Motorola ATS 3000 User Manual

700/800 MHz Schematics, Board Overlays, and Parts Lists 9.4-29
6816985H01-F February 14, 2012
R216 0613952R17 47K OHM 5% 0402
R217 0613952Q49 100 OHM 5 0402
R220 0613952Q61 330 OHM 5% 0402
R221 0613952R18 51K OHM 5% 0402
R222 0613952Q25 10.0 OHM 5% 0402
R223 0613952R08 20K OHM 5% 0402
R224 0613952R08 20K OHM 5% 0402
R225 0613952Q37 33.0 OHM 5% 0402
R226 0613952Q17 4.7 OHM 5% 0402
R227 0613952R18 51K OHM 5% 0402
R228 0613952Q55 180 OHM 5% 0402
R229 0613952R08 20K OHM 5% 0402
R230 0613952R08 20K OHM 5% 0402
R231 0613952Q31 18.0 OHM 5% 0402
R232 0613952R18 51K OHM 5% 0402
R233 0613952Q57 220 OHM 5% 0402
R234 0613952R08 20K OHM 5% 0402
R235 0613952R08 20K OHM 5% 0402
R236 0613952Q31 18.0 OHM 5% 0402
R237 0613952Q57 220 OHM 5% 0402
R238 0613952Q49 100 OHM 5 0402
R239 0613952R10 24K OHM 5 0402
R241 0613952R66 0.0 0.050 OHM
R243 0613952R12 30K OHM 5% 0402
R244 0613952R18 51K OHM 5% 0402
R250 0613952R66 0.0 0.050 OHM
R251 0613952R66 0.0 0.050 OHM
R252 0613952R66 0.0 0.050 OHM
R261 0613952R18 51K OHM 5% 0402
R262 0613952Q91 5600 OHM 5 0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R285 0613952Q80 2000 OHM 5% 0402
R286 0613952Q45
(PMLF4040A)
0613952K81
(PMLF4040B)
68.0 OHM 5% 0402
68.0 OHM 1% 0402
R289 0613952Q37 33.0 OHM 5% 0402
R290 0613952R13 33K OHM 5% 0402
R291 0613952R13 33K OHM 5% 0402
R292 0613952Q37 33.0 OHM 5% 0402
R293 0613952Q95 8200 OHM 5% 0402
R294 0613952R66 0.0 0.050 OHM
R295 0613952R17 47K OHM 5% 0402
R297 0613952R66 0.0 0.050 OHM
R298 NOT PLACED –
R299 NOT PLACED –
R401 0613952Q49 100 OHM 5 0402
R402 0613952R10 24K OHM 5 0402
R403 0613952Q94 7500 OHM 5% 0402
R404 0613952C81 681 OHM 1% 0603
R405 0613952Q80 2000 OHM 5% 0402
R406 0613952Q70 330 OHM 5% 0402
R407 0613952R10 24K OHM 5 0402
R408 0613952Q41 47.0 OHM 5% 0402
R409 0613952R25 100K OHM 5% 0402
R410 0613952R01 10K OHM 5% 0402
R411 0613952Q63 390 OHM 5% 0402
R412 0613952R01 10K OHM 5% 0402
R413 0613952R66 0.0 0.050 OHM
R414 0613952R25 100K OHM 5% 0402
R415 0613952R66 0.0 0.050 OHM
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R416 NOT PLACED –
R503 0613952Q63 390 OHM 5% 0402
R504 0613952Q66 510 OHM 5% 0402
R505 0613952Q93 6800 OHM
R507 0613952Q49 100 OHM 5 0402
R508 0613952Q49 100 OHM 5 0402
R509 0613952Q49 100 OHM 5 0402
R510 0613952Q49 100 OHM 5 0402
R511 0613952R01 10K OHM 5% 0402
R512 0613952R17 47K OHM 5% 0402
R520 0613952R37 330K OHM 5% 0402
R530 0613952R01 10K OHM 5% 0402
R531 0613952R01 10K OHM 5% 0402
R532 0613952R01 10K OHM 5% 0402
R533 0613952R01 10K OHM 5% 0402
R534 0613952R01 10K OHM 5% 0402
R535 0613952R01 10K OHM 5% 0402
R536 0613952R01 10K OHM 5% 0402
R537 0613952R01 10K OHM 5% 0402
R540 NOT PLACED –
R545 0613952R17 47K OHM 5% 0402
R546 0613952R17 47K OHM 5% 0402
R547 0613952R17 47K OHM 5% 0402
R594 NOT PLACED ART NUMBER
R595 0613952R66 0.0 0.050 OHM
R608 0613952Q49 100 OHM 5 0402
R610 NOT PLACED –
R611 0613952Q49 100 OHM 5 0402
R613 0613952R08 20K OHM 5% 0402
R614 0613952R08 20K OHM 5% 0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R615 0613952R25 100K OHM 5% 0402
R616 0613952Q49 100 OHM 5 0402
R617 NOT PLACED –
R620 0613952Q49 100 OHM 5 0402
R621 0613952Q49 100 OHM 5 0402
R622 0613952Q49 100 OHM 5 0402
R625 0613952Q49 100 OHM 5 0402
R626 0613952Q49 100 OHM 5 0402
R633 NOT PLACED –
R634 0613952R66 0.0 0.050 OHM
R635 NOT PLACED –
R636 0613952R01 10K OHM 5% 0402
R637 0613952Q73 1000 OHM 5% 0402
R638 0613952Q73 1000 OHM 5% 0402
R639 0613952Q73 1000 OHM 5% 0402
R640 0613952Q73 1000 OHM 5% 0402
R641 0613952Q73 1000 OHM 5% 0402
R642 0613952Q73 1000 OHM 5% 0402
R643 0613952Q73 1000 OHM 5% 0402
R644 0613952Q73 1000 OHM 5% 0402
R647 0613952R01 10K OHM 5% 0402
R649 0613952R17 47K OHM 5% 0402
R654 0613952R01 10K OHM 5% 0402
R656 0613952R01 10K OHM 5% 0402
R658 0613952P18 150K OHM 1% 0402
R666 0613952Q42 51.0 OHM 5% 0402
R667 0613952Q63 390 OHM 5% 0402
R668 0613952Q45 68.0 OHM 5 0402
R669 0613952Q49 100 OHM 5 0402
R670 0613952Q49 100 OHM 5 0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
