Motorola ATS 3000 User Manual

9.4-40 700/800 MHz Schematics, Board Overlays, and Parts Lists
February 14, 2012 6816985H01-F
C109 NOT PLACED –
C110 2113944A32 CAP CER CHP 39.0PF 50V 5%
C111 2113944C37 CAP CER CHP 39.0PF 50V 5%
C116 2113944C61
CAP,FXD,.5PF,.1PF+/-,50V-
DC,0603,C0G,-55DEG CMIN,
125DEG CMAX,P
C117 2113944C63
CAP,FXD,1PF,.1PF+/-,50V-DC,
0603,C0G,-55DEG CMIN,
125DEG CMAX,PB
C118 2113944A77
CAP,FXD,11PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX,PB
C119 2113946K02 CAP CER CHP 0.10UF 16V
C120 2113944C37 CAP CER CHP 39.0PF 50V 5%
C121 2113944M28
CAP,FXD,27PF,+2%,-2%,50V-
DC,0603,C0G,-55DEG CMIN,
125DEG CMAX,PB
C122 2113946K02 CAP CER CHP 0.10UF 16V
C123 2113944A32 CAP CER CHP 39.0PF 50V 5%
C125 2113945L49
CAP,FXD,.01UF,+5%,-5%,50V-
DC,0603,X7R,-55DEG CMIN,
125DEG CMAX,P
C127 2113951C14
CAP,FXD,1.5PF,.05PF+/-,
250V-DC,0603,C0G,-55DEG
CMIN,125DEG CMA
C128 2113951A38
CAP NPO 18.0PF +/-5% 250V
HI FREQ
C129 2113951A05
CAP NPO 0.50PF +/-.1PF 250V
HI FREQ
C130 2113946K02 CAP CER CHP 0.10UF 16V
C132 2113944A40
CAP CER CHP 100.0PF 50V
5%
C133 2113944A77
CAP,FXD,11PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX,PB
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C134 2113944M25
CAP,FXD,20PF,+2%,-2%,50V-
DC,0603,C0G,-55DEG CMIN,
125DEG CMAX,PB
C136 2113946K02 CAP CER CHP 0.10UF 16V
C137 2113944A32 CAP CER CHP 39.0PF 50V 5%
C139 2113946K02 CAP CER CHP 0.10UF 16V
C140 2113944C31 CAP CER CHP 12.0PF 50V 5%
C141 NOT PLACED –
C142 2113951A42
CAP NPO 27.0PF +/-5% 250V
HI FREQ
C144 2113944A32 CAP CER CHP 39.0PF 50V 5%
C145 2113945B02
CAP CER CHP 10,000PF 25V
10%
C146 2113944A32 CAP CER CHP 39.0PF 50V 5%
C147 2113946K02 CAP CER CHP 0.10UF 16V
C148 2113945B02
CAP CER CHP 10,000PF 25V
10%
C149 2113944A24
CAP CER CHP 9.1PF 50V +/-
0.5PF
C151 2113944A32 CAP CER CHP 39.0PF 50V 5%
C152 2113944A32 CAP CER CHP 39.0PF 50V 5%
C153 2113944A32 CAP CER CHP 39.0PF 50V 5%
C154 2113944A32 CAP CER CHP 39.0PF 50V 5%
C156 2113945A07 CAP CER CHP 680PF 50V 10%
C157 2113945A07 CAP CER CHP 680PF 50V 10%
C158 2113945B02
CAP CER CHP 10,000PF 25V
10%
C159 2113944A32 CAP CER CHP 39.0PF 50V 5%
C160 2113944A32 CAP CER CHP 39.0PF 50V 5%
C161 2113944A32 CAP CER CHP 39.0PF 50V 5%
C162 2113946K02 CAP CER CHP 0.10UF 16V
C163 2113944A32 CAP CER CHP 39.0PF 50V 5%
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C164 2113946K02 CAP CER CHP 0.10UF 16V
C165 2113944A32 CAP CER CHP 39.0PF 50V 5%
C166 2113946K02 CAP CER CHP 0.10UF 16V
C168 2313960C26
CAP,FXD,1UF,+10%,-10%,
35V-DC,SM,-55DEG CMIN,
125DEG CMAX,114MA,E
C169 2113944A77
CAP,FXD,11PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX,PB
C200 2113946K02 CAP CER CHP 0.10UF 16V
C201 2113946N03 CAP CER CHP 2.2UF 16V
C202 2113945B02
CAP CER CHP 10,000PF 25V
10%
C203 2113945B02
CAP CER CHP 10,000PF 25V
10%
C204 2113945B02
CAP CER CHP 10,000PF 25V
10%
C205 2113945B02
CAP CER CHP 10,000PF 25V
10%
C206 2113944A31 CAP CER CHP 33.0PF 50V 5%
C207 2313960D07
CAP,FXD,10UF,+10%,-10%,
16V-DC,SM,-55DEG CMIN,
125DEG CMAX,174MA
C208 2313960D07
CAP,FXD,10UF,+10%,-10%,
16V-DC,SM,-55DEG CMIN,
125DEG CMAX,174MA
C209 2113946K02 CAP CER CHP 0.10UF 16V
C210 2113945B02
CAP CER CHP 10,000PF 25V
10%
C211 NOT PLACED –
C212 2113946K02 CAP CER CHP 0.10UF 16V
C213 2113946K02 CAP CER CHP 0.10UF 16V
C214 2113946N03 CAP CER CHP 2.2UF 16V
C215 2113946K02 CAP CER CHP 0.10UF 16V
C216 2113944A31 CAP CER CHP 33.0PF 50V 5%
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C217 2113946N03 CAP CER CHP 2.2UF 16V
C218 2185419D06 CAP CER SUPER L/D 0.1UF
C219 2113946K02 CAP CER CHP 0.10UF 16V
C220 2113944A31 CAP CER CHP 33.0PF 50V 5%
C221 2185419D06 CAP CER SUPER L/D 0.1UF
C222 2113944A31 CAP CER CHP 33.0PF 50V 5%
C223 2113945A01 CAP CER CHP 220PF 50V 10,
C224 2113946K02 CAP CER CHP 0.10UF 16V
C225 2113946K02 CAP CER CHP 0.10UF 16V
C226 2113944A31 CAP CER CHP 33.0PF 50V 5%
C227 2113946K02 CAP CER CHP 0.10UF 16V
C228 2113945C27
CAP,FXD,.047UF,+10%,-10%,
50V-DC,0603,X7R,-55DEG
CMIN,125DEG CMA
C229 2113945C27
CAP,FXD,.047UF,+10%,-10%,
50V-DC,0603,X7R,-55DEG
CMIN,125DEG CMA
C230 2113946K02 CAP CER CHP 0.10UF 16V
C231 NOT PLACED –
C232 2113946N03 CAP CER CHP 2.2UF 16V
C233 2113946K02 CAP CER CHP 0.10UF 16V
C234 2113944A31 CAP CER CHP 33.0PF 50V 5%
C235 2113945L41
CAP,FXD,4700PF,+5%,-5%
,50V-DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C236 2113944A31 CAP CER CHP 33.0PF 50V 5%
C237 2113944A62
CAP,FXD,.75PF,.25PF+/-,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX
C238 2113944A31 CAP CER CHP 33.0PF 50V 5%
C239 2113945A09
CAP CER CHP 1000PF 50V
10%
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
