Motorola ATS 3000

9.3-32 UHF2 Schematics, Board Overlays, and Parts Lists
February 14, 2012 6816985H01-F
C188 2113944A40 CAP CER CHP 100.0PF 50V
5%
C189 2113944A40 CAP CER CHP 100.0PF 50V
5%
C191 NOT PLACED –
C200 2113945A13 CAP CER CHP 4700PF 50V
10%
C201 2185419D06 CAP CER SUPER L/D 0.1UF
C202 2113945C27 CAP,FXD,.047UF,+10%,-10%,
50V-DC,0603,X7R
C203 2113945C27 CAP,FXD,.047UF,+10%,-10%,
50V-DC,0603,X7R
C204 2185419D08 CAP CER SUPER L/D
0.0012UF
C206 2113945Y02 CAP,FXD,.1UF,+10%,-10%,
16V-DC,0402,X7R
C207 2113945Y02 CAP,FXD,.1UF,+10%,-10%,
16V-DC, 0402,X7R
C208 2113945Y02 CAP,FXD,.1UF,+10%,-10%,
16V-DC, 0402,X7R
C209 2113945Y02 CAP,FXD,.1UF,+10%,-10%,
16V-DC, 0402,X7R
C210 2313960D07 CAP,FXD,10,+10,-10,16,SM
C211 2113945Y02 CAP,FXD,.1UF,+10%,-10%,
16V-DC, 0402,X7R
C212 2113944A40 CAP CER CHP 100.0PF 50V
5%
C213 2113945Y02 CAP,FXD,.1UF,+10%,-10%,
16V-DC,0402,X7R
C214 2113945B02 CAP CER CHP 10,000PF 25V
10%
C215 2113944A40 CAP CER CHP 100.0PF 50V
5%
C217 2113944A40 CAP CER CHP 100.0PF 50V
5%
C218 2113945Y02 CAP,FXD,.1UF,+10%,-10%,
16V-DC, 0402,X7R
C219 2313960D07 CAP,FXD,10,+10,-10,16,SM
C220 2113945B02 CAP CER CHP 10,000PF 25V
10%
C221 2113944A40 CAP CER CHP 100.0PF 50V
5%
C222 2313960D07 CAP,FXD,10,+10,-10,16,SM
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C223 2113944A40 CAP CER CHP 100.0PF 50V
5%
C226 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC, 0603,X7R
C227 2113944A40 CAP CER CHP 100.0PF 50V
5%
C228 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC, 0603,X7R
C229 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC, 0603,X7R
C230 2113945Y02 CAP,FXD,.1UF,+10%,-10%,
16V-DC,0402,X7R
C231 2113945A01 CAP CER CHP 220PF 50V 10
C232 2113945Y02 CAP,FXD,.1UF,+10%,-10%,
16V-DC,0402,X7R
C233 2113945Y02 CAP,FXD,.1UF,+10%,-10%,
16V-DC,0402,X7R
C234 2113944A40 CAP CER CHP 100.0PF 50V
5%
C235 2113944A40 CAP CER CHP 100.0PF 50V
5%
C236 2185419D06 CAP CER SUPER L/D 0.1UF
C237 2185419D06 CAP CER SUPER L/D 0.1UF
C238 2185419D06 CAP CER SUPER L/D 0.1UF
C239 2185419D06 CAP CER SUPER L/D 0.1UF
C240 2185419D06 CAP CER SUPER L/D 0.1UF
C243 2113945Y02 CAP,FXD,.1UF,+10%,-10%,
16V-DC, 0402,X7R
C245 2113944A40 CAP CER CHP 100.0PF 50V
5%
C246 2113946N03 CAP CER CHP 2.2UF 16V
C247 2113945A09 CAP CER CHP 1000PF 50V
10%
C248 NOT PLACED –
C249 2113945A09 CAP CER CHP 1000PF 50V
10%
C250 2113944A40 CAP CER CHP 100.0PF 50V
5%
C251 2113945Y02 CAP,FXD,.1UF,+10%,-10%,
16V-DC, 0402,X7R
C253 2113944A11 CAP CER CHP 2.7PF 50V
+/- 0.25PF
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C254 2113944A08 CAP CER CHP 2.0PF 50V
+/- 0.25PF
C255 2113944A25 CAP CER CHP 10.0PF 50V
+/- 0.5PF
C256 2113944C77 CAP,FXD,11PF,+5%,-5%,
50V-DC, 0603,C
C257 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC ,0603,X7R
C258 2113945A03 CAP CER CHP 330PF 50V 10%
C259 2113944C77 CAP,FXD,11PF,+5%,-5%,
50V-DC, 0603,C
C261 2113944A40 CAP CER CHP 100.0PF 50V
5%
C262 NOT PLACED –
C263 2113944A08 CAP CER CHP 2.0PF 50V
+/- 0.25PF
C266 NOT PLACED –
C267 2113944A02 CAP CER CHP 1.2PF 50V
+/- 0.25PF
C271 2113944A08 CAP CER CHP 2.0PF 50V
+/- 0.25PF
C272 2113944A16 CAP CER CHP 4.3PF 50V
+/- 0.25PF
C273 2113944A17 CAP CER CHP 4.7PF 50V
+/- 0.25PF
C276 2113944A19 CAP CER CHP 5.6PF 50V
+/- 0.5PF
C277 2113944A29 CAP CER CHP 22.0PF 50V 5%
C278 2113944A34 CAP CER CHP 56.0PF 50V 5%
C280 2113944C21 CAP CER CHP 4.3PF 50V
+/- 0.25PF
C281 2113944C21 CAP CER CHP 4.3PF 50V
+/- 0.25PF
C282 2113944C21 CAP CER CHP 4.3PF 50V
+/- 0.25PF
C286 2113945A03 CAP CER CHP 330PF 50V 10%
C292 2113944A40 CAP CER CHP 100.0PF 50V
5%
C293 2113944A40 CAP CER CHP 100.0PF 50V
5%
C294 NOT PLACED –
C295 2113944A40 CAP CER CHP 100.0PF 50V
5%
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C296 2113944A40 CAP CER CHP 100.0PF 50V
5%
C400 2113944A40 CAP CER CHP 100.0PF 50V
5%
C401 2113945Y02 CAP,FXD,.1UF,+10%,-10%,
16V-DC, 0402,X7R
C405 2113944A40 CAP CER CHP 100.0PF 50V
5%
C411 2113945A11 CAP CER CHP 2200PF 50V
10%
C412 NOT PLACED –
C416 2113945Y02 CAP,FXD,.1UF,+10%,-10%,
16V-DC, 0402,X7R
C417 2113944A40 CAP CER CHP 100.0PF 50V
5%
C421 NOT PLACED –
C422 2113945B02 CAP CER CHP 10,000PF 25V
10%
C423 2113944C41 CAP CER CHP 68.0PF 50V 5%
C424 2113944A40 CAP CER CHP 100.0PF 50V
5%
C425 2113945H69 CAP,FXD,.1UF,+5%,-5%,
50V-DC, 1206,X7R
C428 2113945B02 CAP CER CHP 10,000PF 25V
10%
C429 2113945Y02 CAP,FXD,.1UF,+10%,-10%,
16V-DC, 0402,X7R
C430 2113945Y02 CAP,FXD,.1UF,+10%,-10%,
16V-DC, 0402,X7R
C431 2113945Y02 CAP,FXD,.1UF,+10%,-10%,
16V-DC, 0402,X7R
C432 2113945Y02 CAP,FXD,.1UF,+10%,-10%,
16V-DC, 0402,X7R
C433 2113944C33 CAP CER CHP 18.0PF 50V 5%
C434 2113945C27 CAP,FXD,.047UF,+10%,-10%,
50V-DC,0603,X7R
C435 2113944A34 CAP CER CHP 56.0PF 50V 5%
C436 2113944A34 CAP CER CHP 56.0PF 50V 5%
C437 2113944C72 CAP,FXD,6.2PF,.25PF+/-,
50V-DC, 0603
C438 2113944C79 CAP,FXD,16PF,+5%,-5%,
50V-DC, 0603
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
