Motorola ATS 3000 User Manual

700/800 MHz Schematics, Board Overlays, and Parts Lists 9.4-39
6816985H01-F February 14, 2012
Notes:
1. For optimum performance, order replacement diodes, transistors, and circuit
modules by Motorola part number only.
2. When ordering crystals, specify carrier frequency, crystal frequency, crystal
type number, and Motorola part number.
3. Part value notations:
p=10
-12
n=10
-9
µ=10
-6
m=10
-3
k=10
3
M=10
6
4. ITEM refers to the component reference designator. SIDE refers to the
location of the component on the board; S1=Side 1, S2=Side 2.
PMLF4040F Main Circuit Board
Electrical Parts List
U705 5114000B39
IC,BFR,1PER PKG,SM,
SOT-353, PB-FREE
U712 5188691V01
IC,ANLG
SW,NC7SB3157P6X,SM,
SC70-6,
U713 5115453H01
RAIL TO RAIL OUTPUT, 8 PIN
BGA
U714 5115453H01
RAIL TO RAIL OUTPUT, 8 PIN
BGA
U800 5185941F04
IC, PATRIOT BRAVO, 1.2.2,
256BGA, PB-FREE
U801 5114000B39
IC,BFR,1PER PKG,SM,
SOT-353, PB-FREE
U802 5114000B39
IC,BFR,1PER PKG,SM,
SOT-353, PB-FREE
U803 51012093001 64MB,60NS,SM,1.8V,90NM
U804 5171897M01
IC,SRAM,,8M,512KX16,55NS,S
M,FBGA48
VR500 4809788E21 ZENER DIODE
VR501 4813977M19 ZENER DIODE
VR502 4809788E21 ZENER DIODE
VR503 4809788E21 ZENER DIODE
VR504 4809788E21 ZENER DIODE
VR505 4809788E21 ZENER DIODE
VR506 4809788E21 ZENER DIODE
VR507 4809788E21 ZENER DIODE
VR591 4813977A43 DIODE
VR592 4813977A43 DIODE
VR593 4813977A43 DIODE
VR594 4813977A43 DIODE
VR595 4813977A43 DIODE
VR596 4813977A43 DIODE
VR650 4813979P12 DIODE
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
VR651 4813977A43 DIODE
VR652 4813977A43 DIODE
VR657 4809788E21 DIODE
VR658 4813977C23 DIODE
VR659 4813979P10 DIODE
VR662 4813979P10 DIODE
VR663 4813977M18 DIODE
VR678 4866544A01 DIODE
VR701 4813977M11 DIODE
Y200 9375432M01 REF OSC 16.8 MHZ 1.5 PPM
Y201 4805911Z23 CER RESONATOR 960 MHZ
Y202 4805911Z25 CER RESONATOR 1025 MHZ
Y203 4805911Z24 CER RESONATOR 1110 MHZ
Y701 4809995L05
XTAL QUARTZ 32.768KHZ
CC4V-T1
Y702 4864005H01
RESONATOR, CRYSTAL
24.576 MHZ
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
B500 0986237A02
CONNECTOR (CONTACT
BATTERY)
C1 2113944A30 CAP CER CHP 27.0PF 50V 5%
C2 2113944A32 CAP CER CHP 39.0PF 50V 5%
C3 NOT PLACED –
C4 2113944A42
CAP CER CHP 150.0PF 50V
5%
C5 2113944A21
CAP CER CHP 6.8PF 50V +/-
0.5PF
C6 2113946F03 CAP CER CHP 4.7UF 6.3V 10%
C7 2113944A32 CAP CER CHP 39.0PF 50V 5%
C8 2113944A32 CAP CER CHP 39.0PF 50V 5%
C9 2113944A32 CAP CER CHP 39.0PF 50V 5%
C11 2113945B05
CAP,FXD,.033UF,+10%,-10%,
25V-DC,0402,X7R,-55DEG
CMIN,125DEG CMA
C12 2113944A32 CAP CER CHP 39.0PF 50V 5%
C13 2113944A32 CAP CER CHP 39.0PF 50V 5%
C14 NOT PLACED –
C15 2113944A32 CAP CER CHP 39.0PF 50V 5%
C16 2113944A33 CAP CER CHP 47.0PF 50V 5%
C17 2113944A08
CAP CER CHP 2.0PF 50V +/-
0.25PF
C18 2113944A01
CAP CER CHP 1.1PF 50V +/-
0.25PF
C19 2113944C67
CAP,FXD,1.5PF,.1PF+/-,50V-
DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C20 2113944A09
CAP CER CHP 2.2PF 50V +/-
0.25PF
C22 2113944A32 CAP CER CHP 39.0PF 50V 5%
C23 2113945B05
CAP,FXD,.033UF,+10%,-10%,
25V-DC,0402,X7R,-55DEG
CMIN,125DEG CMA
C25 2113945B05
CAP,FXD,.033UF,+10%,-10%,
25V-DC,0402,X7R,-55DEG
CMIN,125DEG CMA
C26 2113944A32 CAP CER CHP 39.0PF 50V 5%
C27 2113945B05
CAP,FXD,.033UF,+10%,-10%,
25V-DC,0402,X7R,-55DEG
CMIN,125DEG CMA
C28 2113946F03 CAP CER CHP 4.7UF 6.3V 10%
C29 2113944A36 CAP CER CHP 68.0PF 50V 5%
C31 2113945B05
CAP,FXD,.033UF,+10%,-10%,
25V-DC,0402,X7R,-55DEG
CMIN,125DEG CMA
C33 2113946F03 CAP CER CHP 4.7UF 6.3V 10%
C35 2113944A33 CAP CER CHP 47.0PF 50V 5%
C36 2113944A70
CAP,FXD,6PF,.5PF+/-,50V-DC,
0402,C0G,-55DEG
CMIN,125DEG CMAX,PB
C37 2113944A32 CAP CER CHP 39.0PF 50V 5%
C101 2113944C37 CAP CER CHP 39.0PF 50V 5%
C103 2113944C61
CAP,FXD,.5PF,.1PF+/-,50V-
DC,0603,C0G,-55DEG CMIN,
125DEG CMAX,P
C104 2113944C67
CAP,FXD,1.5PF,.1PF+/-,50V-
DC,0603,C0G,-55DEG CMIN,
125DEG CMAX
C105 2113944C13
CAP CER CHP 2.0PF 50V +/-
0.25PF
C106 2113944C13
CAP CER CHP 2.0PF 50V +/-
0.25PF
C107 2113944C63
CAP,FXD,1PF,.1PF+/-,50V-DC,
0603,C0G,-55DEG CMIN,
125DEG CMAX,PB
C108 2113944C67
CAP,FXD,1.5PF,.1PF+/-,50V-
DC,0603,C0G,-55DEG CMIN,
125DEG CMAX
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
