Motorola ATS 3000

UHF2 Schematics, Board Overlays, and Parts Lists 9.3-37
6816985H01-F February 14, 2012
R172 NOT PLACED –
R173 NOT PLACED –
R199 0613952J01 CER CHIP RES 10K OHM 5%
0603
R201 0613952Q47 CER CHIP RES 82.0 OHM 5%
0402
R202 0613952Q69 CER CHIP RES 680 OHM
5 0402
R203 0613952Q57 CER CHIP RES 220 OHM
5 0402
R204 0613952R17 CER CHIP RES 47K OHM 5%
0402
R205 0613952R12 CER CHIP RES 30K OHM
5 0402
R206 0613952R01 CER CHIP RES 10K OHM 5%
0402
R207 0613952Q73 CER CHIP RES 1000 OHM
5 0402
R208 0613952R13 CER CHIP RES 33K OHM 5%
0402
R209 0613952G67 CER CHIP RES 0.0 +/-0.050
OHM
R210 0613952R13 CER CHIP RES 33K OHM 5%
0402
R211 0613952Q80 CER CHIP RES 2000 OHM
5 0402
R212 NOT PLACED –
R213 0613952Q95 CER CHIP RES 8200 OHM
5 0402
R214 0613952Q73 CER CHIP RES 1000 OHM
5 0402
R215 0613952R01 CER CHIP RES 10K OHM 5%
0402
R216 0613952K93 CER CHIP RES 90.9 OHM 1
0402
R251 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R252 0613952R01 CER CHIP RES 10K OHM 5%
0402
R253 0613952R05 CER CHIP RES 15K OHM 5%
0402
R254 0613952R35 CER CHIP RES 270K OHM 5%
0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R255 0613952Q73 CER CHIP RES 1000 OHM
5 0402
R257 0613958T74 CER CHIP RES 0.0 OHM JMP
1206
R258 0613952Q22 CER CHIP RES 7.5 OHM
5 0402
R259 0613952Q61 CER CHIP RES 330 OHM
5 0402
R266 2113944V03 CAP,FXD,1PF,.1PF+/-,50V-DC,
0402,C0G,-55DEG CMIN,
125DEG CMAX,PB
R270 0613952Q51 CER CHIP RES 120 OHM
5 0402
R271 0613952Q36 CER CHIP RES 30.0 OHM
5 0402
R272 0613952Q56 CER CHIP RES 200 OHM
5 0402
R273 0613952Q56 CER CHIP RES 200 OHM
5 0402
R274 0613952Q32 CER CHIP RES 20.0 OHM
5 0402
R275 0613952Q56 CER CHIP RES 200 OHM
5 0402
R276 0613952R01 CER CHIP RES 10K OHM 5%
0402
R278 0613952R03 CER CHIP RES 12K OHM 5%
0402
R291 0613952Q36 CER CHIP RES 30.0 OHM
5 0402
R293 0613952Q32 CER CHIP RES 20.0 OHM
5 0402
R294 0613952Q61 CER CHIP RES 330 OHM
5 0402
R295 0613952R01 CER CHIP RES 10K OHM 5%
0402
R296 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R297 NOT PLACED –
R298 NOT PLACED –
R299 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R406 0613952R01 CER CHIP RES 10K OHM 5%
0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R407 0613952R01 CER CHIP RES 10K OHM 5%
0402
R408 0613952H79 CER CHIP RES 1800 OHM 5%
0603
R412 0613952H55 CER CHIP RES 180 OHM 5%
0603
R413 0613952H61 CER CHIP RES 330 OHM
5 0603
R414 0613952R01 CER CHIP RES 10K OHM 5%
0402
R415 0613952R01 CER CHIP RES 10K OHM 5%
0402
R417 0613952Q74 RES,MF,1.1KOHM,5%,.0625W,
SM,0402,200PPM/CEL,
PB-FREE
R418 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R419 0613952R25 CER CHIP RES 100K OHM 5%
0402
R420 0613952R19 CER CHIP RES 56K OHM 5%
0402
R436 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R499 0613952R01 CER CHIP RES 10K OHM 5%
0402
R503 0613952Q63 CER CHIP RES 390 OHM
5 0402
R504 0613952Q66 CER CHIP RES 510 OHM
5 0402
R505 0613952Q93 CER CHIP RES 6800 OHM 5
0402
R507 0613952Q49 CER CHIP RES 100 OHM
5 0402
R508 0613952Q49 CER CHIP RES 100 OHM
5 0402
R509 0613952Q49 CER CHIP RES 100 OHM
5 0402
R510 0613952Q49 CER CHIP RES 100 OHM
5 0402
R511 0613952R01 CER CHIP RES 10K OHM 5%
0402
R512 0613952R17 CER CHIP RES 47K OHM 5%
0402
R513 0613952R01 CER CHIP RES 10K OHM 5%
0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R514 0613952R01 CER CHIP RES 10K OHM 5%
0402
R515 0613952R01 CER CHIP RES 10K OHM 5%
0402
R516 0613952R01 CER CHIP RES 10K OHM 5%
0402
R517 0613952R01 CER CHIP RES 10K OHM 5%
0402
R518 0613952R01 CER CHIP RES 10K OHM 5%
0402
R519 0613952R17 CER CHIP RES 47K OHM 5%
0402
R520 0613952R37 CER CHIP RES 330K OHM 5%
0402
R521 NOT PLACED –
R522 0613952R17 CER CHIP RES 47K OHM 5%
0402
R523 0613952R17 CER CHIP RES 47K OHM 5%
0402
R524 0613952G67 CER CHIP RES 0.0 +/-0.050
OHM
R525 0613952R01 CER CHIP RES 10K OHM 5%
0402
R526 0613952R01 CER CHIP RES 10K OHM 5%
0402
R527 NOT PLACED –
R528 0613952G67 CER CHIP RES 0.0 +/-0.050
OHM
R608 0613952Q49 CER CHIP RES 100 OHM
5 0402
R610 NOT PLACED –
R611 0613952Q49 CER CHIP RES 100 OHM
5 0402
R613 0613952R08 CER CHIP RES 20K OHM
5 0402
R614 0613952R08 CER CHIP RES 20K OHM
5 0402
R615 0613952R25 CER CHIP RES 100K OHM 5%
0402
R616 0613952Q49 CER CHIP RES 100 OHM
5 0402
R617 NOT PLACED –
R620 0613952Q49 CER CHIP RES 100 OHM
5 0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
