9.4-30 700/800 MHz Schematics, Board Overlays, and Parts Lists
February 14, 2012 6816985H01-F
R671 0613952Q63 390 OHM 5% 0402
R672 0613952R01 10K OHM 5% 0402
R673 0613952R01 10K OHM 5% 0402
R674 0613952Q49 100 OHM 5 0402
R675 0613952Q67 560 OHM 5% 0402
R677 0613952R01 10K OHM 5% 0402
R678 0613952Q49 100 OHM 5 0402
R697 0613952Q49 100 OHM 5 0402
R700 0613952Q80 2000 OHM 5% 0402
R701 0613952R17 47K OHM 5% 0402
R702 0613952R66 0.0 0.050 OHM
R703 0613952R17 47K OHM 5% 0402
R704 0613952Q49 100 OHM 5 0402
R705 0613952R17 47K OHM 5% 0402
R708 0613952R19 56K OHM 5% 0402
R709 0613952H17 4.7OHM 5%
R710 0688044N04 .1 OHM 1% 2X1.27MM
R711 0613952G67 0.0 0.050 OHM
R712 0613952Q49 100 OHM 5 0402
R714 0688044N04 .1 OHM 1% 2X1.27MM
R717 0613952R66 0.0 0.050 OHM
R718 0613952G67 0.0 0.050 OHM
R722 0613952R08 20K OHM 5% 0402
R725 0613952R66 0.0 0.050 OHM
R726 0613952R66 0.0 0.050 OHM
R729 0613952R13 33K OHM 5% 0402
R740 0613952Q63 390 OHM 5% 0402
R741 0613952R17 47K OHM 5% 0402
R742 0613952R17 47K OHM 5% 0402
R743 NOT PLACED –
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R744 NOT PLACED –
R745 0613952R56 2.0M OHM 5 0402
R746 0613952R56 2.0M OHM 5 0402
R747 0613952Q73 1000 OHM 5% 0402
R748 0613952R41 470K OHM 5% 0402
R749 0613952R41 470K OHM 5% 0402
R750 0613952Q63 390 OHM 5% 0402
R751 0613952Q63 390 OHM 5% 0402
R752 0613952Q81 2200 OHM 5% 0402
R753 0613952Q81 2200 OHM 5% 0402
R756 0613952R66 0.0 0.050 OHM
R757 0613952R08 20K OHM 5% 0402
R758 0613952R19 56K OHM 5% 0402
R759 0613952R01 10K OHM 5% 0402
R760 0613952Q93 6800 OHM 5% 0402
R763 NOT PLACED –
R764 NOT PLACED –
R765 NOT PLACED –
R767 0613952R66 0.0 0.050 OHM
R768 NOT PLACED –
R771 NOT PLACED –
R772 0613952Q49 100 OHM 5 0402
R773 0613952Q49 100 OHM 5 0402
R774 0613952Q49 100 OHM 5 0402
R775 0613952Q49 100 OHM 5 0402
R776 NOT PLACED –
R777 0613952R01 10K OHM 5% 0402
R778 0613952R01 10K OHM 5% 0402
R779 0613952R01 10K OHM 5% 0402
R780 0613952Q89 4700 OHM 5 0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R781 0613952R01 10K OHM 5% 0402
R782 0613952R01 10K OHM 5% 0402
R783 0613952R01 10K OHM 5% 0402
R784 NOT PLACED –
R785 0613952Q49 100 OHM 5 0402
R786 0613952R17 47K OHM 5% 0402
R790 0613952R19 56K OHM 5% 0402
R791 0613952R66 0.0 0.050 OHM
R792 0613952R66 0.0 0.050 OHM
R793 0613952R66 0.0 0.050 OHM
R794 0613952R66 0.0 0.050 OHM
R795 0613952R17 47K OHM 5% 0402
R796 0613952R66 0.0 0.050 OHM
R797 0613952Q41 47.0 OHM 5% 0402
R798 0613952Q61 330 OHM 5% 0402
R799 0613952R01 10K OHM 5% 0402
R801 NOT PLACED –
R802 0613952Q49 100 OHM 5 0402
R803 0613952Q49 100 OHM 5 0402
R804 0613952Q66 510 OHM 5% 0402
R805 0613952R01 10K OHM 5% 0402
R806 0613952Q66 510 OHM 5% 0402
R807 0613952R01 10K OHM 5% 0402
R808 0613952R66 0.0 0.050 OHM
R809 0613952R17 47K OHM 5% 0402
R810 0613952R01 10K OHM 5% 0402
R811 0613952Q66 510 OHM 5% 0402
R812 0613952R25 100K OHM 5% 0402
R813 0613952R66 0.0 0.050 OHM
R814 NOT PLACED –
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R815 0613952R66 0.0 0.050 OHM
R816 0613952R17 47K OHM 5% 0402
R820 0613952R01 10K OHM 5% 0402
R829 NOT PLACED –
R837 0613952Q37 33.0 OHM 5% 0402
R838 0613952Q37 33.0 OHM 5% 0402
R839 0613952R01 10K OHM 5% 0402
R840 0613952Q66 510 OHM 5% 0402
R841 0613952R01 10K OHM 5% 0402
R842 0613952R01 10K OHM 5% 0402
R843 0613952R41 470K OHM 5% 0402
R844 0613952Q61 330 OHM 5% 0402
S500 4085131E03
SWITCH FREQ DUAL
FUNCTION
S501 1880619Z06 VOL POTENTIOMETER
S502 4016618H01 SWITCH SURFACE MOUNT
S503 4070354A01 LIGHT TOUCH SWITCH-SMD
S504 4070354A01 LIGHT TOUCH SWITCH-SMD
S505 4070354A01 LIGHT TOUCH SWITCH-SMD
S506 4070354A01 LIGHT TOUCH SWITCH-SMD
SH001 2616071H01 SHIELD MIXER
SH002 2616550H01 SHLD FITLER
SH101 2616559H01 SHLD PCIC
SH102 2616557H01 SHLD HARMONIC BOT
SH103 2616558H01 SHLD HARMONIC TOP
SH104 2616555H01 SHLD PA
SH201 2616560H01 SHLD SYN
SH202 2616556H01 SHLD FRAN N
SH203 2616553H01 SHLD VCO BOT
SH204 2616551H01 SHLD DAC
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
