Motorola ATS 3000

UHF2 Schematics, Board Overlays, and Parts Lists 9.3-33
6816985H01-F February 14, 2012
C440 2113945G96 CAP,FXD,.33UF,+10%,-10%,
50V-DC,0805,X7R
C441 2313960M26 CAP,FXD,1UF,+10%,-10%,
10V-DC
C442 2113945B02 CAP CER CHP 10,000PF 25V
10%
C447 NOT PLACED –
C448 2113945C25 CAP,FXD,.033UF,+10%,-10%,
50V-DC,0603,X7R
C449 2113944C75 CAP,FXD,8.2PF,.25PF+/-,
50V-DC,0603
C461 2113945Y02 CAP,FXD,.1UF,+10%,-10%,
16V-DC,0402,X7R
C463 2113945C27 CAP,FXD,.047UF,+10%,-10%,
50V-DC,0603,X7R
C464 2113945Y02 CAP,FXD,.1UF,+10%,-10%,
16V-DC, 0402,X7R
C465 2113945Y02 CAP,FXD,.1UF,+10%,-10%,
16V-DC, 0402,X7R
C470 2113945Y02 CAP,FXD,.1UF,+10%,-10%,
16V-DC, 0402,X7R
C472 2113945Y02 CAP,FXD,.1UF,+10%,-10%,
16V-DC, 0402,X7R
C473 2113945Y02 CAP,FXD,.1UF,+10%,-10%,
16V-DC, 0402,X7R
C475 NOT PLACED –
C476 2113944C89 CAP,FXD,200PF,+5%,-5%,
50V-DC,0603
C478 2113945C27 CAP,FXD,.047UF,+10%,-10%,
50V-DC,0603,X7R
C480 2313960M26 CAP,FXD,1UF,+10%,-10%,
10V-DC
C481 2313960B30 CAP,FXD,4.7UF,+10%,-10%,
10V-DC
C482 2313960B30 CAP,FXD,4.7UF,+10%,-10%,
10V-DC
C483 NOT PLACED –
C500 2113945A05 CAP CER CHP 470PF 50V 10%
C501 2113945A05 CAP CER CHP 470PF 50V 10%
C502 2113945A05 CAP CER CHP 470PF 50V 10%
C503 2113945A05 CAP CER CHP 470PF 50V 10%
C504 2113945A05 CAP CER CHP 470PF 50V 10%
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C505 2113945G98 CAP,FXD,.47UF,+10%,-10%,
50V-DC,0805,X7R
C506 2113946E02 CAP CER CHP 1.0UF 16V 10%
C507 2113945B02 CAP CER CHP 10,000PF 25V
10%
C508 2113945B02 CAP CER CHP 10,000PF 25V
10%
C509 2113945B02 CAP CER CHP 10,000PF 25V
10%
C510 2113945Y02 CAP,FXD,.1UF,+10%,-10%,
16V-DC, 0402,X7R
C511 2113945Y02 CAP,FXD,.1UF,+10%,-10%,
16V-DC, 0402,X7R
C512 2113945Y02 CAP,FXD,.1UF,+10%,-10%,
16V-DC, 0402,X7R
C513 2113955E37 CAP,FXD,10UF,+10%,-10%,
16V-DC,1210,X7R
C514 2113955E37 CAP,FXD,10UF,+10%,-10%,
16V-DC,1210,X7R
C516 2113946E02 CAP CER CHP 1.0UF 16V 10%
C517 2113946E02 CAP CER CHP 1.0UF 16V 10%
C518 2313960B57 CAP,FXD,10UF,+10%,-10%,
6.3V-DC
C520 2113944A40 CAP CER CHP 100.0PF 50V
5%
C521 2113945B02 CAP CER CHP 10,000PF 25V
10%
C522 2113945B02 CAP CER CHP 10,000PF 25V
10%
C523 2113945B02 CAP CER CHP 10,000PF 25V
10%
C524 2314030U26 CAP,FXD,10UF,+10%,-10%,
35V-DC
C525 2113944A38 CAP CER CHP 82.0PF 50V 5%
C526 2113944A38 CAP CER CHP 82.0PF 50V 5%
C527 2113944A40 CAP CER CHP 100.0PF 50V
5%
C530 2113944A40 CAP CER CHP 100.0PF 50V
5%
C540 2113944A45 CAP CER CHP 270.0 PF 50V
5%
C541 2113944A45 CAP CER CHP 270.0 PF 50V
5%
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C550 2113945B02 CAP CER CHP 10,000PF 25V
10%
C607 2113945Y02 CAP,FXD,.1UF,+10%,-10%,
16V-DC, 0402,X7R
C610 2113944A32 CAP CER CHP 39.0PF 50V 5%
C611 2113944A32 CAP CER CHP 39.0PF 50V 5%
C612 2113944A32 CAP CER CHP 39.0PF 50V 5%
C613 2113944A32 CAP CER CHP 39.0PF 50V 5%
C614 2113945A03 CAP CER CHP 330PF 50V 10%
C615 2113944A32 CAP CER CHP 39.0PF 50V 5%
C617 2113944A32 CAP CER CHP 39.0PF 50V 5%
C619 2113944A32 CAP CER CHP 39.0PF 50V 5%
C620 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC, 0603,X7R
C621 2113945Y02 CAP,FXD,.1UF,+10%,-10%,
16V-DC, 0402,X7R
C629 2113944A40 CAP CER CHP 100.0PF 50V
5%
C630 2113944A40 CAP CER CHP 100.0PF 50V
5%
C631 2113944A40 CAP CER CHP 100.0PF 50V
5%
C632 2113944A40 CAP CER CHP 100.0PF 50V
5%
C633 2113944A40 CAP CER CHP 100.0PF 50V
5%
C634 2113944A40 CAP CER CHP 100.0PF 50V
5%
C635 2113944A40 CAP CER CHP 100.0PF 50V
5%
C636 2113944A40 CAP CER CHP 100.0PF 50V
5%
C637 2113945L49 CAP,FXD,.01UF,+5%,-5%,
50V-DC, 0603,X7R
C638 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC, 0603,X7R
C640 NOT PLACED –
C641 NOT PLACED –
C652 2113944A40 CAP CER CHP 100.0PF 50V
5%
C653 2113944A40 CAP CER CHP 100.0PF 50V
5%
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C654 2113944A40 CAP CER CHP 100.0PF 50V
5%
C655 2113944A40 CAP CER CHP 100.0PF 50V
5%
C656 2113944A40 CAP CER CHP 100.0PF 50V
5%
C657 2113944A40 CAP CER CHP 100.0PF 50V
5%
C658 2113944A40 CAP CER CHP 100.0PF 50V
5%
C671 2113944A31 CAP CER CHP 33.0PF 50V 5%
C672 2113944A40 CAP CER CHP 100.0PF 50V
5%
C673 2113944A31 CAP CER CHP 33.0PF 50V 5%
C674 2113945A05 CAP CER CHP 470PF 50V 10%
C675 2113944A40 CAP CER CHP 100.0PF 50V
5%
C680 2113944A31 CAP CER CHP 33.0PF 50V 5%
C700 2113946B04 CAP CER CHP 0.10UF 10V
10%
C701 2113944A19 CAP CER CHP 5.6PF 50V
+/- 0.5PF
C702 2113944A19 CAP CER CHP 5.6PF 50V
+/- 0.5PF
C703 NOT PLACED –
C704 2113946F01 CAP CER CHP 2.2UF 6.3V 10%
C705 2113946F01 CAP CER CHP 2.2UF 6.3V 10%
C706 2113945A09 CAP CER CHP 1000PF 50V
10%
C708 2113944A31 CAP CER CHP 33.0PF 50V 5%
C709 2113944A31 CAP CER CHP 33.0PF 50V 5%
C710 2113946J03 CAP CER CHP 10.0UF 16V
10%
C711 2113946F03 CAP CER CHP 4.7UF 6.3V 10%
C712 2113946E02 CAP CER CHP 1.0UF 16V 10%
C713 2314030F31 CAP,FXD,68UF,+10%,-10%,
10V-DC
C714 2113945A09 CAP CER CHP 1000PF 50V
10%
C715 2314030F31 CAP,FXD,68UF,+10%,-10%,
10V-DC
C716 2113946F01 CAP CER CHP 2.2UF 6.3V 10%
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
