Motorola ATS 3000 User Manual

700/800 MHz Schematics, Board Overlays, and Parts Lists 9.4-43
6816985H01-F February 14, 2012
C641 NOT PLACED –
C652 2113944A32 CAP CER CHP 39.0PF 50V 5%
C653 2113944A32 CAP CER CHP 39.0PF 50V 5%
C654 2113944A32 CAP CER CHP 39.0PF 50V 5%
C655 2113944A32 CAP CER CHP 39.0PF 50V 5%
C656 2113944A32 CAP CER CHP 39.0PF 50V 5%
C657 2113944A32 CAP CER CHP 39.0PF 50V 5%
C658 2113944A32 CAP CER CHP 39.0PF 50V 5%
C671 2113944A31 CAP CER CHP 33.0PF 50V 5%
C672 2113944A32 CAP CER CHP 39.0PF 50V 5%
C673 2113944A31 CAP CER CHP 33.0PF 50V 5%
C674 2113945A05 CAP CER CHP 470PF 50V 10%
C675 2113944A32 CAP CER CHP 39.0PF 50V 5%
C680 2113944A31 CAP CER CHP 33.0PF 50V 5%
C700 2113946B04
CAP CER CHP 0.10UF 10V
10%
C701 2113944A19
CAP CER CHP 5.6PF 50V +/-
0.5PF
C702 2113944A19
CAP CER CHP 5.6PF 50V +/-
0.5PF
C703 NOT PLACED –
C704 2113946F01 CAP CER CHP 2.2UF 6.3V 10%
C705 2113946F01 CAP CER CHP 2.2UF 6.3V 10%
C706 2113945A09
CAP CER CHP 1000PF 50V
10%
C708 2113944A31 CAP CER CHP 33.0PF 50V 5%
C709 2113944A31 CAP CER CHP 33.0PF 50V 5%
C710 2113946J03
CAP CER CHP 10.0UF 16V
10%
C711 211394600 CAP CER CHP 1.0UF 16V 10%
C712 211394600 CAP CER CHP 1.0UF 16V 10%
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C713 2314030F03
CAP,FXD,22UF,+10%,-
10%,16V-DC,SM,-55DEG
CMIN,125DEG CMAX,561MA
C714 2113945A09
CAP CER CHP 1000PF 50V
10%
C715 2314030F03
CAP,FXD,22UF,+10%,-
10%,16V-DC,SM,-55DEG
CMIN,125DEG CMAX,561MA
C716 2113946F01 CAP CER CHP 2.2UF 6.3V 10%
C717 211394600 CAP CER CHP 1.0UF 16V 10%
C718 2113946F01 CAP CER CHP 2.2UF 6.3V 10%
C719 211394600 CAP CER CHP 1.0UF 16V 10%
C720 2113946G01 CAP CER CHP 2.2UF 16V 10%
C721 211394600 CAP CER CHP 1.0UF 16V 10%
C722 211394600 CAP CER CHP 1.0UF 16V 10%
C723 211394600 CAP CER CHP 1.0UF 16V 10%
C724 211394600 CAP CER CHP 1.0UF 16V 10%
C725 2113946K02 CAP CER CHP 0.10UF 16V
C726 2113944F07
CAP,CHIP,1000PF,+5%,-
5%,50V-DC,0805,C0G,-55DEG
CMIN,125DEG CMAX
C727 2113944A40
CAP CER CHP 100.0PF 50V
5%
C728 2113945A58
CAP,FXD,910PF,+10%,-
10%,50V-DC,0402,X7R,-
55DEG CMIN,125DEG CMAX
C729 2314030V06
CAP,FXD,68UF,+10%,-
10%,16V-DC,SM,-55DEG
CMIN,125DEG CMAX,833MA
C730 2113944A40
CAP CER CHP 100.0PF 50V
5%
C731 2113946G01 CAP CER CHP 2.2UF 16V 10%
C732 2113944A40
CAP CER CHP 100.0PF 50V
5%
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C734 2113945C31
CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C735 211394600 CAP CER CHP 1.0UF 16V 10%
C736 2113946J03
CAP CER CHP 10.0UF 16V
10%
C737 2113945C31
CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C738 2113946K02 CAP CER CHP 0.10UF 16V
C742 2113945A05 CAP CER CHP 470PF 50V 10%
C743 2113944A25
CAP CER CHP 10.0PF 50V +/-
0.5PF
C750 2113946J03
CAP CER CHP 10.0UF 16V
10%
C751 2113946J03
CAP CER CHP 10.0UF 16V
10%
C752 2113944A40
CAP CER CHP 100.0PF 50V
5%
C753 2113944A40
CAP CER CHP 100.0PF 50V
5%
C754 211394600 CAP CER CHP 1.0UF 16V 10%
C755 211394600 CAP CER CHP 1.0UF 16V 10%
C756 2113944A40
CAP CER CHP 100.0PF 50V
5%
C757 2113944A40
CAP CER CHP 100.0PF 50V
5%
C758 211394600 CAP CER CHP 1.0UF 16V 10%
C759 211394600 CAP CER CHP 1.0UF 16V 10%
C760 2113944A40
CAP CER CHP 100.0PF 50V
5%
C761 2113944A40
CAP CER CHP 100.0PF 50V
5%
C762 2113945C31
CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C763 2113944A40
CAP CER CHP 100.0PF 50V
5%
C764 2113946B03 CAP CER CHP 0.068UF 10V 10
C765 2113946B03 CAP CER CHP 0.068UF 10V 10
C766 2113944A40
CAP CER CHP 100.0PF 50V
5%
C767 2113944A40
CAP CER CHP 100.0PF 50V
5%
C768 2113944A40
CAP CER CHP 100.0PF 50V
5%
C769 2113944A40
CAP CER CHP 100.0PF 50V
5%
C770 2113945C31
CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C771 2113945C31
CAP,FXD,.1UF,+10%,-
10%,50V-DC,0603,X7R,-
55DEG CMIN,125DEG CMAX
C773 2113946K02 CAP CER CHP 0.10UF 16V
C780 NOT PLACED –
C790 2113946A02
CAP CER CHP 0.022UF 16V
10,
C791 2113946K02 CAP CER CHP 0.10UF 16V
C792 2113946K02 CAP CER CHP 0.10UF 16V
C796 2113945A03 CAP CER CHP 330PF 50V 10%
C800 2113955D31
CAP,FXD,1UF,+10%,-10%,
16V-DC,1206,X7R,-55DEG
CMIN,125DEG CMAX,P
C801 2113944A32 CAP CER CHP 39.0PF 50V 5%
C802 2113945C20
CAP,FXD,.016UF,+10%,-10%,
50V-DC,0603,X7R,-55DEG
CMIN,125DEG CMA
C803 2113944A32 CAP CER CHP 39.0PF 50V 5%
C804 211394600 CAP CER CHP 1.0UF 16V 10%
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
