Motorola ATS 3000

UHF1 Schematics, Board Overlays, and Parts Lists 9.2-63
6816985H01-F February 14, 2012
C865 2113945B02 CAP CER CHP 10,000PF 25V
10%
C866 2113945B02 CAP CER CHP 10,000PF 25V
10%
C867 NOT PLACED –
C868 NOT PLACED –
CR800 4813978A25 SCHOTTKY 30V SOD-323 T&R
PB FREE
CR801 4813978A25 SCHOTTKY 30V SOD-323 T&R
PB FREE
D3 4815096H01 VARACTOR DIODE 1SV305
D5 4815096H01 VARACTOR DIODE 1SV305
D10 4815096H01 VARACTOR DIODE 1SV305
D12 4815096H01 VARACTOR DIODE 1SV305
D20 4813974A19 DIODE ARRAY,MXR,SM,
SOT-323, 7V,.2W,SHTK,2,PB-F
D170 4802482J02 PIN DIODE SMD
D171 4802482J02 PIN DIODE SMD
D172 4813978A26 DIODE ARRAY,DET,SOT-363/
SC-88,30V,.12W,2
D173 4813978A26 DIODE ARRAY,DET,SOT-363/
SC-88,30V,.12W,2
D201 4815011H01 DIODE TRIPLE
D202 4815011H01 DIODE TRIPLE
D251 4815002H02 DIODE,VCTR, @ 30V,SILICON
EPITAXIAL
D252 4815002H02 DIODE,VCTR, @ 30V,SILICON
EPITAXIAL
D253 4815002H02 DIODE,VCTR, @ 30V,SILICON
EPITAXIAL
D254 4815002H02 DIODE,VCTR, @ 30V,SILICON
EPITAXIAL
D271 4815002H02 DIODE,VCTR, @ 30V,SILICON
EPITAXIAL
D272 4815002H02 DIODE,VCTR, @ 30V,SILICON
EPITAXIAL
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
D273 4815002H02 DIODE,VCTR, @ 30V,SILICON
EPITAXIAL
D274 4815002H02 DIODE,VCTR, @ 30V,SILICON
EPITAXIAL
D401 4805656W87 DIODE,VCTR, @ 15V,1SV279,
SOD-523/SC-79
D402 4815096H01 VARACTOR DIODE 1SV305
D403 4815096H01 VARACTOR DIODE 1SV305
D500 4815155H01 RECTIFIER
D501 4809118D02 LED BICOLOR
LNJ115W8POMT
D510 4813978M15 DIODE,RECT,1A,40V,
PB-FREE,NOTCOMPLETELY
D511 4813978B18 DIODE,SWG,BAT54,SM,
SOT-23,200MA,30V,.2W,SHTK,
D512 4813978M15 DIODE,RECT,1A,40V,
PB-FREE, NOTCOMPLETELY
D513 4813978M15 DIODE,RECT,1A,40V,
PB-FREE, NOTCOMPLETELY
D600 4813978B18 DIODE,SWG,BAT54,SM,
SOT-23, 200MA,30V,.2W,
SHTK,
D601 4813978A25 SCHOTTKY 30V SOD-323 T&R
PB FREE
D603 4813978A25 SCHOTTKY 30V SOD-323 T&R
PB FREE
D662 4813978A25 SCHOTTKY 30V SOD-323 T&R
PB FREE
D700 4813978B18 DIODE,SWG,BAT54,SM,
SOT-23,200MA,30V,.2W,SHTK,
E102 2480574F01 IND FERRITE CHIP 60OHM
0603
E140 2405688Z01 INDUCTOR FERRITE BEAD
E141 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E402 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E406 2414032B76 IDCTR,WW,4.7UH,5%,330MA,
4OHM,CER,20 Q,60MH
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
E800 2480574F01 IND FERRITE CHIP 60OHM
0603
E801 2480574F01 IND FERRITE CHIP 60OHM
0603
E802 0613952G67 CER CHIP RES 0.0 +/-0.050
OHM
FL51 9185924B01 FILTER, 73.35 MHZ 3-POLE
CRYST
FL200 9116848H01 FLTR SW CAP 3 POLE
BUTTERW, W18
F500 6515076H01 FUSE CHIP SMT TR/1608FF
3A
J101 2880658Z08 CONNECTOR SMA
J601 0916287H01 CONN VERT 45 PIN ZIF
J650 0916287H02 CONN 20 PIN ZIF
L5 2460591C16 COIL AIR WOUND INDUC
16.28
L12 2460591C16 COIL AIR WOUND INDUC
16.28
L31 2414017P13 IDCTR,CHIP,10NH,5%,300MA,
.46OHM,CER,9 Q,2.5GH
L33 2415429H36 CHIP INDUCTOR
L34 2415429H36 CHIP INDUCTOR
L42 2460591C16 COIL AIR WOUND INDUC
16.28
L49 2460591C16 COIL AIR WOUND INDUC
16.28
L53 2415429H43 CHIP INDUCTOR
L54 2414017K32 IDCTR,CHIP,560NH,5%,50MA,
5OHM,CER,11Q,150MHZS
L55 2414032D25 IDCTR,WW,620NH,5%,400MA,
1.6OHM,CER,28Q,400MHZ
L57 2414017P12 IDCTR,CHIP,8.2NH,5%,300MA,
.39OHM,CER,9 Q,2.8G
L61 2415429H39 CHIP INDUCTOR
L63 2414017P17 IDCTR,CHIP,22NH,5%,300MA,
.88OHM,CER,9 Q,1.8GH
L69 2415429H38 CHIP INDUCTOR
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
L71 2414017P16 IDCTR,CHIP,18NH,5%,300MA,
.76OHM,CER,9 Q,1.9GH
L72 2415429H38 CHIP INDUCTOR
L73 2415429H47 CHIP INDUCTOR
L74 2414017P17 IDCTR,CHIP,22NH,5%,300MA,
.88OHM,CER,9 Q,1.8GH
L106 2414032D30 IDCTR,WW,1UH,5%,320MA,
2.8OHM,CER,28 Q,340MHZ
L114 2414032B56 IDCTR,WW,180NH,5%,750MA,
.77OHM,CER,25 Q,700MH
L119 2460591C35 COIL AIR WOUND INDUC
18.08
L120 2414017G09 IDCTR,CHIP,15NH,5%,300MA,
.45OHM,CER,8Q,SM
L121 NOT PLACED –
L128 2414032D30 IDCTR,WW,1UH,5%,320MA,
2.8OHM,CER,28 Q,340MHZ
L130 2414017G09 IDCTR,CHIP,15NH,5%,300MA,
.45OHM,CER,8Q,SM
L131 2414017G01 IDCTR,CHIP,3.3NH,300MA,
.22OHM,CER,8Q,SM,
L132 NOT PLACED –
L134 2414017G03 IDCTR,CHIP,4.7NH,300MA,
.28OHM,CER,8 Q,SM,0603
L139 2460591A29 COIL AIR WOUND INDUC 6.61
L171 2460591B80 COIL AIR WOUND INDUC
19.61
L172 2460591B80 COIL AIR WOUND INDUC
19.61
L173 2460591B80 COIL AIR WOUND INDUC
19.61
L176 2460591D24 COIL AIR WOUND INDUC
19.71
L200 2414017Q47 IDCTR,FXD,1UH,10%,50MA
,.45OHM,FERR,45 Q,75MHZ
L201 2414017Q20 IDCTR,FXD,2.2UH,20%,30MA,
.65OHM,FERR,45Q,50MH
L202 2414017Q20 IDCTR,FXD,2.2UH,20%,30MA,
.65OHM,FERR,45Q,50MH
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
