Motorola ATS 3000 User Manual

700/800 MHz Schematics, Board Overlays, and Parts Lists 9.4-49
6816985H01-F February 14, 2012
R758 0613952R19
CER CHIP RES 56K OHM 5%
0402
R759 0613952R01
CER CHIP RES 10K OHM 5%
0402
R760 0613952Q93
CER CHIP RES 6800 OHM 5
0402
R763 NOT PLACED –
R764 NOT PLACED –
R765 NOT PLACED –
R767 0613952R66
CER CHIP RES 0.0 +/-0.050
OHM
R768 NOT PLACED –
R771 NOT PLACED –
R772 0613952Q49
CER CHIP RES 100 OHM 5
0402
R773 0613952Q49
CER CHIP RES 100 OHM 5
0402
R774 0613952Q49
CER CHIP RES 100 OHM 5
0402
R775 0613952Q49
CER CHIP RES 100 OHM 5
0402
R776 NOT PLACED –
R777 0613952R01
CER CHIP RES 10K OHM 5%
0402
R778 0613952R01
CER CHIP RES 10K OHM 5%
0402
R779 0613952R01
CER CHIP RES 10K OHM 5%
0402
R780 0613952Q89
CER CHIP RES 4700 OHM 5
0402
R781 0613952R01
CER CHIP RES 10K OHM 5%
0402
R782 0613952R01
CER CHIP RES 10K OHM 5%
0402
R783 0613952R01
CER CHIP RES 10K OHM 5%
0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R784 NOT PLACED –
R785 0613952Q49
CER CHIP RES 100 OHM 5
0402
R786 0613952R17
CER CHIP RES 47K OHM 5%
0402
R790 0613952R19
CER CHIP RES 56K OHM 5%
0402
R791 0613952R66
CER CHIP RES 0.0 +/-0.050
OHM
R792 0613952R66
CER CHIP RES 0.0 +/-0.050
OHM
R793 0613952R66
CER CHIP RES 0.0 +/-0.050
OHM
R794 0613952R66
CER CHIP RES 0.0 +/-0.050
OHM
R795 0613952R17
CER CHIP RES 47K OHM 5%
0402
R796 0613952R66
CER CHIP RES 0.0 +/-0.050
OHM
R797 0613952Q41
CER CHIP RES 47.0 OHM 5
0402
R798 0613952Q61
CER CHIP RES 330 OHM 5
0402
R799 0613952R01
CER CHIP RES 10K OHM 5%
0402
R801 NOT PLACED –
R802 0613952Q49
CER CHIP RES 100 OHM 5
0402
R803 0613952Q49
CER CHIP RES 100 OHM 5
0402
R804 0613952Q66
CER CHIP RES 510 OHM 5
0402
R805 0613952R01
CER CHIP RES 10K OHM 5%
0402
R806 0613952Q66
CER CHIP RES 510 OHM 5
0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R807 0613952R01
CER CHIP RES 10K OHM 5%
0402
R808 0613952R66
CER CHIP RES 0.0 +/-0.050
OHM
R809 0613952R17
CER CHIP RES 47K OHM 5%
0402
R810 0613952R01
CER CHIP RES 10K OHM 5%
0402
R811 0613952Q66
CER CHIP RES 510 OHM 5
0402
R812 0613952R25
CER CHIP RES 100K OHM 5%
0402
R813 0613952R66
CER CHIP RES 0.0 +/-0.050
OHM
R814 NOT PLACED –
R815 0613952R66
CER CHIP RES 0.0 +/-0.050
OHM
R816 0613952R17
CER CHIP RES 47K OHM 5%
0402
R820 0613952R01
CER CHIP RES 10K OHM 5%
0402
R829 NOT PLACED –
R837 0613952Q37
CER CHIP RES 33.0 OHM 5
0402
R838 0613952Q37
CER CHIP RES 33.0 OHM 5
0402
R839 0613952R01
CER CHIP RES 10K OHM 5%
0402
R840 0613952Q66
CER CHIP RES 510 OHM 5
0402
R841 0613952R01
CER CHIP RES 10K OHM 5%
0402
R842 0613952R01
CER CHIP RES 10K OHM 5%
0402
R843 0613952R41
CER CHIP RES 470K OHM 5%
0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R844 0613952Q61
CER CHIP RES 330 OHM 5
0402
S500 408513E04
SWITCH FREQ DUAL
FUNCTION
S501 1880619Z06 POTENTIOMETER, VOLUME
S502 4016882H01
TACTILE SWITCH
EMERGENCY
S503 4070354A01 LIGHT TOUCH SWITCH-SMD
S504 4070354A01 LIGHT TOUCH SWITCH-SMD
S505 4070354A01 LIGHT TOUCH SWITCH-SMD
S506 4070354A01 LIGHT TOUCH SWITCH-SMD
SH001 2616071H01 SHIELD MIXER
SH002 2616550H01 SHLD FITLER
SH101 2616559H01 SHLD PCIC
SH102 2616557H01 SHLD HARMONIC BOT
SH103 2616558H01 SHLD HARMONIC TOP
SH104 2616555H01 SHLD PA
SH201 2616560H01 SHLD SYN
SH202 2616556H01 SHLD FRAN N
SH203 2616553H01 SHLD VCO BOT
SH204 2616551H01 SHLD DAC
SH205 2616554H01 SHLD VCO TOP
SH401 2616552H01 SHLD ABACUS
SH402 2616518H01 SHLD 2ND LO FLTR
T1 2516148H01 XMFR MIXER 5:1
T2 2516372H01
TRANSFORMER, BALUN,
MIXER ,25:1
U1 5164015H81
IC,MXR,DBL BAL
GILBERT,CELL,SM
U2 5185941F45
ATTEN,VAR,14.4DBMIN,15.6D
BMAX,0-2000 MHZFREQ,
50OHM,PCMT,SOT
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
