700/800 MHz Schematics, Board Overlays, and Parts Lists 9.4-41
6816985H01-F February 14, 2012
C240 2314030A94
CAP,FXD,10UF,+10%,-10%,
10V-DC,SM,-55DEG CMIN,
125DEG CMAX
C241 2113946K02 CAP CER CHP 0.10UF 16V
C242 2113944A31 CAP CER CHP 33.0PF 50V 5%
C243 2113945B02
CAP CER CHP 10,000PF 25V
10%
C244 2113944A31 CAP CER CHP 33.0PF 50V 5%
C245 2113944A31 CAP CER CHP 33.0PF 50V 5%
C246 2113946K02 CAP CER CHP 0.10UF 16V
C250 2113944A31 CAP CER CHP 33.0PF 50V 5%
C251 2113944A31 CAP CER CHP 33.0PF 50V 5%
C252 2113944M05
CAP,FXD,3PF,.1PF+/-,50V-DC,
0603,C0G,-55DEG CMIN,
125DEG CMAX,PB
C253 2113944A31 CAP CER CHP 33.0PF 50V 5%
C254 2113944M05
CAP,FXD,3PF,.1PF+/-,50V-DC,
0603,C0G,-55DEG CMIN,
125DEG CMAX,PB
C255 2113944V11
CAP,FXD,2.2PF,.1PF+/-,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX
C256 2113944A31 CAP CER CHP 33.0PF 50V 5%
C257 2188881Y17
CAPACITOR CERAMIC NPO
HIGH FREQUENCY 16 VOLT
(REPLACES 2104801Z17)
C258 2113944A31 CAP CER CHP 33.0PF 50V 5%
C259 2188881Y17
CAPACITOR CERAMIC NPO
HIGH FREQUENCY 16 VOLT
(REPLACES 2104801Z17)
C260 2113944M04
CAP,FXD,2.7PF,.1PF+/-,50V-
DC,0603,C0G,-55DEG CMIN,
125DEG CMAX
C261 2113944A31 CAP CER CHP 33.0PF 50V 5%
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C262 2113944V03
CAP,FXD,1PF,.1PF+/-,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX,PB
C263 2113944M04
CAP,FXD,2.7PF,.1PF+/-,50V-
DC,0603,C0G,-55DEG CMIN,
125DEG CMAX
C264 2113944V11
CAP,FXD,2.2PF,.1PF+/-,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX
C265 2188881Y12
CAPACITOR CERAMIC NPO
HIGH FREQUENCY 16 VOLT
(REPLACES 2104801Z12)
C266 2113944A31 CAP CER CHP 33.0PF 50V 5%
C267 2113944A31 CAP CER CHP 33.0PF 50V 5%
C268 2188881Y12
CAPACITOR CERAMIC NPO
HIGH FREQUENCY 16 VOLT
(REPLACES 2104801Z12)
C269 2113944M04
CAP,FXD,2.7PF,.1PF+/-,50V-
DC,0603,C0G,-55DEG CMIN,
125DEG CMAX
C270 2113944A01
CAP CER CHP 1.1PF 50V +/-
0.25PF
C271 2113944C69
CAP,FXD,1.8PF,.1PF+/-,50V-
DC,0603,C0G,-55DEG CMIN,
125DEG CMAX
C272 2113944V11
CAP,FXD,2.2PF,.1PF+/-,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX
C273 2188881Y12
CAPACITOR CERAMIC NPO
HIGH FREQUENCY 16 VOLT
(REPLACES 2104801Z12)
C274 2113944A31 CAP CER CHP 33.0PF 50V 5%
C275 2188881Y12
CAPACITOR CERAMIC NPO
HIGH FREQUENCY 16 VOLT
(REPLACES 2104801Z12)
C276 2113944A31 CAP CER CHP 33.0PF 50V 5%
C277 2113944A31 CAP CER CHP 33.0PF 50V 5%
C278 2113944A31 CAP CER CHP 33.0PF 50V 5%
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C279 2113944A15
CAP CER CHP 3.9PF 50V +/-
0.25PF
C280 2113944A10
CAP CER CHP 2.4PF 50V +/-
0.25PF
C281 2113944V03
CAP,FXD,1PF,.1PF+/-,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX,PB
C282 2113946K02 CAP CER CHP 0.10UF 16V
C283 2113946K02 CAP CER CHP 0.10UF 16V
C284 2113946K02 CAP CER CHP 0.10UF 16V
C285 2113946K02 CAP CER CHP 0.10UF 16V
C286 2113945A09
CAP CER CHP 1000PF 50V
10%
C289 2113946K02 CAP CER CHP 0.10UF 16V
C290 2113945A09
CAP CER CHP 1000PF 50V
10%
C291 2185419D06 CAP CER SUPER L/D 0.1UF
C292 2185419D06 CAP CER SUPER L/D 0.1UF
C293 2113944A40
CAP CER CHP 100.0PF 50V
5%
C295 2185419D06 CAP CER SUPER L/D 0.1UF
C296 2113944A31 CAP CER CHP 33.0PF 50V 5%
C297 2113944A31 CAP CER CHP 33.0PF 50V 5%
C298 2185419D06 CAP CER SUPER L/D 0.1UF
C401 2113955E37
CAP,FXD,10UF,+10%,-
10%,16V-DC,1210,X7R,-
55DEG CMIN,125DEG CMAX
C402 2113946K02 CAP CER CHP 0.10UF 16V
C403 2113946K02 CAP CER CHP 0.10UF 16V
C404 2113945C31
CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C405 2113944A79
CAP,FXD,16PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX,PB
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C406 2113944A79
CAP,FXD,16PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX,PB
C407 2113944A79
CAP,FXD,16PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX,PB
C408 2113945B02
CAP CER CHP 10,000PF 25V
10%
C409 2113945L49
CAP,FXD,.01UF,+5%,-5%,50V-
DC,0603,X7R,-55DEG CMIN,
125DEG CMAX,P
C410 2113944A32 CAP CER CHP 39.0PF 50V 5%
C411 2113945C31
CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C412 2113945C31
CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C413 2113945B02
CAP CER CHP 10,000PF 25V
10%
C414 2113945B02
CAP CER CHP 10,000PF 25V
10%
C415 2113945L37
CAP,FXD,3300PF,+5%,-5%,
50V-DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C416 2189705V01
CAP,CER,.1UF,+5%,-5%,50V-
DC,-55DEG CMIN,85DEG
CMAX,PB-FREE
C417 2113945C31
CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C418 2113944A32 CAP CER CHP 39.0PF 50V 5%
C419 NOT PLACED –
C420 NOT PLACED –
C421 2113945B02
CAP CER CHP 10,000PF 25V
10%
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
