Motorola ATS 3000 User Manual

9.4-48 700/800 MHz Schematics, Board Overlays, and Parts Lists
February 14, 2012 6816985H01-F
R613 0613952R08
CER CHIP RES 20K OHM 5
0402
R614 0613952R08
CER CHIP RES 20K OHM 5
0402
R615 0613952R25
CER CHIP RES 100K OHM 5%
0402
R616 0613952Q49
CER CHIP RES 100 OHM 5
0402
R617 NOT PLACED –
R620 0613952Q49
CER CHIP RES 100 OHM 5
0402
R621 0613952Q49
CER CHIP RES 100 OHM 5
0402
R622 0613952Q49
CER CHIP RES 100 OHM 5
0402
R625 0613952Q49
CER CHIP RES 100 OHM 5
0402
R626 0613952Q49
CER CHIP RES 100 OHM 5
0402
R633 NOT PLACED –
R634 0613952R66
CER CHIP RES 0.0 +/-0.050
OHM
R635 NOT PLACED –
R636 0613952R01
CER CHIP RES 10K OHM 5%
0402
R637 0613952Q73
CER CHIP RES 1000 OHM 5
0402
R638 0613952Q73
CER CHIP RES 1000 OHM 5
0402
R639 0613952Q73
CER CHIP RES 1000 OHM 5
0402
R640 0613952Q73
CER CHIP RES 1000 OHM 5
0402
R641 0613952Q73
CER CHIP RES 1000 OHM 5
0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R642 0613952Q73
CER CHIP RES 1000 OHM 5
0402
R643 0613952Q73
CER CHIP RES 1000 OHM 5
0402
R644 0613952Q73
CER CHIP RES 1000 OHM 5
0402
R647 0613952R01
CER CHIP RES 10K OHM 5%
0402
R649 0613952R17
CER CHIP RES 47K OHM 5%
0402
R654 0613952R01
CER CHIP RES 10K OHM 5%
0402
R656 0613952R01
CER CHIP RES 10K OHM 5%
0402
R658 0613952P18
CER CHIP RES 150K OHM 1
0402
R666 0613952Q42
CER CHIP RES 51.0 OHM 5
0402
R667 0613952Q63
CER CHIP RES 390 OHM 5
0402
R668 0613952Q45
CER CHIP RES 68.0 OHM 5
0402
R669 0613952Q49
CER CHIP RES 100 OHM 5
0402
R670 0613952Q49
CER CHIP RES 100 OHM 5
0402
R671 0613952Q63
CER CHIP RES 390 OHM 5
0402
R672 0613952R01
CER CHIP RES 10K OHM 5%
0402
R673 0613952R01
CER CHIP RES 10K OHM 5%
0402
R674 0613952Q49
CER CHIP RES 100 OHM 5
0402
R675 0613952Q67
CER CHIP RES 560 OHM 5
0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R677 0613952R01
CER CHIP RES 10K OHM 5%
0402
R678 0613952Q49
CER CHIP RES 100 OHM 5
0402
R697 0613952Q49
CER CHIP RES 100 OHM 5
0402
R700 0613952Q80
CER CHIP RES 2000 OHM 5
0402
R701 0613952R17
CER CHIP RES 47K OHM 5%
0402
R702 0613952R66
CER CHIP RES 0.0 +/-0.050
OHM
R703 0613952R17
CER CHIP RES 47K OHM 5%
0402
R704 0613952Q49
CER CHIP RES 100 OHM 5
0402
R705 0613952R17
CER CHIP RES 47K OHM 5%
0402
R708 0613952R19
CER CHIP RES 56K OHM 5%
0402
R709 0613952H17 CER CHIP RES 4.7OHM 5%
R710 0688044N04
RES,METAL STRIP, 0.1 OHM,
1%,0.125W,SMD,0805,75PPM/
CEL,PKG
R711 0613952G67
CER CHIP RES 0.0 +/-0.050
OHM
R712 0613952Q49
CER CHIP RES 100 OHM 5
0402
R714 0688044N04
RES,METAL STRIP, 0.1 OHM,
1%,0.125W,SMD,0805,75PPM/
CEL,PKG
R717 0613952R66
CER CHIP RES 0.0 +/-0.050
OHM
R718 0613952G67
CER CHIP RES 0.0 +/-0.050
OHM
R722 0613952R08
CER CHIP RES 20K OHM 5
0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R725 0613952R66
CER CHIP RES 0.0 +/-0.050
OHM
R726 0613952R66
CER CHIP RES 0.0 +/-0.050
OHM
R729 0613952R13
CER CHIP RES 33K OHM 5%
0402
R740 0613952Q63
CER CHIP RES 390 OHM 5
0402
R741 0613952R17
CER CHIP RES 47K OHM 5%
0402
R742 0613952R17
CER CHIP RES 47K OHM 5%
0402
R743 NOT PLACED –
R744 NOT PLACED –
R745 0613952R56
CER CHIP RES 2.0M OHM 5
0402
R746 0613952R56
CER CHIP RES 2.0M OHM 5
0402
R747 0613952Q73
CER CHIP RES 1000 OHM 5
0402
R748 0613952R41
CER CHIP RES 470K OHM 5%
0402
R749 0613952R41
CER CHIP RES 470K OHM 5%
0402
R750 0613952Q63
CER CHIP RES 390 OHM 5
0402
R751 0613952Q63
CER CHIP RES 390 OHM 5
0402
R752 0613952Q81
CER CHIP RES 2200 OHM 5
0402
R753 0613952Q81
CER CHIP RES 2200 OHM 5
0402
R756 0613952R66
CER CHIP RES 0.0 +/-0.050
OHM
R757 0613952R08
CER CHIP RES 20K OHM 5
0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
