Motorola ATS 3000

UHF2 Schematics, Board Overlays, and Parts Lists 9.3-31
6816985H01-F February 14, 2012
PMLE4427A/ PMLE4427B/ PMUE4007A/
PMUE4008A/PMUE4009A/PMUE4010A/
PMUE3700A/PMUE3665A/PMUE3702A/
PMUE3662A Main Circuit Board
Electrical Parts List
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
PCB 8416852H01 BOARD, PC, UHF BAND 2
B500 0986237A02 CONNECTOR (CONTACT
BATTERY)
C1 2113944A15 CAP CER CHP 3.9PF 50V
+/- 0.25PF
C2 2113944A23 CAP CER CHP 8.2PF 50V
+/- 0.5PF
C3 2113944C17 CAP CER CHP 3.0PF 50V +/-
0.25PF
C4 2113944A23 CAP CER CHP 8.2PF 50V
+/- 0.5PF
C5 2113944A15 CAP CER CHP 3.9PF 50V
+/- 0.25PF
C7 2113944A40 CAP CER CHP 100.0PF 50V
5%
C8 2113944A40 CAP CER CHP 100.0PF 50V
5%
C9 2113945B02 CAP CER CHP 10,000PF 25V
10%
C10 2113944A40 CAP CER CHP 100.0PF 50V
5%
C12 2113944A15 CAP CER CHP 3.9PF 50V
+/- 0.25PF
C13 2113944A24 CAP CER CHP 9.1PF 50V
+/- 0.5PF
C14 2113945Y02 CAP,FXD,.1UF,+10%,-10%,
16V-DC,0402,X7R
C15 2113944A40 CAP CER CHP 100.0PF 50V
5%
C16 2113944C17 CAP CER CHP 3.0PF 50V +/-
0.25PF
C17 2113944A24 CAP CER CHP 9.1PF 50V
+/- 0.5PF
C18 2113944A15 CAP CER CHP 3.9PF 50V
+/- 0.25PF
C21 2113945B02 CAP CER CHP 10,000PF 25V
10%
C51 2113944A14 CAP CER CHP 3.6PF 50V
+/- 0.25PF
C54 2113944C74 CAP,FXD,7.5PF,.25PF+/-,50V-
DC,0603,C0G
C55 2113945B02 CAP CER CHP 10,000PF 25V
10%
C57 2113944M12 CAP,FXD,5.6PF,.1PF+/-,
50V-DC, 0603
C58 2113944M07 CAP,FXD,3.6PF,.1PF+/-,
50V-DC,0603
C60 2113945Y02 CAP,FXD,.1UF,+10%,-10%,
16V-DC, 0402,X7R
C61 2113945A03 CAP CER CHP 330PF 50V 10%
C62 NOT PLACED –
C63 2113944C16 CAP CER CHP 2.7PF 50V +/-
0.25PF
C64 2113944C16 CAP CER CHP 2.7PF 50V +/-
0.25PF
C65 2113944C16 CAP CER CHP 2.7PF 50V +/-
0.25PF
C66 2113944C16 CAP CER CHP 2.7PF 50V +/-
0.25PF
C67 2113945B02 CAP CER CHP 10,000PF 25V
10%
C77 2113945B02 CAP CER CHP 10,000PF 25V
10%
C79 2113944A40 CAP CER CHP 100.0PF 50V
5%
C80 2113945B02 CAP CER CHP 10,000PF 25V
10%
C81 2113945A58 CAP,FXD,910PF,+10%,-10%,
50V-DC,0402,X7R
C82 2113944A40 CAP CER CHP 100.0PF 50V
5%
C88 2113945B02 CAP CER CHP 10,000PF 25V
10%
C89 2113946F03 CAP CER CHP 4.7UF 6.3V 10%
C90 2113944A40 CAP CER CHP 100.0PF 50V
5%
C100 2113944C45 CAP CER CHP 100.0PF 50V
5%
C101 NOT PLACED –
C102 2113944A40 CAP CER CHP 100.0PF 50V
5%
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C103 2113945B02 CAP CER CHP 10,000PF 25V
10%
C104 2113944A40 CAP CER CHP 100.0PF 50V
5%
C106 2113944A40 CAP CER CHP 100.0PF 50V
5%
C108 2113945B02 CAP CER CHP 10,000PF 25V
10%
C109 2113945B02 CAP CER CHP 10,000PF 25V
10%
C110 2113945B02 CAP CER CHP 10,000PF 25V
10%
C111 2113944C45 CAP CER CHP 100.0PF 50V
5%
C112 2113944C45 CAP CER CHP 100.0PF 50V
5%
C113 2113944C32 CAP CER CHP 15.0PF 50V 5%
C115 2113944C45 CAP CER CHP 100.0PF 50V
5%
C120 2113945G91 CAP,FXD,.1UF,+10%,-10%,
50V-DC,0805,X7R
C122 2113945C31 CAP,FXD,.1UF,+10%,-
10%,50V-DC ,0603,X7R
C124 2113944F50 CAP ,FXD,22PF,+5%,-5%,
50V-DC,0805
C125 2113944C20 CAP CER CHP 3.9PF 50V
+/- 0.25PF
C126 2113944F51 CAP,FXD,24PF,+5%,-5%,
50V-DC, 0805
C128 2113944F42 CAP,FXD,10PF,+5%,-5%,
50V-DC, 0805
C129 2113944C45 CAP CER CHP 100.0PF 50V
5%
C130 2113945B02 CAP CER CHP 10,000PF 25V
10%
C131 2113945B02 CAP CER CHP 10,000PF 25V
10%
C140 2113944A40 CAP CER CHP 100.0PF 50V
5%
C141 2113944C45 CAP CER CHP 100.0PF 50V
5%
C142 2313960A76 CAP,FXD,1UF,+10%,-10%,
20V-DC
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C143 2113945A10 CAP CER CHP 1500PF 50V
10%
C144 2113945A05 CAP CER CHP 470PF 50V 10%
C145 2113945B03 CAP,FXD,.015UF,+10%,-10%,
25V-DC,0402,X7R
C146 2113945Y02 CAP,FXD,.1UF,+10%,-10%,
16V-DC,0402,X7R
C147 2313960A76 CAP,FXD,1UF,+10%,-10%,
20V-DC
C148 2113944A40 CAP CER CHP 100.0PF 50V
5%
C149 2113945B02 CAP CER CHP 10,000PF 25V
10%
C170 2113944M10 CAP,FXD,4.7PF,.1PF+/-,
50V-DC,0603
C171 2113944C45 CAP CER CHP 100.0PF 50V
5%
C172 2113944C63 CAP,FXD,1PF,.1PF+/-,50V-DC,
0603
C173 2113944M10 CAP,FXD,4.7PF,.1PF+/-,
50V-DC,0603
C174 2113944C69 CAP,FXD,1.8PF,.1PF+/-,
50V-DC,0603
C175 2113944M13 CAP,FXD,6.2PF,.1PF+/-,
50V-DC, 0603
C176 2113944C30 CAP CER CHP 10.0PF 50V
+/- 0.5PF
C177 2113944M09 CAP,FXD,4.3PF,.1PF+/-,
50V-DC, 0603
C178 2113944A08 CAP CER CHP 2.0PF 50V
+/- 0.25PF
C179 2113944A40 CAP CER CHP 100.0PF 50V
5%
C180 NOT PLACED –
C181 2113944F56 CAP,FXD,39PF,+5%,-5%,
50V-DC,0805
C182 2113944C45 CAP CER CHP 100.0PF 50V
5%
C185 2113945B02 CAP CER CHP 10,000PF 25V
10%
C186 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC, 0603,X7R
C187 2113944A40 CAP CER CHP 100.0PF 50V
5%
