Motorola ATS 3000

9.2-64 UHF1 Schematics, Board Overlays, and Parts Lists
February 14, 2012 6816985H01-F
L203 2414017Q20 IDCTR,FXD,2.2UH,20%,30MA
,.65OHM,FERR,45Q,50MH
L204 2414017Q20 IDCTR,FXD,2.2UH,20%,30MA,
.65OHM,FERR,45Q,50MH
L205 2414017Q47 IDCTR,FXD,1UH,10%,50MA,
.45OHM,FERR,45 Q,75MHZ
L206 2414017Q20 IDCTR,FXD,2.2UH,20%,30MA,
.65OHM,FERR,45Q,50MH
L251 2414032F41 IDCTR,WW,390NH,10%,200M,
1.5OHM,CER,40 Q,730M
L252 2415427H36 CHIP INDUCTOR
L253 2415010H04 AIRWOUND COIL
L254 2414032F41 IDCTR,WW,390NH,10%,200M,
1.5OHM,CER,40 Q,730M
L255 2414032F41 IDCTR,WW,390NH,10%,200M,
1.5OHM,CER,40 Q,730M
L256 2414032F41 IDCTR,WW,390NH,10%,200M,
1.5OHM,CER,40 Q,730M
L257 2414032F41 IDCTR,WW,390NH,10%,200M,
1.5OHM,CER,40 Q,730M
L258 2415427H26 CHIP INDUCTOR
L270 2414032F41 IDCTR,WW,390NH,10%,200M,
1.5OHM,CER,40 Q,730M
L271 2415427H37 CHIP INDUCTOR
L272 2415010H03 AIRWOUND COIL
L273 2414032F41 IDCTR,WW,390NH,10%,200M,
1.5OHM,CER,40 Q,730M
L274 2414032F41 IDCTR,WW,390NH,10%,200M,
1.5OHM,CER,40 Q,730M
L275 2414032F41 IDCTR,WW,390NH,10%,200M,
1.5OHM,CER,40 Q,730M
L276 2414032F41 IDCTR,WW,390NH,10%,200M,
1.5OHM,CER,40 Q,730M
L277 2414017H17 IDCTR,CHIP,27NH,5%,300MA,
.45OHM,CER,12Q,1.1GH
L278 2414017P18 IDCTR,CHIP,27NH,5%,300MA,
1.04OHM,CER,9 Q,1.5G
L279 2414017P18 IDCTR,CHIP,27NH,5%,300MA,
1.04OHM,CER,9 Q,1.5G
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
L280 2414017Q47 IDCTR,FXD,1UH,10%,50MA,
.45OHM,FERR,45 Q,75MHZ
L403 2414032B75 IDCTR,WW,3.9UH,5%,340MA,
3.6OHM,CER,20Q,70MHZS
L404 2414032B59 IDCTR,WW,330NH,5%,690MA,
1.05OHM,CER,30Q,500MH
L407 2414032B76 IDCTR,WW,4.7UH,5%,330MA,
4OHM,CER,20 Q,60MH
L411 2466505A01 COIL INDUCTOR
L412 2466505A01 COIL INDUCTOR
L413 2414032B59 IDCTR,WW,330NH,5%,690MA,
1.05OHM,CER,30Q,500MH
L414 2414017Q51 IDCTR,FXD,2.2UH,10%,30MA,
.65OHM,FERR,45 Q,50M
L500 2414017Q42 IDCTR,FXD,390NH,10%,
200MA, .65OHM,FERR,25Q,
135
L501 2414017Q51 IDCTR,FXD,2.2UH,10%,30MA,
.65OHM,FERR,45 Q,50M
L502 2489669V01 IDCTR,WW,100UH,5%,40MA,
10OHM,20 Q,10MHZ SRF,S
L651 2414032F75 IDCTR,WW,270NH,2%,350MA,
1OHM,CER,48 Q,650MHZ
L652 2414032F75 IDCTR,WW,270NH,2%,350MA,
1OHM,CER,48 Q,650MHZ
L701 2486085A01 COIL, POWER INDUCTOR
L702 2486085A01 COIL, POWER INDUCTOR
L703 2464675H01 IDCTR,WW,560NH,5%,550MA
L704 2464675H01 IDCTR,WW,560NH,5%,550MA
L705 2464675H01 IDCTR,WW,560NH,5%,550MA
L708 2416307H01 IDCTR,WW,680NH,5%,0603
L710 2416307H01 IDCTR,WW,680NH,5%,0603
M501 NOT PLACED –
M701 0985888K02 SKT RTC BTTY LEAP
P4 3905643V01 CONTACT ANT GRD
P5 3916333H02 GROUND CONTACT
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
Q29 4805585Q19 TRANSISTOR
Q101 4816698H03 MITSUBISHI RD09MUP2-T112
UHF RFPA
Q197 4813973A13 XSTR,BIP GP SS,PNP,TO-236,
SOT-23,SMT,40V,.
Q200 4871674S01 XSTR,BIP GP SS
Q251 4885061Y01 XSTR NPN 6V 30UA 12GHZ
PB-FREE
Q252 4885061Y01 XSTR NPN 6V 30UA 12GHZ
PB-FREE
Q253 4815055H01 TSTR DUAL NPN/PNP UMH 5
Q271 4885061Y01 XSTR NPN 6V 30UA 12GHZ
PB-FREE
Q272 4885061Y01 XSTR NPN 6V 30UA 12GHZ
PB-FREE
Q273 4815055H01 TSTR DUAL NPN/PNP UMH 5
Q401 4805585Q27 TRANSISTOR RF NPN,
BFQ67W NOPB
Q402 4813973A04 XSTR,BIP GP SS,NPN,TA13,
SM,SOT-23,SMT,30V,.22
Q501 4805921T28 XSTR, DUAL NOPB
Q698 4813973A81 XSTR,BIP GP SS,DIG,NPN
AND PNP,SOT-363,50V,.2
Q700 4813970A62 XSTR,FET GP PWR,MOSFET,
P-CH,ENHN,CF,-20V,1.3W
Q701 4813973M07 XSTR,BIP GP SS,NPN,TO-236,
SMT,40V,.225W,2
Q702 5185956E76 IC,CONV,SM,SO16,0-30
VINPUT RANGE,6.5A,3.8V
Q703 4813970A62 XSTR,FET GP PWR,MOSFET,
P-CH,ENHN,CF,-20V,1.3W
Q704 NOT PLACED –
Q705 NOT PLACED –
Q706 NOT PLACED –
Q709 4885061Y01 XSTR NPN 6V 30UA 12GHZ
PB-FREE
Q801 4813973A42 XSTR,BIP GP SS,NPN,SM,
SC-59, SMT,50V,.23W,
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
Q804 4813973A81 XSTR,BIP GP SS,DIG,NPN
AND PNP,SOT-363,50V,.2
R13 0613952R01 CER CHIP RES 10K OHM 5%
0402
R14 0613952R01 CER CHIP RES 10K OHM 5%
0402
R24 0613952Q93 CER CHIP RES 6800 OHM
5 0402
R32 0613952Q70 CER CHIP RES 750 OHM
5 0402
R33 0613952R01 CER CHIP RES 10K OHM 5%
0402
R34 0613952R01 CER CHIP RES 10K OHM 5%
0402
R35 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R36 0613952G67 CER CHIP RES 0.0 +/-0.050
OHM
R37 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R38 0613958J74 CER CHIP RES 0.0 OHM JMP
0805
R51 0613952Q46 CER CHIP RES 75.0 OHM
5 0402
R60 0613952R25 CER CHIP RES 100K OHM 5%
0402
R61 0613952Q81 CER CHIP RES 2200 OHM
5 0402
R62 0613952Q81 CER CHIP RES 2200 OHM
5 0402
R63 0613952Q69 CER CHIP RES 680 OHM
5 0402
R102 0613952R05 CER CHIP RES 15K OHM 5%
0402
R103 0613952Q42 CER CHIP RES 51.0 OHM
5 0402
R104 0613952R06 CER CHIP RES 16K OHM
5 0402
R108 0613952G67 CER CHIP RES 0.0 +/-0.050
OHM
