Motorola ATS 3000 User Manual

9.4-28 700/800 MHz Schematics, Board Overlays, and Parts Lists
February 14, 2012 6816985H01-F
L107 2414017G19 100NH
L108 2414017G18 82NH
L109 2460591B22 COIL AIR WOUND INDUC 8.67
L110 2414017G05 6.8NH
L111 2414017G18 82NH
L112 2414017G12 27NH
L113 2415428H03 AIR WOUND INDUCTOR
L114 2460591A11 COIL AIR WOUND INDUC 7.66
L200 2414017Q20 2.2UH
L201 2414017Q20 2.2UH
L203 2414017Q47 1UH
L204 2414032F21 6.8NH
L205 2414017Q20 2.2UH
L210 2414032F36 150NH
L211 2414032F36 150NH
L212 2414032F36 150NH
L214 2414032F36 150NH
L215 2414032F36 150NH
L216 2414032F36 150NH
L217 2414032F36 150NH
L218 2414032F36 150NH
L219 2414032F36 150NH
L220 2414032F26 22NH
L221 2414032F24 15NH
L230 2414032F25 18NH
L290 2414017Q47 1UH
L299 NOT PLACED –
L401 2414032D17 150NH
L402 2466505A01 COIL INDUCTOR
L403 2466505A01 COIL INDUCTOR
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
L405 2414032B76 4700 NH
L406 2414032F73 820NH
L407 2414032F73 820NH
L500 2414017Q42 390NH
L503 2489669V01 100UH
L511 2489669V01 100UH
L651 2414032F75 270NH
L652 2414032F75 270NH
L701 2486085A01 COIL, POWER INDUCTOR
L702 2486085A01 COIL, POWER INDUCTOR
L703 2464675H01 560NH
L704 2464675H01 560NH
L705 2464675H01 560NH
L708 2416307H01 680NH
L710 2416307H01 680NH
M101 3916333H01 GROUND CONTACT
M701 0985888K02 SKT RTC BTTY LEAP
PCB 8416095H01
STINGRAY RUGGED 7/800
MHZ
Q1 4805585Q19 TRANSISTOR
Q101 4816698H01
MOD,XSTR,FET RF PWR,950
MHZ
Q210 4813972A15
PB-FREE,NOT COMPLETELY
ENRICHED
Q211 4885061Y01 XSTR
Q212 4813972A15 XSTR
Q213 4885061Y01 XSTR
Q214 4813972A15 XSTR
Q215 4885061Y01 XSTR
Q216 4885061Y01 XSTR
Q217 4813972A15 XSTR
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
Q218 4813972A15 XSTR
Q401 4805585Q28
TRANSISTOR RF NPN 8GHZ
NOPB
Q501 4805921T28 XSTR, DUAL NOPB
Q698 4813973A81 XSTR
Q700 4813970A62 XSTR
Q701 4813973M07 XSTR
Q702 5185956E76
IC,CONV,SM,SO16,0-30
VINPUT RANGE,6.5A,3.8V
Q703 4813970A62
XSTR,FET GP PWR,MOSFET,
P-CH,ENHN,CF,-20V,1.3W
Q704 NOT PLACED –
Q705 NOT PLACED –
Q706 NOT PLACED –
Q709 4885061Y01 XSTR
Q801 4813973A42 XSTR
Q804 4813973A81 XSTR
R1 0613952Q66 510 OHM
R2 0613952Q93 6800 OHM 5% 0402
R3 0613952Q89 4700 OHM 5 0402
R4 0613952Q83 2700 OHM 5% 0402
R5 0613952Q58 240 OHM 5% 0402
R7 0613952Q39 33.0 OHM 5% 0402
R10 0613952R66 0.0 +/-0.050 OHM
R11 0613952Q37 33.0 OHM 5% 0402
R20 NOT PLACED –
R30 0613952R66 0.0 0.050 OHM
R40 0613952G67 0.0 0.050 OHM
R100 0613952H53 150 OHM 5% 0603
R101 0613952H42 51.0 OHM 5% 0603
R103 0613952H53 150 OHM 5% 0603
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R104 0613952Z22 220 1% 1/16W
R105 0613952H42 51.0 OHM 5% 0603
R106 0613952H53 150 OHM 5% 0603
R107 0613952H63 390 OHM 5% 0603
R108 0613952R04 15K OHM 5% 0402
R109 0613952Q80 2000 OHM 5% 0402
R110 0613952R15 39K OHM 5% 0402
R111 NOT PLACED –
R113 NOT PLACED –
R114 0613952R66 0 5 20X40
R115 0613952Q93 6800 OHM 5% 0402
R117 0613952R25 100K OHM 5% 0402
R118 0613952R32 200K OHM 5% 0402
R119 0613952Q93 6800 5% 20X40
R120 0613952Q53 150 OHM 5% 0402
R121 0613952H73 1000 OHM 5% 0603
R200 0613952Q49 100 OHM 5 0402
R201 0613952Q53 150 OHM 5% 0402
R202 0613952Q53 150 OHM 5% 0402
R204 0613952R66 0.0 +/-0.050 OHM
R205 0613952Q87 3900 OHM 5% 0402
R206 0613952Q48 91.0 OHM 5% 0402
R207 0613952Q57 220 OHM 5% 0402
R208 0613952Q73 1000 OHM 5% 0402
R210 0613952Q73 1000 OHM 5% 0402
R211 0613952R66 0.0 0.050 OHM
R212 0613952Q37 33.0 OHM 5% 0402
R213 0613952R66 0.0 0.050 OHM
R214 0613952R08 20K OHM 5% 0402
R215 0613952R19 56K OHM 5% 0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
