Motorola ATS 3000

9.3-34 UHF2 Schematics, Board Overlays, and Parts Lists
February 14, 2012 6816985H01-F
C717 2113946E02 CAP CER CHP 1.0UF 16V 10%
C718 2113946F01 CAP CER CHP 2.2UF 6.3V 10%
C719 2113946E02 CAP CER CHP 1.0UF 16V 10%
C720 2113946G01 CAP CER CHP 2.2UF 16V 10%
C721 2113946E02 CAP CER CHP 1.0UF 16V 10%
C722 2113946E02 CAP CER CHP 1.0UF 16V 10%
C723 2113946E02 CAP CER CHP 1.0UF 16V 10%
C724 2113946E02 CAP CER CHP 1.0UF 16V 10%
C725 2113945Y02 CAP,FXD,.1UF,+10%,-10%,
16V-DC, 0402,X7R
C726 2113944F07 CAP,CHIP,1000PF,+5%,-
5%,50V-DC,0805,C0G
C727 2113944A40 CAP CER CHP 100.0PF 50V
5%
C728 2113944A40 CAP CER CHP 100.0PF 50V
5%
C729 2314030U26 CAP,FXD,10UF,+10%,-
10%,35V-DC
C730 2113944A40 CAP CER CHP 100.0PF 50V
5%
C731 2113946G01 CAP CER CHP 2.2UF 16V 10%
C732 2113944A40 CAP CER CHP 100.0PF 50V
5%
C734 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC, 0603,X7R
C735 2113946E02 CAP CER CHP 1.0UF 16V 10%
C736 2113946J03 CAP CER CHP 10.0UF 16V
10%
C737 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC, 0603,X7R
C738 2113945Y02 CAP,FXD,.1UF,+10%,-10%,
16V-DC, 0402,X7R
C742 2113945A05 CAP CER CHP 470PF 50V 10%
C743 2113944A25 CAP CER CHP 10.0PF 50V
+/- 0.5PF
C750 2113946J03 CAP CER CHP 10.0UF 16V
10%
C751 2113946J03 CAP CER CHP 10.0UF 16V
10%
C752 2113944A40 CAP CER CHP 100.0PF 50V
5%
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C753 2113944A40 CAP CER CHP 100.0PF 50V
5%
C754 2113946E02 CAP CER CHP 1.0UF 16V 10%
C755 2113946E02 CAP CER CHP 1.0UF 16V 10%
C756 2113944A40 CAP CER CHP 100.0PF 50V
5%
C757 2113944A40 CAP CER CHP 100.0PF 50V
5%
C758 2113946E02 CAP CER CHP 1.0UF 16V 10%
C759 2113946E02 CAP CER CHP 1.0UF 16V 10%
C760 2113944A40 CAP CER CHP 100.0PF 50V
5%
C761 2113944A40 CAP CER CHP 100.0PF 50V
5%
C762 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC, 0603,X7R
C763 2113944A40 CAP CER CHP 100.0PF 50V
5%
C764 2113946B03 CAP CER CHP 0.068UF 10V 10
C765 2113946B03 CAP CER CHP 0.068UF 10V 10
C766 2113944A40 CAP CER CHP 100.0PF 50V
5%
C767 2113944A40 CAP CER CHP 100.0PF 50V
5%
C768 2113944A40 CAP CER CHP 100.0PF 50V
5%
C769 2113944A40 CAP CER CHP 100.0PF 50V
5%
C770 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC, 0603,X7R
C771 2113945C31 CAP,FXD,.1UF,+10%,-10%,
50V-DC, 0603,X7R
C773 2113945Y02 CAP,FXD,.1UF,+10%,-10%,
16V-DC, 0402,X7R
C777 2113944A40 CAP CER CHP 100.0PF 50V
5%
C790 2113946A02 CAP CER CHP 0.022UF 16V 10
C791 2113945Y02 CAP,FXD,.1UF,+10%,-10%,
16V-DC, 0402,X7R
C792 2113945Y02 CAP,FXD,.1UF,+10%,-10%,
16V-DC, 0402,X7R
C796 2113944A40 CAP CER CHP 100.0PF 50V
5%
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C800 2113955D31 CAP,FXD,1UF,+10%,-10%,
16V-DC, 1206,X7R
C801 2113944A40 CAP CER CHP 100.0PF 50V
5%
C802 2113945C20 CAP,FXD,.016UF,+10%,-10%,
50V-DC,0603,X7R
C803 2113944A40 CAP CER CHP 100.0PF 50V
5%
C804 2113946E02 CAP CER CHP 1.0UF 16V 10%
C805 2113945C20 CAP,FXD,.016UF,+10%,-10%,
50V-DC,0603,X7R
C806 2113945Y02 CAP,FXD,.1UF,+10%,-10%,
16V-DC ,0402,X7R
C807 2113945Y02 CAP,FXD,.1UF,+10%,-10%,
16V-DC, 0402,X7R
C808 2113945Y02 CAP,FXD,.1UF,+10%,-10%,
16V-DC, 0402,X7R
C809 2113945C20 CAP,FXD,.016UF,+10%,-10%,
50V-DC,0603,X7R
C810 2113946E02 CAP CER CHP 1.0UF 16V 10%
C811 2113945Y02 CAP,FXD,.1UF,+10%,-10%,
16V-DC, 0402,X7R
C812 2113945Y02 CAP,FXD,.1UF,+10%,-10%,
16V-DC, 0402,X7R
C813 2113945Y02 CAP,FXD,.1UF,+10%,-10%,
16V-DC, 0402,X7R
C814 2113945Y02 CAP,FXD,.1UF,+10%,-10%,
16V-DC, 0402,X7R
C815 2113945Y02 CAP,FXD,.1UF,+10%,-10%,
16V-DC, 0402,X7R
C816 2113945Y02 CAP,FXD,.1UF,+10%,-10%,
16V-DC, 0402,X7R
C817 2113945Y02 CAP,FXD,.1UF,+10%,-10%,
16V-DC, 0402,X7R
C818 2113945Y02 CAP,FXD,.1UF,+10%,-10%,
16V-DC, 0402,X7R
C830 2113945Y02 CAP,FXD,.1UF,+10%,-10%,
16V-DC, 0402,X7R
C840 2113946F03 CAP CER CHP 4.7UF 6.3V 10%
C850 2113945A03 CAP CER CHP 330PF 50V 10%
C851 2113944A40 CAP CER CHP 100.0PF 50V
5%
C855 NOT PLACED –
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C856 NOT PLACED –
C857 NOT PLACED –
C858 2113945B02 CAP CER CHP 10,000PF 25V
10%
C859 2113945B02 CAP CER CHP 10,000PF 25V
10%
C860 2113945B02 CAP CER CHP 10,000PF 25V
10%
C861 2113945B02 CAP CER CHP 10,000PF 25V
10%
C862 2113945B02 CAP CER CHP 10,000PF 25V
10%
C863 2113945B02 CAP CER CHP 10,000PF 25V
10%
C864 2113945B02 CAP CER CHP 10,000PF 25V
10%
C865 2113945B02 CAP CER CHP 10,000PF 25V
10%
C866 2113945B02 CAP CER CHP 10,000PF 25V
10%
C867 NOT PLACED –
C868 NOT PLACED –
C873 NOT PLACED –
CR1 4805656W90 DIODE V.1SV304(TPH3,F)
SOD323 NOPB
CR2 4805656W90 DIODE V.1SV304(TPH3,F)
SOD323 NOPB
CR3 4815048H01 SOT MMBD353 DIODE DUAL
SCHT
CR4 4805656W90 DIODE
V.1SV304(TPH3,F)SOD323
NOPB
CR5 4805656W90 DIODE
V.1SV304(TPH3,F)SOD323
NOPB
CR800 4813978A25 SCHOTTKY 30V SOD-323 T&R
PB FREE
CR801 4813978A25 SCHOTTKY 30V SOD-323 T&R
PB FREE
D100 NOT PLACED –
D170 4802482J02 PIN DIODE SMD
D171 4802482J02 PIN DIODE SMD
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
