Motorola ATS 3000

9.3-36 UHF2 Schematics, Board Overlays, and Parts Lists
February 14, 2012 6816985H01-F
L271 2414032F41 IDCTR,WW,390NH,10%,200M,
1.5OHM,CER,40 Q,730MHZ
SRF,SM,LEAD
L273 2414032F41 IDCTR,WW,390NH,10%,200M,
1.5OHM,CER,40 Q,730MHZ
SRF,SM,LEAD
L274 2415429H20 CHIP INDUCTOR 18nH
L275 2460591C02
(PMLE4427A)
2475672M01
(PMLE4427B)
COIL AIR WOUND INDUC 9.31
RF AIR WOUND COIL 8.9NH
L276 2415429H21 CHIP INDUCTOR 22nH
L403 2414032B75 IDCTR,WW,3.9UH,5%,340MA,
3.6OHM,CER,20Q,70MHZSRF,
SM,LEAD-FRE
L404 2414032B59 IDCTR,WW,330NH,5%,690MA,
1.05OHM,CER,30Q,500MHZS
RF, SM,LEAD-F
L407 2414032B76 IDCTR,WW,4.7UH,5%,330MA,
4OHM,CER,20 Q,60MHZ
SRF,SM
L411 2466505A01 COIL INDUCTOR 10uH
L412 2466505A01 COIL INDUCTOR 10uH
L413 2414032B59 IDCTR,WW,330NH,5%,690MA,
1.05OHM,CER,30Q,500MHZS
RF, SM,LEAD-F
L414 2414017Q51 IDCTR,FXD,2.2UH,10%,30MA,
.65OHM,FERR,45 Q,50MHZ
SRF,SM,0805
L500 2414017Q42 IDCTR,FXD,390NH,10%,200M
A,.65OHM,FERR,25Q,
135MHZSRF, SM,0805
L501 2414017Q51 IDCTR,FXD,2.2UH,10%,30MA,
.65OHM,FERR,45 Q,50MHZ
SRF,SM,0805
L502 2489669V01 IDCTR,WW,100UH,5%,40MA,
10OHM,20 Q,10MHZ SRF,SM,
1210,PB-FREE
L651 2414032F75 IDCTR,WW,270NH,2%,350MA,
1OHM,CER,48 Q,650MHZ
SRF,SM, 0805
L652 2414032F75 IDCTR,WW,270NH,2%,350MA,
1OHM,CER,48 Q,650MHZ
SRF,SM, 0805
L701 2486085A01 COIL, POWER INDUCTOR
L702 2486085A01 COIL, POWER INDUCTOR
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
L703 2464675H01 IDCTR,WW,560NH,5%,550MA
L704 2464675H01 IDCTR,WW,560NH,5%,550MA
L705 2464675H01 IDCTR,WW,560NH,5%,550MA
L708 2416307H01 IDCTR,WW,680NH,5%,0603
L710 2416307H01 IDCTR,WW,680NH,5%,0603
M501 NOT PLACED –
M701 0985888K02 SKT RTC BTTY LEAP
P4 3905643V01 CONTACT ANT GRD
P100 3916333H02 GROUND CONTACT
Q1 4816531H01 NPN SILICON BIPOLAR
TRANSISTOR
Q101 4816698H03 MITSUBISHI RD09MUP2-T112
UHF RFPA
Q197 4813973A13 XSTR,BIP GP SS,PNP,TO-236,
SOT-23,SMT,40V,.225W,
200MA, 250M
Q200 4871674S01 XSTR,BIP GP SS
Q250 4805218N63 RF TRANS SOT 323 BFQ67W
Q251 4816371H01 XSTR DUAL PNP W18
COMPLIANT
Q401 4805585Q27 TRANSISTOR RF NPN,
BFQ67W NOPB
Q402 4813973A04 XSTR,BIP GP SS,NPN,TA13,
SM,SOT-23,SMT,30V,.225W,
300MA,125MHZ
Q501 4805921T28 XSTR, DUAL NOPB
Q698 4813973A81 XSTR,BIP GP SS,DIG,NPN
AND PNP,SOT-363,50V,.25W,
100MA,BIAS
Q700 4813970A62 XSTR,FET GP PWR,MOSFET,
P-CH,ENHN,CF,-20V,1.3W,
PB-FREE
Q701 4813973M07 XSTR,BIP GP SS,NPN,TO-236,
SMT,40V,.225W,200MA,300MH
Z, PB-FREE
Q702 5185956E76 IC,CONV,SM,SO16,0-30
VINPUT RANGE,6.5A,3.8V,HI
SPD SWTH DR
Q703 4813970A62 XSTR,FET GP PWR,MOSFET,
P-CH,ENHN,CF,-20V,1.3W,
PB-FREE
Q704 NOT PLACED –
Q705 NOT PLACED –
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
Q706 NOT PLACED –
Q709 4885061Y01 XSTR NPN 6V 30UA 12GHZ
PB-FREE
Q801 4813973A42 XSTR,BIP GP SS,NPN,SM,
SC-59, SMT,50V,.23W,BIAS
RSTR. TRANS
Q804 4813973A81 XSTR,BIP GP SS,DIG,NPN
AND PNP,SOT-363,50V,.25W,
100MA, BIAS
R1 0613952R25 CER CHIP RES 100K OHM 5%
0402
R2 0613952R25 CER CHIP RES 100K OHM 5%
0402
R3 0613952Q73 CER CHIP RES 1000 OHM
5 0402
R4 0613952R03 CER CHIP RES 12K OHM 5%
0402
R5 0613952Q65 CER CHIP RES 470 OHM
5 0402
R6 0613952R25 CER CHIP RES 100K OHM 5%
0402
R7 0613952R25 CER CHIP RES 100K OHM 5%
0402
R28 0613952Q09 CER CHIP RES 2.2 OHM
5 0402
R40 0613952Q95 CER CHIP RES 8200 OHM
5 0402
R42 0613952R25 CER CHIP RES 100K OHM 5%
0402
R51 0613952Q46 CER CHIP RES 75.0 OHM
5 0402
R56 NOT PLACED
R102 0613952R05 CER CHIP RES 15K OHM 5%
0402
R103 0613952Q73 CER CHIP RES 1000 OHM
5 0402
R104 0613952R07 CER CHIP RES 18K OHM 5%
0402
R105 0613958H55 CER CHIP RES 180 OHM 5%
0805
R108 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R109 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R125 0613952H47 CER CHIP RES 82.0 OHM
5 0603
R127 0613952R01 CER CHIP RES 10K OHM 5%
0402
R142 0613952Z63 RES,MF,36KOHM,1%,.0625W,
SM, 0402,200PPM/CEL,
PB-FREE
R143 0613952Z64 RES,MF,39KOHM,1%,.0625W,
SM, 0402
R144 0613952R25 CER CHIP RES 100K OHM 5%
0402
R146 0613952H73 CER CHIP RES 1000 OHM 5%
0603
R147 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R149 0613952Q89 CER CHIP RES 4700 OHM
5 0402
R150 0613952H47 CER CHIP RES 82.0 OHM
5 0603
R151 0613952H47 CER CHIP RES 82.0 OHM
5 0603
R152 NOT PLACED –
R153 NOT PLACED –
R154 0613952Q49 CER CHIP RES 100 OHM
5 0402
R155 0613952Q68 CER CHIP RES 620 OHM
5 0402
R156 NOT PLACED –
R157 NOT PLACED –
R158 NOT PLACED –
R159 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R160 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R162 NOT PLACED –
R168 0613952Q52 CER CHIP RES 130 OHM
5 0402
R169 0613952Q46 CER CHIP RES 75.0 OHM
5 0402
R170 0613952Q53 CER CHIP RES 150 OHM
5 0402
R171 0613952Q46 CER CHIP RES 75.0 OHM
5 0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
