Motorola ATS 3000

700/800 MHz Schematics, Board Overlays, and Parts Lists 9.4-37
6816985H01-F February 14, 2012
R285 0613952Q80 2000 OHM 5% 0402
R286 0613952K81
CER CHIP RES 68.1 OHM 1%
0402
R289 0613952Q37 33.0 OHM 5% 0402
R290 0613952R13 33K OHM 5% 0402
R291 0613952R13 33K OHM 5% 0402
R292 0613952Q37 33.0 OHM 5% 0402
R293 0613952Q95 8200 OHM 5% 0402
R294 0613952R66 0.0 0.050 OHM
R295 0613952R17 47K OHM 5% 0402
R297 0613952R66 0.0 0.050 OHM
R298 NOT PLACED –
R299 NOT PLACED –
R401 0613952Q49 100 OHM 5 0402
R402 0613952R10 24K OHM 5 0402
R403 0613952Q94 7500 OHM 5% 0402
R404 0613952C81 681 OHM 1% 0603
R405 0613952Q80 2000 OHM 5% 0402
R406 0613952Q70 330 OHM 5% 0402
R407 0613952R10 24K OHM 5 0402
R408 0613952Q41 47.0 OHM 5% 0402
R409 0613952R25 100K OHM 5% 0402
R410 0613952R01 10K OHM 5% 0402
R411 0613952Q63 390 OHM 5% 0402
R412 0613952R01 10K OHM 5% 0402
R413 0613952R66 0.0 0.050 OHM
R414 0613952R25 100K OHM 5% 0402
R415 0613952R66 0.0 0.050 OHM
R416 NOT PLACED –
R503 0613952Q63 390 OHM 5% 0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R504 0613952Q66 510 OHM 5% 0402
R505 0613952Q93 6800 OHM
R507 0613952Q49 100 OHM 5 0402
R508 0613952Q49 100 OHM 5 0402
R509 0613952Q49 100 OHM 5 0402
R510 0613952Q49 100 OHM 5 0402
R511 0613952R01 10K OHM 5% 0402
R512 0613952R17 47K OHM 5% 0402
R520 0613952R37 330K OHM 5% 0402
R530 0613952R01 10K OHM 5% 0402
R531 0613952R01 10K OHM 5% 0402
R532 0613952R01 10K OHM 5% 0402
R533 0613952R01 10K OHM 5% 0402
R534 0613952R01 10K OHM 5% 0402
R535 0613952R01 10K OHM 5% 0402
R536 0613952R01 10K OHM 5% 0402
R537 0613952R01 10K OHM 5% 0402
R540 NOT PLACED –
R545 0613952R17 47K OHM 5% 0402
R546 0613952R17 47K OHM 5% 0402
R547 0613952R17 47K OHM 5% 0402
R594 NOT PLACED ART NUMBER
R595 0613952R66 0.0 0.050 OHM
R608 0613952Q49 100 OHM 5 0402
R610 NOT PLACED –
R611 0613952Q49 100 OHM 5 0402
R613 0613952R08 20K OHM 5% 0402
R614 0613952R08 20K OHM 5% 0402
R615 0613952R25 100K OHM 5% 0402
R616 0613952Q49 100 OHM 5 0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R617 NOT PLACED –
R620 0613952Q49 100 OHM 5 0402
R621 0613952Q49 100 OHM 5 0402
R622 0613952Q49 100 OHM 5 0402
R625 0613952Q49 100 OHM 5 0402
R626 0613952Q49 100 OHM 5 0402
R633 NOT PLACED –
R634 0613952R66 0.0 0.050 OHM
R635 NOT PLACED –
R636 0613952R01 10K OHM 5% 0402
R637 0613952Q73 1000 OHM 5% 0402
R638 0613952Q73 1000 OHM 5% 0402
R639 0613952Q73 1000 OHM 5% 0402
R640 0613952Q73 1000 OHM 5% 0402
R641 0613952Q73 1000 OHM 5% 0402
R642 0613952Q73 1000 OHM 5% 0402
R643 0613952Q73 1000 OHM 5% 0402
R644 0613952Q73 1000 OHM 5% 0402
R647 0613952R01 10K OHM 5% 0402
R649 0613952R17 47K OHM 5% 0402
R654 0613952R01 10K OHM 5% 0402
R656 0613952R01 10K OHM 5% 0402
R658 0613952P18 150K OHM 1% 0402
R666 0613952Q42 51.0 OHM 5% 0402
R667 0613952Q63 390 OHM 5% 0402
R668 0613952Q45 68.0 OHM 5 0402
R669 0613952Q49 100 OHM 5 0402
R670 0613952Q49 100 OHM 5 0402
R671 0613952Q63 390 OHM 5% 0402
R672 0613952R01 10K OHM 5% 0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R673 0613952R01 10K OHM 5% 0402
R674 0613952Q49 100 OHM 5 0402
R675 0613952Q67 560 OHM 5% 0402
R677 0613952R01 10K OHM 5% 0402
R678 0613952Q49 100 OHM 5 0402
R697 0613952Q49 100 OHM 5 0402
R700 0613952Q80 2000 OHM 5% 0402
R701 0613952R17 47K OHM 5% 0402
R702 0613952R66 0.0 0.050 OHM
R703 0613952R17 47K OHM 5% 0402
R704 0613952Q49 100 OHM 5 0402
R705 0613952R17 47K OHM 5% 0402
R708 0613952R19 56K OHM 5% 0402
R709 0613952H17 4.7OHM 5%
R710 0688044N04 .1 OHM 1% 2X1.27MM
R711 0613952G67 0.0 0.050 OHM
R712 0613952Q49 100 OHM 5 0402
R714 0688044N04 .1 OHM 1% 2X1.27MM
R717 0613952R66 0.0 0.050 OHM
R718 0613952G67 0.0 0.050 OHM
R722 0613952R08 20K OHM 5% 0402
R725 0613952R66 0.0 0.050 OHM
R726 0613952R66 0.0 0.050 OHM
R729 0613952R13 33K OHM 5% 0402
R740 0613952Q63 390 OHM 5% 0402
R741 0613952R17 47K OHM 5% 0402
R742 0613952R17 47K OHM 5% 0402
R743 NOT PLACED –
R744 NOT PLACED –
R745 0613952R56 2.0M OHM 5 0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
