Motorola ATS 3000

9.4-38 700/800 MHz Schematics, Board Overlays, and Parts Lists
February 14, 2012 6816985H01-F
R746 0613952R56 2.0M OHM 5 0402
R747 0613952Q73 1000 OHM 5% 0402
R748 0613952R41 470K OHM 5% 0402
R749 0613952R41 470K OHM 5% 0402
R750 0613952Q63 390 OHM 5% 0402
R751 0613952Q63 390 OHM 5% 0402
R752 0613952Q81 2200 OHM 5% 0402
R753 0613952Q81 2200 OHM 5% 0402
R756 0613952R66 0.0 0.050 OHM
R757 0613952R08 20K OHM 5% 0402
R758 0613952R19 56K OHM 5% 0402
R759 0613952R01 10K OHM 5% 0402
R760 0613952Q93 6800 OHM 5% 0402
R763 NOT PLACED –
R764 NOT PLACED –
R765 NOT PLACED –
R767 0613952R66 0.0 0.050 OHM
R768 NOT PLACED –
R771 NOT PLACED –
R772 0613952Q49 100 OHM 5 0402
R773 0613952Q49 100 OHM 5 0402
R774 0613952Q49 100 OHM 5 0402
R775 0613952Q49 100 OHM 5 0402
R776 NOT PLACED –
R777 0613952R01 10K OHM 5% 0402
R778 0613952R01 10K OHM 5% 0402
R779 0613952R01 10K OHM 5% 0402
R780 0613952Q89 4700 OHM 5 0402
R781 0613952R01 10K OHM 5% 0402
R782 0613952R01 10K OHM 5% 0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R783 0613952R01 10K OHM 5% 0402
R784 NOT PLACED –
R785 0613952Q49 100 OHM 5 0402
R786 0613952R17 47K OHM 5% 0402
R790 0613952R19 56K OHM 5% 0402
R791 0613952R66 0.0 0.050 OHM
R792 0613952R66 0.0 0.050 OHM
R793 0613952R66 0.0 0.050 OHM
R794 0613952R66 0.0 0.050 OHM
R795 0613952R17 47K OHM 5% 0402
R796 0613952R66 0.0 0.050 OHM
R797 0613952Q41 47.0 OHM 5% 0402
R798 0613952Q61 330 OHM 5% 0402
R799 0613952R01 10K OHM 5% 0402
R801 NOT PLACED –
R802 0613952Q49 100 OHM 5 0402
R803 0613952Q49 100 OHM 5 0402
R804 0613952Q66 510 OHM 5% 0402
R805 0613952R01 10K OHM 5% 0402
R806 0613952Q66 510 OHM 5% 0402
R807 0613952R01 10K OHM 5% 0402
R808 0613952R66 0.0 0.050 OHM
R809 0613952R17 47K OHM 5% 0402
R810 0613952R01 10K OHM 5% 0402
R811 0613952Q66 510 OHM 5% 0402
R812 0613952R25 100K OHM 5% 0402
R813 0613952R66 0.0 0.050 OHM
R814 NOT PLACED –
R815 0613952R66 0.0 0.050 OHM
R816 0613952R17 47K OHM 5% 0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R820 0613952R01 10K OHM 5% 0402
R829 NOT PLACED –
R837 0613952Q37 33.0 OHM 5% 0402
R838 0613952Q37 33.0 OHM 5% 0402
R839 0613952R01 10K OHM 5% 0402
R840 0613952Q66 510 OHM 5% 0402
R841 0613952R01 10K OHM 5% 0402
R842 0613952R01 10K OHM 5% 0402
R843 0613952R41 470K OHM 5% 0402
R844 0613952Q61 330 OHM 5% 0402
S500 4085131E03
SWITCH FREQ DUAL
FUNCTION
S501 1880619Z06 VOL POTENTIOMETER
S502 4016882H01
TACTILE SWITCH
EMERGENCY
S503 4070354A01 LIGHT TOUCH SWITCH-SMD
S504 4070354A01 LIGHT TOUCH SWITCH-SMD
S505 4070354A01 LIGHT TOUCH SWITCH-SMD
S506 4070354A01 LIGHT TOUCH SWITCH-SMD
SH001 2616071H01 SHIELD MIXER
SH002 2616550H01 SHLD FITLER
SH101 2616559H01 SHLD PCIC
SH102 2616557H01 SHLD HARMONIC BOT
SH103 2616558H01 SHLD HARMONIC TOP
SH104 2616555H01 SHLD PA
SH201 2616560H01 SHLD SYN
SH202 2616556H01 SHLD FRAN N
SH203 2616553H01 SHLD VCO BOT
SH204 2616551H01 SHLD DAC
SH205 2616554H01 SHLD VCO TOP
SH401 2616552H01 SHLD ABACUS
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
SH402 2616518H01 SHLD 2ND LO FLTR
T1 2516148H01 XMFR MIXER 5:1
T2 2516372H01
TRANSFORMER, BALUN,
MIXER, 25:1
U1 5164015H81
IC,MXR,DBL BAL GILBERT,
CELL,SM
U2 5185941F45
ATTEN,VAR,14.4DBMIN,15.6D
BMAX
U3 5116349H01 IC INVERTER DUAL SC70
U101 51012101001
VHF/UHF/800/900 MHZ
LDMOS DRIVER IC
U102 5185765B26 IC PWR CTRL IN MOS20
U103 5115022H01
IC,TEMP SENS,LM50C,SM,
SOT-23
U106 5185368C84
DIRECTIONAL CPLR 7/
800MHZ
U201 5116245H01 CC LVFRACN
U202 5185941F40 IC, 12 BIT DAC
U205 5116411H01 IC,OP AMP,
U250 5171121L01
CUSTOM LOW VOLTAGE VCO
BUFFER IC
U401 5185963A85 IC-ABACUS III-LP
U500 5188493T01 IC,VREG/SWG,LP2989,SM
U501 5185941F35 IC, VREG, NOPB
U502 5185941F35 IC, VREG, NOPB
U601 5185941F22
IC,OPAMP,SGL,OPA237
SOT23, NOPB
U602 5185941F22
IC,OPAMP,SGL,OPA237,
SOT23, NOPB
U701 5185143E77
IC, MAKO ASIC, CMOS PWR
MGMT
U702 5185941F22
IC,OPAMP,SGL,OPA237,
SOT23 ,NOPB
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
