Motorola ATS 3000

UHF1 Schematics, Board Overlays, and Parts Lists 9.2-65
6816985H01-F February 14, 2012
R125 0613952H47 CER CHIP RES 82.0 OHM
5 0603
R127 0613952R01 CER CHIP RES 10K OHM 5%
0402
R130 0613952H53 CER CHIP RES 150 OHM 5%
0603
R142 0613952R14 CER CHIP RES 36K OHM
5 0402
R143 0613952Z64 RES,MF,39KOHM,1%,.0625W,
SM, 0402,200PPM/CEL,FO
R144 0613952R25 CER CHIP RES 100K OHM 5%
0402
R146 0613952H73 CER CHIP RES 1000 OHM 5%
0603
R149 0613952Q89 CER CHIP RES 4700 OHM
5 0402
R150 0613952H47 CER CHIP RES 82.0 OHM
5 0603
R151 0613952H47 CER CHIP RES 82.0 OHM
5 0603
R153 NOT PLACED –
R154 0613952Q61 CER CHIP RES 330 OHM
5 0402
R155 0613952Q76 CER CHIP RES 1300 OHM
5 0402
R156 NOT PLACED –
R157 NOT PLACED –
R158 NOT PLACED –
R159 0613952Q25 CER CHIP RES 10.0 OHM
5 0402
R160 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R162 NOT PLACED –
R168 0613952Q56 CER CHIP RES 200 OHM
5 0402
R169 0613952Q52 CER CHIP RES 130 OHM
5 0402
R170 0613952Q56 CER CHIP RES 200 OHM
5 0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R171 0613952Q52 CER CHIP RES 130 OHM
5 0402
R199 0613952H73 CER CHIP RES 1000 OHM 5%
0603
R201 0613952Q51 CER CHIP RES 120 OHM
5 0402
R202 0613952Q75 CER CHIP RES 1200 OHM
5 0402
R203 0613952Q63 CER CHIP RES 390 OHM
5 0402
R204 0613952R19 CER CHIP RES 56K OHM 5%
0402
R205 0613952R15 CER CHIP RES 39K OHM 5%
0402
R206 0613952R01 CER CHIP RES 10K OHM 5%
0402
R207 0613952Q73 CER CHIP RES 1000 OHM
5 0402
R208 0613952R13 CER CHIP RES 33K OHM 5%
0402
R209 0613952G67 CER CHIP RES 0.0 +/-0.050
OHM
R210 0613952R13 CER CHIP RES 33K OHM 5%
0402
R211 0613952Q80 CER CHIP RES 2000 OHM
5 0402
R212 NOT PLACED –
R213 0613952Q95 CER CHIP RES 8200 OHM
5 0402
R214 0613952Q73 CER CHIP RES 1000 OHM
5 0402
R215 0613952R01 CER CHIP RES 10K OHM 5%
0402
R216 0613952K93 CER CHIP RES 90.9 OHM 1
0402
R217 0613952Q88 CER CHIP RES 4300 OHM
5 0402
R218 0613952Q93 CER CHIP RES 6800 OHM
5 0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R248 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R249 NOT PLACED –
R252 0613952Q93 CER CHIP RES 6800 OHM
5 0402
R253 0613952Q96 CER CHIP RES 9100 OHM
5 0402
R256 0613952Q51 CER CHIP RES 120 OHM
5 0402
R257 0613952Q42 CER CHIP RES 51.0 OHM
5 0402
R260 0613952Q94 CER CHIP RES 7500 OHM
5 0402
R261 NOT PLACED –
R262 0613952Q91 CER CHIP RES 5600 OHM
5 0402
R263 0613952Q58 CER CHIP RES 240 OHM
5 0402
R265 0613952Q41 CER CHIP RES 47.0 OHM
5 0402
R266 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R269 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R270 0613952Q95 CER CHIP RES 8200 OHM
5 0402
R271 0613952Q93 CER CHIP RES 6800 OHM
5 0402
R272 0613952Q53 CER CHIP RES 150 OHM
5 0402
R277 NOT PLACED –
R278 0613952Q95 CER CHIP RES 8200 OHM
5 0402
R279 0613952Q88 CER CHIP RES 4300 OHM
5 0402
R280 0613952Q49 CER CHIP RES 100 OHM
5 0402
R284 0613952Q49 CER CHIP RES 100 OHM
5 0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R285 0613952Q73 CER CHIP RES 1000 OHM
5 0402
R286 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R287 NOT PLACED –
R288 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R289 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R290 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R406 0613952R01 CER CHIP RES 10K OHM 5%
0402
R407 0613952R01 CER CHIP RES 10K OHM 5%
0402
R408 0613952H79 CER CHIP RES 1800 OHM 5%
0603
R412 0613952H55 CER CHIP RES 180 OHM 5%
0603
R413 0613952H61 CER CHIP RES 330 OHM
5 0603
R414 0613952R01 CER CHIP RES 10K OHM 5%
0402
R415 0613952R01 CER CHIP RES 10K OHM 5%
0402
R417 0613952Q74 RES,MF,1.1KOHM,5%,.0625W,
SM,0402,200PPM/CEL,P
R418 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R419 0613952R25 CER CHIP RES 100K OHM 5%
0402
R420 0613952R19 CER CHIP RES 56K OHM 5%
0402
R436 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R499 0613952R01 CER CHIP RES 10K OHM 5%
0402
R503 0613952Q63 CER CHIP RES 390 OHM
5 0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
