D
C480 2313960M26 CAP,FXD,1UF,+10%,-10%,
10V-DC,SM,-55DEG CMIN,
C481 2313960B30 CAP,FXD,4.7UF,+10%,-10%,
10V-DC,SM,-55DEG CMIN
C482 2313960B30 CAP,FXD,4.7UF,+10%,-10%,
10V-DC,SM,-55DEG CMIN
C500 2113945A58 CAP,FXD,910PF,+10%,-10%,
50V-DC,0402,X7R,-55DE
C501 2113945A58 CAP,FXD,910PF,+10%,-10%,
50V-DC,0402,X7R,-55DE
C502 2113945A58 CAP,FXD,910PF,+10%,-10%,
50V-DC,0402,X7R,-55DE
C503 2113945A58 CAP,FXD,910PF,+10%,-10%,
50V-DC,0402,X7R,-55DE
C504 2113944A40 CAP CER CHP 100.0PF 50V
5%
C505 2113945G98 CAP,FXD,.47UF,+10%,-10%
,50V-DC,0805,X7R,-55DE
C506 2113946E02 CAP CER CHP 1.0UF 16V 10%
C507 2113945B02 CAP CER CHP 10,000PF 25V
10%
C508 2113945B02 CAP CER CHP 10,000PF 25V
10%
C509 2113945B02 CAP CER CHP 10,000PF 25V
10%
C510 2113946K02 CAP CER CHP 0.10UF 16V
C511 2113946K02 CAP CER CHP 0.10UF 16V
C512 2113946K02 CAP CER CHP 0.10UF 16V
C513 2113955E37 CAP,FXD,10UF,+10%,-10%,
16V-DC,1210,X7R,-55DEG
C514 2113955E37 CAP,FXD,10UF,+10%,-10%,
16V-DC,1210,X7R,-55DEG
C516 2113946E02 CAP CER CHP 1.0UF 16V 10%
C517 2113946E02 CAP CER CHP 1.0UF 16V 10%
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C518 2313960B57 CAP,FXD,10UF,+10%,-10%,
6.3V-DC,SM,-55DEG CMIN
C520 2113944A40 CAP CER CHP 100.0PF 50V
5%
C521 2113945B02 CAP CER CHP 10,000PF 25V
10%
C522 2113945B02 CAP CER CHP 10,000PF 25V
10%
C523 2113945B02 CAP CER CHP 10,000PF 25V
10%
C524 2313960G32 CAP,FXD,10UF,+10%,-10%,
35V-DC,SM,-55DEG CMIN
C525 2113945A58 CAP,FXD,910PF,+10%,-10%,
50V-DC,0402,X7R,-55DE
C526 2113945A58 CAP,FXD,910PF,+10%,-10%,
50V-DC,0402,X7R,-55DE
C527 2113945A58 CAP,FXD,910PF,+10%,-10%,
50V-DC,0402,X7R,-55DE
C528 2113944A40 CAP CER CHP 100.0PF 50V
5%
C529 NOT PLACED –
C550 2113945B02 CAP CER CHP 10,000PF 25V
10%
C551 2113945B02 CAP CER CHP 10,000PF 25V
10%
C607 2113946K02 CAP CER CHP 0.10UF 16V
C610 2113944A32 CAP CER CHP 39.0PF 50V 5%
C611 2113944A32 CAP CER CHP 39.0PF 50V 5%
C612 2113944A32 CAP CER CHP 39.0PF 50V 5%
C613 2113944A32 CAP CER CHP 39.0PF 50V 5%
C614 2113945A03 CAP CER CHP 330PF 50V 10%
C615 2113944A32 CAP CER CHP 39.0PF 50V 5%
C617 2113944A32 CAP CER CHP 39.0PF 50V 5%
C619 2113944A32 CAP CER CHP 39.0PF 50V 5%
C620 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603,X7R,-55DEG
C621 2113946K02 CAP CER CHP 0.10UF 16V
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C629 2113944A32 CAP CER CHP 39.0PF 50V 5%
C630 2113944A32 CAP CER CHP 39.0PF 50V 5%
C631 2113944A32 CAP CER CHP 39.0PF 50V 5%
C632 2113944A32 CAP CER CHP 39.0PF 50V 5%
C633 2113944A32 CAP CER CHP 39.0PF 50V 5%
C634 2113944A32 CAP CER CHP 39.0PF 50V 5%
C635 2113944A32 CAP CER CHP 39.0PF 50V 5%
C636 2113944A32 CAP CER CHP 39.0PF 50V 5%
C637 2113945L49 CAP,FXD,.01UF,+5%,-5%,
50V-DC, 0603,X7R,-55DEG
C638 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603,X7R,-55DEG
C640 NOT PLACED –
C641 NOT PLACED –
C652 2113944A40 CAP CER CHP 100.0PF 50V
5%
C653 2113944A36 CAP CER CHP 68.0PF 50V 5%
C654 2113944A36 CAP CER CHP 68.0PF 50V 5%
C655 2113944A40 CAP CER CHP 100.0PF 50V
5%
C656 2113944A36 CAP CER CHP 68.0PF 50V 5%
C657 2113944A36 CAP CER CHP 68.0PF 50V 5%
C658 2113944A40 CAP CER CHP 100.0PF 50V
5%
C671 2113944A31 CAP CER CHP 33.0PF 50V 5%
C672 2113944A40 CAP CER CHP 100.0PF 50V
5%
C673 2113944A31 CAP CER CHP 33.0PF 50V 5%
C674 2113945A05 CAP CER CHP 470PF 50V 10%
C675 2113944A40 CAP CER CHP 100.0PF 50V
5%
C680 2113944A31 CAP CER CHP 33.0PF 50V 5%
C700 2113946B04 CAP CER CHP 0.10UF 10V
10%
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
