Motorola ATS 3000 User Manual

9.5-32 900MHz Schematics, Board Overlays, and Parts Lists
February 14, 2012 6816985H01-F
Q709 4885061Y01
XSTR NPN 6V 30UA 12GHZ
PB-FREE
Q801 4813973A42
XSTR,BIP GP SS,NPN,SM,
SC-59,SMT,50V,.23W, 100MA,
PB-FREE
Q804 4813973A81
XSTR,BIP GP SS,DIG,NPN
AND PNP,SOT-363,50V,
.25W,100MA,BIAS
R1 0613952Q55
CER CHIP RES 180 OHM
5 0402
R2 0613952Q96
CER CHIP RES 9100 OHM
5 0402
R3 0613952Q83
CER CHIP RES 2700 OHM
5 0401
R4 0613952Q83
CER CHIP RES 2700 OHM
5 0402
R5 0613952Q54
CER CHIP RES 160 OHM
5 0402
R6 NOT PLACED
–
R7 0613952Q39
CER CHIP RES 39.0 OHM
5 0402
R8 0613952G67
CER CHIP RES 0.0
+/-0.050 OHM
R10 0613952R66
CER CHIP RES 0.0 +/-0.050
OHM
R100 0613952H47
CER CHIP RES 82.0 OHM
5 0603
R101 0613952H47
CER CHIP RES 82.0 OHM
5 0603
R102 0613952H42
CER CHIP RES 51.0 OHM 5%
0603
R103 0613952H47
CER CHIP RES 82.0 OHM
5 0603
R104 0613952H42
CER CHIP RES 51.0 OHM 5%
0603
R105 0613952H68
CER CHIP RES 620 OHM
5 0603
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R106 0613952H56
CER CHIP RES 200 OHM
5 0603
R107 0613952Q53
CER CHIP RES 150 OHM
5 0402
R108 0613952R04
CER CHIP RES 13K OHM
5 0402
R109 0613952R15
CER CHIP RES 39K OHM 5%
0402
R110 0613952Q73
CER CHIP RES 1000 OHM 5
0402
R111 NOT PLACED
–
R113 NOT PLACED
–
R114 0613952R66
CER CHIP RES 0.0 +/-0.050
OHM
R115 0613952R01
CER CHIP RES 10K OHM 5%
0402
R117 0613952R24
CER CHIP RES 91K OHM
5 0402
R118 0613952R32
CER CHIP RES 200K OHM 5
0402
R119 0613952R01
CER CHIP RES 10K OHM 5%
0402
R199 0613952H71
CER CHIP RES 820 OHM
5 0603
R200 0613952Q49
CER CHIP RES 100 OHM
5 0402
R201 0613952Q53
CER CHIP RES 150 OHM
5 0402
R202 0613952Q53
CER CHIP RES 150 OHM
5 0402
R204 0613952R66
CER CHIP RES 0.0
+/-0.050 OHM
R205 0613952Q87
CER CHIP RES 3900 OHM 5
0402
R206 0613952Q48
CER CHIP RES 91.0 OHM
5 0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R207 0613952Q56
CER CHIP RES 200 OHM
5 0402
R208 0613952Q73
CER CHIP RES 1000 OHM 5
0402
R210 0613952Q70
CER CHIP RES 750 OHM
5 0402
R211 0613952R66
CER CHIP RES 0.0
+/-0.050 OHM
R212 0613952Q61
CER CHIP RES 330 OHM
5 0402
R213 0613952R66
CER CHIP RES 0.0
+/-0.050 OHM
R214 0613952R03
CER CHIP RES 12K OHM 5%
0402
R215 0613952R08
CER CHIP RES 20K OHM
5 0402
R216 0613952R17
CER CHIP RES 47K OHM 5%
0402
R217 0613952Q49
CER CHIP RES 100 OHM
5 0402
R220 0613952Q61
CER CHIP RES 330 OHM
5 0402
R222 0613952Q70
CER CHIP RES 750 OHM
5 0402
R225 0613952Q37
CER CHIP RES 33.0 OHM
5 0402
R227 0613952R18
CER CHIP RES 51K OHM
5 0402
R229 0613952R07
CER CHIP RES 18K OHM 5%
0402
R230 0613952R08
CER CHIP RES 20K OHM
5 0402
R231 0613952Q31
CER CHIP RES 18.0 OHM
5 0402
R232 0613952R18
CER CHIP RES 51K OHM
5 0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R233 0613952Q57
CER CHIP RES 220 OHM
5 0402
R234 0613952R07
CER CHIP RES 18K OHM 5%
0402
R235 0613952R08
CER CHIP RES 20K OHM
5 0402
R236 0613952Q33
CER CHIP RES 22.0 OHM
5 0402
R237 0613952Q58
CER CHIP RES 240 OHM
5 0402
R238 0613952Q53
CER CHIP RES 150 OHM
5 0402
R239 0613952R10
CER CHIP RES 24K OHM
5 0402
R241 0613952R66
CER CHIP RES 0.0
+/-0.050 OHM
R243 0613952R12
CER CHIP RES 30K OHM
5 0402
R244 0613952R18
CER CHIP RES 51K OHM
5 0402
R250 0613952R66
CER CHIP RES 0.0
+/-0.050 OHM
R251 0613952R66
CER CHIP RES 0.0
+/-0.050 OHM
R252 0613952R66
CER CHIP RES 0.0
+/-0.050 OHM
R261 0613952R18
CER CHIP RES 51K OHM
5 0402
R262 0613952Q91
CER CHIP RES 5600 OHM 5
0402
R285 0613952Q80
CER CHIP RES 2000 OHM 5
0402
R286 0613952Q45
CER CHIP RES 68.0 OHM
5 0402
R289 0613952Q47
CER CHIP RES 82.0 OHM 5%
0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
