Motorola ATS 3000

9.5-30 900MHz Schematics, Board Overlays, and Parts Lists
February 14, 2012 6816985H01-F
C800 2113955D31
CAP,FXD,1UF,+10%, -10%,
16V-DC,1206
C801 2113944A32
CAP CER CHP 39.0PF 50V 5%
C802 2113945C20
CAP,FXD,.016UF,+10%,
-10%,50V-DC,0603
C803 2113944A32
CAP CER CHP 39.0PF 50V 5%
C804 2113946E02
CAP CER CHP 1.0UF 16V 10%
C805 2113945C20
CAP,FXD,.016UF,+10%, -10%,
50V-DC,0604
C806 2113945Y02
CAP,FXD,.1UF,+10%, -10%,
16V-DC,0402
C807 2113945Y02
CAP,FXD,.1UF,+10%, -10%,
16V-DC,0402
C808 2113945Y02
CAP,FXD,.1UF,+10%, -10%,
16V-DC,0402
C809 2113945C20
CAP,FXD,.016UF,+10%, -10%,
50V-DC,0605
C810 2113946E02
CAP CER CHP 1.0UF 16V 10%
C811 2113945Y02
CAP,FXD,.1UF,+10%, -10%,
16V-DC,0402
C812 2113945Y02
CAP,FXD,.1UF,+10%, -10%,
16V-DC,0402
C813 2113945Y02
CAP,FXD,.1UF,+10%,-10%,
16V-DC,0402
C814 2113945Y02
CAP,FXD,.1UF,+10%,-10%,
16V-DC,0402
C815 2113945Y02
CAP,FXD,.1UF,+10%,-10%,
16V-DC,0402
C816 2113945Y02
CAP,FXD,.1UF,+10%,-10%,
16V-DC,0402
C817 2113945Y02
CAP,FXD,.1UF,+10%, -10%,
16V-DC,0402
C818 2113945Y02
CAP,FXD,.1UF,+10%, -10%,
16V-DC,0402
C830 2113945Y02
CAP,FXD,.1UF,+10%, -10%,
16V-DC,0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C840 2113946F03
CAP CER CHP 4.7UF 6.3V 10%
C850 2113945A03
CAP CER CHP 330PF 50V 10%
C851 2113944A31
CAP CER CHP 33.0PF 50V 5%
C852 2113944A18
CAP CER CHP 5.1PF 50V
+/- 0.5PF
C853 2113944A32
CAP CER CHP 39.0PF 50V 5%
C855 NOT PLACED
–
C856 NOT PLACED
–
C857 NOT PLACED
–
C858 2113945B02
CAP CER CHP 10,000PF 25V
10%
C859 2113945B02
CAP CER CHP 10,000PF 25V
10%
C860 2113945B02
CAP CER CHP 10,000PF 25V
10%
C861 2113945B02
CAP CER CHP 10,000PF 25V
10%
C862 2113945B02
CAP CER CHP 10,000PF 25V
10%
C863 2113945B02
CAP CER CHP 10,000PF 25V
10%
C864 2113945B02
CAP CER CHP 10,000PF 25V
10%
C865 2113945B02
CAP CER CHP 10,000PF 25V
10%
C866 2113945B02
CAP CER CHP 10,000PF 25V
10%
C867 NOT PLACED
–
C868 NOT PLACED
–
CR101 4815897H01
PIN DIODE
CR102 4815897H01
PIN DIODE
CR800 4813978A25
SCHOTTKY 30V SOD-323 T&R
PB FREE
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
CR801 4813978A25
SCHOTTKY 30V SOD-323 T&R
PB FREE
D103 4813974A05
DIODE,SWG,MMBD301,SM,
SOT-23,30V,.2W,SHTK,
PB-FREE
D104 4816487H01
SWITCHING DIODE,
MINIBLOC
D105 4813974A05
DIODE,SWG,MMBD301,SM,
SOT-23,30V,.2W,SHTK,
PB-FREE
D201 4815011H01
DIODE TRIPLE
D202 4815011H01
DIODE TRIPLE
D211 4805656W87
DIODE,VCTR, @
15V,1SV279,SOD-523/SC-79
D212 4805656W87
DIODE,VCTR, @
15V,1SV279,SOD-523/SC-79
D401 4815096H01
VARACTOR DIODE 1SV305
D402 4885055Y01
DIODE VARACTOR
PB-FREE
D501 4809118D02
LED BICOLOR
LNJ115W8POMT
D510 NOT PLACED
–
D511 4813978M15
DIODE,RECT,RM140,SM,1A,
40V,SHTK,PB-FREE
D600 4813978B18
DIODE,SWG,BAT54,SM,
SOT-23,200MA,30V,.2W,
SHTK,PB-FREE
D603 4813978A25
SCHOTTKY 30V SOD-323 T&R
PB FREE
D662 4813978A25
SCHOTTKY 30V SOD-323 T&R
PB FREE
D700 4813978B18
DIODE,SWG,BAT54,SM,
SOT-23, 200MA,30V,.2W,
SHTK,PB-FREE
D800 4813974A19
DIODE ARRAY,MXR,SM,
SOT-323,7V,.2W,SHTK,2,
PB-FREE
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
E101 2415954H02
INDUCTOR BEAD CHIP EPP
WITH EPOXY
E102 2405688Z01
INDUCTOR FERRITE BEAD
E401 2480640Z01
SURFACE MOUNT FERRITE
BEAD
E402 2480640Z01
SURFACE MOUNT FERRITE
BEAD
E403 2480640Z01
SURFACE MOUNT FERRITE
BEAD
E404 2480640Z01
SURFACE MOUNT FERRITE
BEAD
E405 2480640Z01
SURFACE MOUNT FERRITE
BEAD
E406 2480640Z01
SURFACE MOUNT FERRITE
BEAD
E407 2480640Z01
SURFACE MOUNT FERRITE
BEAD
E408 2480640Z01
SURFACE MOUNT FERRITE
BEAD
E409 2480640Z01
SURFACE MOUNT FERRITE
BEAD
E500 2405688Z01
INDUCTOR FERRITE BEAD
E501 2405688Z01
INDUCTOR FERRITE BEAD
E800 2480574F01
IND FERRITE CHIP 60OHM
0603
E801 2480574F01
IND FERRITE CHIP 60OHM
0603
E802 0613952G67
CER CHIP RES 0.0 +/-0.050
OHM
F500 6515076H01
FUSE CHIP SMT TR/1608FF
3A
FL1 9116138H01
CERAMIC FILTER
FL2 9116138H01
CERAMIC FILTER
FL3 4885631B01
XTAL FILT 3 POLE 109.65
MOTORO
