Motorola ATS 3000 User Manual

9.4-42 700/800 MHz Schematics, Board Overlays, and Parts Lists
February 14, 2012 6816985H01-F
C422 2113945C31
CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C423 2113944C01
CAP CER CHP 180.0PF 50V
5%
C424 2113945C31
CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C425 2113945B02
CAP CER CHP 10,000PF 25V
10%
C426 2113944A40
CAP CER CHP 100.0PF 50V
5%
C427 2113944A40
CAP CER CHP 100.0PF 50V
5%
C428 2113945C31
CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C429 2113945A11
CAP CER CHP 2200PF 50V
10%
C431 2113945C31
CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C432 2113945C31
CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C433 2113945C31
CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C434 2113945B02
CAP CER CHP 10,000PF 25V
10%
C435 NOT PLACED –
C436 NOT PLACED –
C437 2113945B02
CAP CER CHP 10,000PF 25V
10%
C438 2113945B02
CAP CER CHP 10,000PF 25V
10%
C439 2113944A40
CAP CER CHP 100.0PF 50V
5%
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C440 2113944A40
CAP CER CHP 100.0PF 50V
5%
C441 2113945C31
CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C442 2113945C31
CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C443 2113944A85
CAP,FXD,51PF,+5%,-5%,50V-
DC,0402,C0G,-55DEG CMIN,
125DEG CMAX,PB
C444 2113945C31
CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C447 2113945C31
CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C448 2113945C31
CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C449 2113945B02
CAP CER CHP 10,000PF 25V
10%
C450 2113946G04
CAP,FXD,.68UF,+10%,-10%,
16V-DC,1206,X5R,-55DEG
CMIN,85DEG CMAX
C460 NOT PLACED –
C461 2113945B02
CAP CER CHP 10,000PF 25V
10%
C500 2113944A32 CAP CER CHP 39.0PF 50V 5%
C501 2113944A32 CAP CER CHP 39.0PF 50V 5%
C502 2113944A32 CAP CER CHP 39.0PF 50V 5%
C503 2113944A32 CAP CER CHP 39.0PF 50V 5%
C504 2113945A11
CAP CER CHP 2200PF 50V
10%
C505 2113945G98
CAP,FXD,.47UF,+10%,-10%,
50V-DC,0805,X7R,-55DEG
CMIN,125DEG CMAX
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C507 2113945B02
CAP CER CHP 10,000PF 25V
10%
C508 2113945B02
CAP CER CHP 10,000PF 25V
10%
C509 2113945B02
CAP CER CHP 10,000PF 25V
10%
C511 2113946F03 CAP CER CHP 4.7UF 6.3V 10%
C513 2113955E37
CAP,FXD,10UF,+10%,-10%,
16V-DC,1210,X7R,-55DEG
CMIN,125DEG CMAX
C514 2113955E37
CAP,FXD,10UF,+10%,-10%,
16V-DC,1210,X7R,-55DEG
CMIN,125DEG CMAX
C516 2113946F03 CAP CER CHP 4.7UF 6.3V 10%
C517 2113946F03 CAP CER CHP 4.7UF 6.3V 10%
C518 2113946F03 CAP CER CHP 4.7UF 6.3V 10%
C520 2113944A32 CAP CER CHP 39.0PF 50V 5%
C550 2113945B02
CAP CER CHP 10,000PF 25V
10%
C552 2113945A01 CAP CER CHP 220PF 50V 10,
C553 2113945B02
CAP CER CHP 10,000PF 25V
10%
C554 2113945A11
CAP CER CHP 2200PF 50V
10%
C555 2113945A01 CAP CER CHP 220PF 50V 10,
C560 2113945B02
CAP CER CHP 10,000PF 25V
10%
C561 2113945B02
CAP CER CHP 10,000PF 25V
10%
C566 2113945B02
CAP CER CHP 10,000PF 25V
10%
C567 NOT PLACED –
C590 NOT PLACED –
C591 NOT PLACED –
C592 NOT PLACED –
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C593 2113955E37
CAP,FXD,10UF,+10%,-10%,
16V-DC,1210,X7R,-55DEG
CMIN,125DEG CMAX
C598 NOT PLACED –
C599 NOT PLACED –
C607 2113946K02 CAP CER CHP 0.10UF 16V
C610 2113944A32 CAP CER CHP 39.0PF 50V 5%
C611 2113944A32 CAP CER CHP 39.0PF 50V 5%
C612 2113944A32 CAP CER CHP 39.0PF 50V 5%
C613 2113944A32 CAP CER CHP 39.0PF 50V 5%
C614 2113945A03 CAP CER CHP 330PF 50V 10%
C615 2113944A32 CAP CER CHP 39.0PF 50V 5%
C617 2113944A32 CAP CER CHP 39.0PF 50V 5%
C619 2113944A32 CAP CER CHP 39.0PF 50V 5%
C620 2113945C31
CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C621 2113946K02 CAP CER CHP 0.10UF 16V
C629 2113944A32 CAP CER CHP 39.0PF 50V 5%
C630 2113944A32 CAP CER CHP 39.0PF 50V 5%
C631 2113944A32 CAP CER CHP 39.0PF 50V 5%
C632 2113944A32 CAP CER CHP 39.0PF 50V 5%
C633 2113944A32 CAP CER CHP 39.0PF 50V 5%
C634 2113944A32 CAP CER CHP 39.0PF 50V 5%
C635 2113944A32 CAP CER CHP 39.0PF 50V 5%
C636 2113944A32 CAP CER CHP 39.0PF 50V 5%
C637 2113945L49
CAP,FXD,.01UF,+5%,-5%,50V-
DC,0603,X7R,-55DEG CMIN,
125DEG CMAX,P
C638 2113945C31
CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C640 NOT PLACED –
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
