Motorola ATS 3000 User Manual

9.4-44 700/800 MHz Schematics, Board Overlays, and Parts Lists
February 14, 2012 6816985H01-F
C805 2113945C20
CAP,FXD,.016UF,+10%,-10%,
50V-DC,0603,X7R,-55DEG
CMIN,125DEG CMA
C806 2113946K02 CAP CER CHP 0.10UF 16V
C807 2113946K02 CAP CER CHP 0.10UF 16V
C808 2113946K02 CAP CER CHP 0.10UF 16V
C809 2113945C20
CAP,FXD,.016UF,+10%,-10%,
50V-DC,0603,X7R,-55DEG
CMIN,125DEG CMA
C810 211394600 CAP CER CHP 1.0UF 16V 10%
C811 2113946K02 CAP CER CHP 0.10UF 16V
C812 2113946K02 CAP CER CHP 0.10UF 16V
C813 2113946K02 CAP CER CHP 0.10UF 16V
C814 2113946K02 CAP CER CHP 0.10UF 16V
C815 2113946K02 CAP CER CHP 0.10UF 16V
C816 2113946K02 CAP CER CHP 0.10UF 16V
C817 2113946K02 CAP CER CHP 0.10UF 16V
C818 2113946K02 CAP CER CHP 0.10UF 16V
C830 2113946K02 CAP CER CHP 0.10UF 16V
C840 2113946F03 CAP CER CHP 4.7UF 6.3V 10%
C850 2113945A03 CAP CER CHP 330PF 50V 10%
C851 2113944A40
CAP CER CHP 100.0PF 50V
5%
C855 NOT PLACED –
C856 NOT PLACED –
C857 NOT PLACED –
C858 2113945B02
CAP CER CHP 10,000PF 25V
10%
C859 2113945B02
CAP CER CHP 10,000PF 25V
10%
C860 2113945B02
CAP CER CHP 10,000PF 25V
10%
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C861 2113945B02
CAP CER CHP 10,000PF 25V
10%
C862 2113945B02
CAP CER CHP 10,000PF 25V
10%
C863 2113945B02
CAP CER CHP 10,000PF 25V
10%
C864 2113945B02
CAP CER CHP 10,000PF 25V
10%
C865 2113945B02
CAP CER CHP 10,000PF 25V
10%
C866 2113945B02
CAP CER CHP 10,000PF 25V
10%
C867 NOT PLACED –
C868 NOT PLACED –
CR101 4815897H01 PIN DIODE
CR102 4815897H01 PIN DIODE
CR800 4813978A25
SCHOTTKY 30V SOD-323 T&R
PB FREE
CR801 4813978A25
SCHOTTKY 30V SOD-323 T&R
PB FREE
D1 4813974A19
DIODE ARRAY,MXR,SM,SOT-
323,7V,.2W,SHTK,2,PB-FREE
D103 4813974A05
DIODE,SWG,MMBD301,SM,
SOT-23,30V,.2W,SHTK,PB-
FREE
D104 4816487H01
SWITCHING DIODE,
MINIBLOC
D201 4815011H01 DIODE TRIPLE
D202 4815011H01 DIODE TRIPLE
D210 4805656W87
DIODE,VCTR, @ 15V,1SV279,
SOD-523/SC-79
D211 4805656W87
DIODE,VCTR, @ 15V,1SV279,
SOD-523/SC-79
D212 4805656W87
DIODE,VCTR, @ 15V,1SV279,
SOD-523/SC-79
D401 4815096H01 VARACTOR DIODE 1SV305
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
D402 4885055Y01 DIODE VARACTOR PB-FREE
D501 4809118D02
LED BICOLOR
LNJ115W8POMT
D510 NOT PLACED –
D511 4813978M15
DIODE,RECT,RM140,SM,1A,
40V,SHTK,PB-FREE
D600 4813978B18
DIODE,SWG,BAT54,SM,
SOT-23,200MA,30V,.2W,
SHTK,PB-FREE
D603 4813978A25
SCHOTTKY 30V SOD-323 T&R
PB FREE
D662 4813978A25
SCHOTTKY 30V SOD-323 T&R
PB FREE
D700 4813978B18
DIODE,SWG,BAT54,SM,
SOT-23,200MA,30V,.2W,
SHTK,PB-FREE
E101 2415954H01 INDUCTOR BEAD CHIP
E102 2405688Z01 INDUCTOR FERRITE BEAD
E401 2480640Z01
SURFACE MOUNT FERRITE
BEAD
E402 2480640Z01
SURFACE MOUNT FERRITE
BEAD
E403 2480640Z01
SURFACE MOUNT FERRITE
BEAD
E404 2480640Z01
SURFACE MOUNT FERRITE
BEAD
E405 2480640Z01
SURFACE MOUNT FERRITE
BEAD
E406 2480640Z01
SURFACE MOUNT FERRITE
BEAD
E407 2480640Z01
SURFACE MOUNT FERRITE
BEAD
E408 2480640Z01
SURFACE MOUNT FERRITE
BEAD
E409 2480640Z01
SURFACE MOUNT FERRITE
BEAD
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
E500 2405688Z01 INDUCTOR FERRITE BEAD
E501 2405688Z01 INDUCTOR FERRITE BEAD
E800 2480574F01
IND FERRITE CHIP 60OHM
0603
E801 2480574F01
IND FERRITE CHIP 60OHM
0603
E802 0613952G67
CER CHIP RES 0.0 +/-0.050
OHM
F500 6515076H01
FUSE CHIP SMT TR/1608FF
3A
FL1 9116647H01
LC FLTR, MULITILAYER
CERAMIC
FL2 9116647H01
LC FLTR, MULITILAYER
CERAMIC
FL3 91009300001
FILTER,MONOLITHIC
CRYSTAL,BANDPASS,109.65
MHZ NOM
FL200 9116848H01
FLTR SW CAP 3 POLE
BUTTERW, W18
J101 2880658Z08 CONNECTOR SMA
J601 0916287H01 CONN VERT 45 PIN ZIF
J650 0916287H02 CONN 20 PIN ZIF
L1 2414017G19
IDCTR,CHIP,100NH,5%,300MA
,2.5OHM,CER,8 Q,SM,0603,
PB-FREE
L2 2415429H33 CHIP INDUCTOR
L4 2488090Y14
INDUCTOR,MULTILAYER,
12NH,1005,SMD,PB FREE
L5 2488090Y12
INDUCTOR,MULTILAYER,
8.2NH,1005,SMD,PB FREE
L6 2488090Y14
INDUCTOR,MULTILAYER,
12NH,1005,SMD,PB FREE
L7 NOT PLACED –
L10 2415429H32 CHIP INDUCTOR
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
