900MHz Schematics, Board Overlays, and Parts Lists 9.5-31
6816985H01-F February 14, 2012
FL200 9116848H01
FLTR SW CAP 3 POLE
BUTTERW, W18
J101 2880658Z08
CONNECTOR SMA
J601 0916287H01
CONN VERT 45 PIN ZIF
J650 0916287H02
CONN 20 PIN ZIF
L1 2414017N23
IDCTR,CHIP,82NH,5%,300MA,
1.8OHM,0603
L2 2415429H38
CHIP INDUCTOR, 120nH
+/-5%
L4 2488090Y09
INDUCTOR,MULTILAYER,
4.7NH
L5 2414017P13
IDCTR,CHIP,10NH,5%,300MA
L6 2488090Y11
INDUCTOR,MULTILAYER,6.8N
H
L7 2414017N14
IDCTR,CHIP,15NH,5%
L10 2415429H32
CHIP INDUCTOR, 56nH
+/-5%
L11 2414017N22
IDCTR,CHIP,68NH,5%
L12 2414017K29
IND CER CHIP 330.0 NH 5%
L13 2414032F42
IDCTR,WW,470NH,10%,170M
A,2.5OHM,CER
L14 2414032F38
IDCTR,WW,220NH,5%
L15 2415429H43
CHIP INDUCTOR, 220nH
+/-5%
L101 2414032F36
IDCTR,WW,150NH,5%
L102 2414017G12
IDCTR,CHIP,27NH,5%,
300MA,.6OHM
L103 2460591C03
COIL AIR WOUND INDUC
11.87
L107 2414017G19
IDCTR,CHIP,100NH,5%,
300MA,2.5OHM
L108 2414017G19
IDCTR,CHIP,100NH,5%,
300MA,2.5OHM
L110 2414017G05
IDCTR,CHIP,6.8NH,5%,
300MA, 0603
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
L111 2414017N23
IDCTR,CHIP,82NH,5%
L114 2460591A11
COIL AIR WOUND INDUC 7.66
L115 2460591A11
COIL AIR WOUND INDUC 7.66
L117 2460591B22
COIL AIR WOUND INDUC 8.67
L200 2414017Q20
IDCTR,FXD,2.2UH,20%, 30MA,
.65OHM,FER
L201 2414017Q20
IDCTR,FXD,2.2UH,20%, 30MA,
.65OHM,FER
L203 2414017Q47
IDCTR,FXD,1UH,10%,50MA,
.45OHM,FERR
L204 2414032F21
IDCTR,WW,6.8NH,5%, 600MA,
.11OHM,CER
L205 2414017Q20
IDCTR,FXD,2.2UH,20%, 30MA,
.65OHM,FER
L206 2414017Q20
IDCTR,FXD,2.2UH,20%,
30MA,.65OHM,FER
L207 0613952G67
CER CHIP RES 0.0
+/-0.050 OHM
L210 2414032F36
IDCTR,WW,150NH,5%
L211 0613952G67
CER CHIP RES 0.0
+/-0.050 OHM
L212 2414032F36
IDCTR,WW,150NH,5%
L215 2414032F34
IDCTR,WW,100NH,5%, 400MA,
.46OHM,CER
L216 2414032F34
IDCTR,WW,100NH,5%, 400MA,
.46OHM,CER
L217 2414032F34
IDCTR,WW,100NH,5%, 400MA,
.46OHM,CER
L218 2414032F34
IDCTR,WW,100NH,5%, 400MA,
.46OHM,CER
L219 2414032F36
IDCTR,WW,150NH,5%
L220 2414032F27
IDCTR,WW,27NH,5%,
500MA,.25OHM,CER
L221 2414032F25
IDCTR,WW,18NH,5%,
600MA,.2OHM,CER
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
L230 2414032F25
IDCTR,WW,18NH,5%,
600MA,.2OHM,CER
L290 2414017Q47
IDCTR,FXD,1UH,10%,
50MA,.45OHM,FERR
L299 NOT PLACED
–
L401 2414032D17
IDCTR,WW,150NH,5%,
750MA,.31OHM,CER
L402 2466505A01
COIL INDUCTOR
L403 2466505A01
COIL INDUCTOR
L405 2414032B76
IDCTR,WW,4.7UH,5%,
330MA,4OHM
L406 2414032F73
IDCTR,WW,820NH,5%,
180MA,2.23OHM,CER
L407 2414032F73
IDCTR,WW,820NH,5%,
180MA,2.23OHM,CER
L500 2414017Q42
IDCTR,FXD,390NH,10%,
200MA,.65OHM,FE
L503 2489669V01
IDCTR,WW,100UH,5%
L511 2489669V01
IDCTR,WW,100UH,5%
L651 2414032F75
IDCTR,WW,270NH,2%, 350MA,
1OHM
L652 2414032F75
IDCTR,WW,270NH,2%, 350MA,
1OHM
L701 2486085A01
COIL, POWER INDUCTOR
L702 2486085A01
COIL, POWER INDUCTOR
L703 2464675H01
IDCTR,WW,560NH,5%, 550MA
L704 2464675H01
IDCTR,WW,560NH,5%, 550MA
L705 2464675H01
IDCTR,WW,560NH,5%, 550MA
L708 2416307H01
IDCTR,WW,680NH,5%,0603
L710 2416307H01
IDCTR,WW,680NH,5%,0603
M101 3916333H01
GROUND CONTACT
M701 0985888K02
SKT RTC BTTY LEAP
Q1 4802247J01
BJT, RF AMP, BFS505
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
Q101 4816698H01
MOD,XSTR,FET RF PWR,
7/800
Q212 4813972A15
N-Ch TMOS FET, '6Z', SOT23
T&R
Q213 4885061Y01
XSTR NPN 6V 30UA 12GHZ
PB-FREE
Q214 4813972A15
N-Ch TMOS FET, '6Z', SOT23
T&R
Q215 4885061Y01
XSTR NPN 6V 30UA 12GHZ
PB-FREE
Q216 4885061Y01
XSTR NPN 6V 30UA 12GHZ
PB-FREE
Q217 4813972A15
N-Ch TMOS FET, '6Z', SOT23
T&R
Q218 4813972A15
N-Ch TMOS FET, '6Z', SOT23
T&R
Q401 4805585Q27
TRANSISTOR RF NPN,
BFQ67W NOPB
Q501 4805921T28
XSTR, DUAL NOPB
Q698 4813973A81
XSTR,BIP GP SS,DIG,NPN
AND PNP,SOT-363,50V,
.25W,100MA,BIAS
Q700 4813970A62
XSTR,FET GP PWR, MOSFET,
P-CH,ENHN, CF,-20V, 1.3W,
PB-FREE
Q701 4813973M07
XSTR,BIP GP SS,NPN,T3904,
SM,SOT-23,SMT, 40V,.225W,
200MA,300MHZ
Q702 5185956E76
IC,CONV,SM,SO16,0-30
VINPUT RANGE,6.5A,3.8V, HI
SPD SWTH DR
Q703 4813970A62
XSTR,FET GP PWR, MOSFET,
P-CH,ENHN,CF, -20V,1.3W,
PB-FREE
Q704 NOT PLACED
–
Q705 NOT PLACED
–
Q706 NOT PLACED
–
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
