Motorola ATS 3000 User Manual

9.4-50 700/800 MHz Schematics, Board Overlays, and Parts Lists
February 14, 2012 6816985H01-F
Notes:
1. For optimum performance, order replacement diodes, transistors, and circuit
modules by Motorola part number only.
2. When ordering crystals, specify carrier frequency, crystal frequency, crystal
type number, and Motorola part number.
3. Part value notations:
p=10
-12
n=10
-9
µ=10
-6
m=10
-3
k=10
3
M=10
6
4. ITEM refers to the component reference designator. SIDE refers to the
location of the component on the board; S1=Side 1, S2=Side 2.
U3 5116349H01 DUAL INVERTER IC
U101 5115678H01
VHF/UHF/800/900 MHZ
LDMOS DRIVER IC
U102 5185765B26 IC PWR CTRL IN MOS20
U103 5115022H01 IC TEMPERATURE SENSOR
U106 5185368C84
DIRECTIONAL CPLR
7/800MHZ
U201 5116245H01 CC LVFRACN
U202 5185941F40 IC, 12 BIT DAC
U205 5116411H01 IC,OP AMP,
U250 5171121L01
CUSTOM LOW VOLTAGE VCO
BUFFER IC
U401 5185963A85 IC-ABACUS III-LP
U500 5188493T01
IC,VREG/SWG,LP2989,SM,
MINI SO-8 HI PRCN REG 5V
U501 5185941F35 IC, VREG, NOPB
U502 5185941F35 IC, VREG, NOPB
U601 5185941F22
IC,OPAMP,SGL,OPA237,
SOT23,NOPB
U602 5185941F22
IC,OPAMP,SGL,OPA237,
SOT23,NOPB
U701 5185143E77
IC, MAKO ASIC, CMOS PWR
MGMT
U702 5185941F22
IC,OPAMP,SGL,OPA237,
SOT23,NOPB
U705 5114000B39
IC,BFR,1PER PKG,SM,
SOT-353,PB-FREE
U712 5188691V01
IC,MUX/
DEMUX,NC7SB3157P6X,SM,S
C70-6,1PER PKG,BUS,PB
FREE
U713 5115453H01
RAIL TO RAIL OUTPUT, 8 PIN
BGA
U714 5115453H01
RAIL TO RAIL OUTPUT, 8 PIN
BGA
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
U800 5185941F04
IC, PATRIOT BRAVO,
1.2.2,256BGA, PB-FREE
U801 5114000B39
IC,BFR,1PER PKG,SM,
SOT-353,PB-FREE
U802 5114000B39
IC,BFR,1PER PKG,SM,
SOT-353,PB-FREE
U803 51012093001 64MB,60NS,SM,1.8V,90NM
U804 5171897M01
IC,SRAM,8M,512KX16,55NS,
SM,FBGA48,
VR500 4809788E21
DIODE, ZENER, SOD-323,
SMD, W18 COMPLIANT
VR501 4813977M19
DIODE,ZEN,MBZ5240,SM,
SOT-23,10V,10MA,.225W,
ZEN,PB-FREE
VR502 4809788E21
DIODE, ZENER, SOD-323,
SMD, W18 COMPLIANT
VR503 4809788E21
DIODE, ZENER, SOD-323,
SMD, W18 COMPLIANT
VR504 4809788E21
DIODE, ZENER, SOD-323,
SMD, W18 COMPLIANT
VR505 4809788E21
DIODE, ZENER, SOD-323,
SMD, W18 COMPLIANT
VR506 4809788E21
DIODE, ZENER, SOD-323,
SMD, W18 COMPLIANT
VR507 4809788E21
DIODE, ZENER, SOD-323,
SMD, W18 COMPLIANT
VR591 4813977A43
PB-FREE, NOT COMPLETELY
ENRICHED
VR592 4813977A43
PB-FREE, NOT COMPLETELY
ENRICHED
VR593 4813977A43
PB-FREE, NOT COMPLETELY
ENRICHED
VR594 4813977A43
PB-FREE, NOT COMPLETELY
ENRICHED
VR595 4813977A43
PB-FREE, NOT COMPLETEL
YENRICHED
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
VR596 4813977A43
PB-FREE, NOT COMPLETELY
ENRICHED
VR650 4813979P12
DIODE ARRAY,TRNSNT
PROT,SM,SOT-457,12V,
.225W,ZEN,4,PB-FREE
VR651 4813977A43
PB-FREE, NOT COMPLETELY
ENRICHED
VR652 4813977A43
PB-FREE, NOT COMPLETELY
ENRICHED
VR657 4809788E21
DIODE, ZENER, SOD-323,
SMD, W18 COMPLIANT
VR658 4813977C23
DIODE,ZEN,MMSZ5243,SM,
SOD-123,13V,10MA,.5W,
ZEN,PB-FREE
VR659 4813979P10
DIODE ARRAY,TRNSNT
PROT,SM,SOT-457,5.6V,
.225W,ZEN,4,PB-FREE
VR662 4813979P10
DIODE ARRAY,TRNSNT
PROT,SM,SOT-457,5.6V,
.225W,ZEN,4,PB-FREE
VR663 4813977M18
DIODE,ZEN,MBZ5239,SM,
SOT-23,9.1V,10MA,.225W,
ZEN,PB-FREE
VR678 4866544A01
DIODE ARRAY,ZEN,
SR05.TCT,SM,5V,5,LOW
CAPACITANCE TVS DIO
VR701 4813977M11
DIODE,ZEN,MBZ5232,SM,
SOT-23,5.6V,10MA,.225W,
ZEN,PB-FREE
Y200 9375432M01 REF OSC 16.8 MHZ 1.5 PPM
Y201 48012102004
RESONATOR CERAMIC
960MHZ
Y202 48012102005
RESONATOR CERAMIC
1025MHZ
Y203 48012102006
RESONATOR CERAMIC
1110MHZ
Y701 4809995L05
XTAL QUARTZ 32.768KHZ
CC4V-T1
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
Y702 4864005H01
RESONATOR, CRYSTAL
24.576 MHZ
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
