Motorola ATS 3000 User Manual

900MHz Schematics, Board Overlays, and Parts Lists 9.5-33
6816985H01-F February 14, 2012
R290 0613952R13
CER CHIP RES 33K OHM 5%
0402
R291 0613952R14
CER CHIP RES 36K OHM
5 0402
R292 0613952Q37
CER CHIP RES 33.0 OHM
5 0402
R293 0613952Q95
CER CHIP RES 8200 OHM 5
0402
R294 0613952R66
CER CHIP RES 0.0
+/-0.050 OHM
R295 0613952R17
CER CHIP RES 47K OHM 5%
0402
R297 0613952R66
CER CHIP RES 0.0
+/-0.050 OHM
R298 NOT PLACED
–
R401 0613952Q49
CER CHIP RES 100 OHM
5 0402
R402 0613952R10
CER CHIP RES 24K OHM
5 0402
R403 0613952Q94
CER CHIP RES 7500 OHM
5 0402
R404 0613952C81
CER CHIP RES 681 OHM 1%
0603
R405 0613952Q80
CER CHIP RES 2000 OHM 5
0402
R406 0613952Q61
CER CHIP RES 330 OHM
5 0402
R407 0613952R10
CER CHIP RES 24K OHM
5 0402
R408 0613952Q41
CER CHIP RES 47.0 OHM
5 0402
R409 0613952R25
CER CHIP RES 100K OHM 5%
0402
R410 0613952R01
CER CHIP RES 10K OHM 5%
0402
R411 0613952Q63
CER CHIP RES 390 OHM
5 0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R412 0613952R01
CER CHIP RES 10K OHM 5%
0402
R413 0613952R66
CER CHIP RES 0.0 +/-0.050
OHM
R414 0613952R25
CER CHIP RES 100K OHM 5%
0402
R415 0613952R66
CER CHIP RES 0.0 +/-0.050
OHM
R416 NOT PLACED
–
R503 0613952Q63
CER CHIP RES 390 OHM
5 0402
R504 0613952Q66
CER CHIP RES 510 OHM
5 0402
R505 0613952Q93
CER CHIP RES 6800 OHM 5
0402
R507 0613952Q49
CER CHIP RES 100 OHM
5 0402
R508 0613952Q49
CER CHIP RES 100 OHM
5 0402
R509 0613952Q49
CER CHIP RES 100 OHM
5 0402
R510 0613952Q49
CER CHIP RES 100 OHM
5 0402
R511 0613952R01
CER CHIP RES 10K OHM 5%
0402
R512 0613952R17
CER CHIP RES 47K OHM 5%
0402
R520 0613952R37
CER CHIP RES 330K OHM 5%
0402
R530 0613952R01
CER CHIP RES 10K OHM 5%
0402
R531 0613952R01
CER CHIP RES 10K OHM 5%
0402
R532 0613952R01
CER CHIP RES 10K OHM 5%
0402
R533 0613952R01
CER CHIP RES 10K OHM 5%
0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R534 0613952R01
CER CHIP RES 10K OHM 5%
0402
R535 0613952R01
CER CHIP RES 10K OHM 5%
0402
R536 0613952R01
CER CHIP RES 10K OHM 5%
0402
R537 0613952R01
CER CHIP RES 10K OHM 5%
0402
R540 NOT PLACED
–
R545 0613952R17
CER CHIP RES 47K OHM 5%
0402
R546 0613952R17
CER CHIP RES 47K OHM 5%
0402
R547 0613952R17
CER CHIP RES 47K OHM 5%
0402
R594 NOT PLACED
–
R595 0613952R66
CER CHIP RES 0.0 +/-0.050
OHM
R608 0613952Q49
CER CHIP RES 100 OHM
5 0402
R610 NOT PLACED
–
R611 0613952Q49
CER CHIP RES 100 OHM
5 0402
R613 0613952R08
CER CHIP RES 20K OHM
5 0402
R614 0613952R08
CER CHIP RES 20K OHM
5 0402
R615 0613952R25
CER CHIP RES 100K OHM 5%
0402
R616 0613952Q49
CER CHIP RES 100 OHM
5 0402
R617 NOT PLACED
–
R620 0613952Q49
CER CHIP RES 100 OHM
5 0402
R621 0613952Q49
CER CHIP RES 100 OHM
5 0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R622 0613952Q49
CER CHIP RES 100 OHM
5 0402
R625 0613952Q49
CER CHIP RES 100 OHM
5 0402
R626 0613952Q49
CER CHIP RES 100 OHM
5 0402
R633 NOT PLACED
–
R634 0613952R66
CER CHIP RES 0.0 +/-0.050
OHM
R635 NOT PLACED
–
R636 0613952R01
CER CHIP RES 10K OHM 5%
0402
R637 0613952Q73
CER CHIP RES 1000 OHM
5 0402
R638 0613952Q73
CER CHIP RES 1000 OHM
5 0402
R639 0613952Q73
CER CHIP RES 1000 OHM
5 0402
R640 0613952Q73
CER CHIP RES 1000 OHM
5 0402
R641 0613952Q73
CER CHIP RES 1000 OHM
5 0402
R642 0613952Q73
CER CHIP RES 1000 OHM
5 0402
R643 0613952Q73
CER CHIP RES 1000 OHM
5 0402
R644 0613952Q73
CER CHIP RES 1000 OHM
5 0402
R647 0613952R01
CER CHIP RES 10K OHM 5%
0402
R649 0613952R17
CER CHIP RES 47K OHM 5%
0402
R654 0613952R01
CER CHIP RES 10K OHM 5%
0402
R656 0613952R01
CER CHIP RES 10K OHM 5%
0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
