Motorola ATS 3000 User Manual

9.5-34 900MHz Schematics, Board Overlays, and Parts Lists
February 14, 2012 6816985H01-F
R658 0613952P18
CER CHIP RES 150K OHM 1
0402
R666 0613952Q57
CER CHIP RES 220 OHM
5 0402
R667 0613952Q63
CER CHIP RES 390 OHM
5 0402
R668 0613952Q45
CER CHIP RES 68.0 OHM
5 0402
R669 0613952Q49
CER CHIP RES 100 OHM
5 0402
R670 0613952Q49
CER CHIP RES 100 OHM
5 0402
R671 0613952Q63
CER CHIP RES 390 OHM
5 0402
R672 0613952R01
CER CHIP RES 10K OHM 5%
0402
R673 0613952R01
CER CHIP RES 10K OHM 5%
0402
R674 0613952Q49
CER CHIP RES 100 OHM
5 0402
R675 0613952Q67
CER CHIP RES 560 OHM
5 0402
R677 0613952R01
CER CHIP RES 10K OHM 5%
0402
R678 0613952Q49
CER CHIP RES 100 OHM
5 0402
R697 0613952Q49
CER CHIP RES 100 OHM
5 0402
R700 0613952Q80
CER CHIP RES 2000 OHM 5
0402
R701 0613952R17
CER CHIP RES 47K OHM 5%
0402
R702 0613952R66
CER CHIP RES 0.0 +/-0.050
OHM
R703 0613952R17
CER CHIP RES 47K OHM 5%
0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R704 0613952Q49
CER CHIP RES 100 OHM
5 0402
R705 0613952R17
CER CHIP RES 47K OHM 5%
0402
R708 0613952R19
CER CHIP RES 56K OHM 5%
0402
R709 0613952H17
CER CHIP RES 4.7OHM 5%
R710 0688044N04
RES,METAL STRIP, 0.1 OHM,
1%,0.125W,SMD,0805,
75PPM/CEL,PKG
R711 0613952G67
CER CHIP RES 0.0 +/-0.050
OHM
R712 0613952Q49
CER CHIP RES 100 OHM
5 0402
R714 0688044N04
RES,METAL STRIP, 0.1
OHM,1%,0.125W,SMD,0805,
75PPM/CEL,PKG
R717 0613952R66
CER CHIP RES 0.0 +/-0.050
OHM
R718 0613952G67
CER CHIP RES 0.0 +/-0.050
OHM
R722 0613952R08
CER CHIP RES 20K OHM
5 0402
R725 0613952R66
CER CHIP RES 0.0 +/-0.050
OHM
R726 0613952R66
CER CHIP RES 0.0 +/-0.050
OHM
R729 0613952R13
CER CHIP RES 33K OHM 5%
0402
R740 0613952Q63
CER CHIP RES 390 OHM
5 0402
R741 0613952R17
CER CHIP RES 47K OHM 5%
0402
R742 0613952R17
CER CHIP RES 47K OHM 5%
0402
R743 NOT PLACED
–
R744 NOT PLACED
–
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R745 0613952R56
CER CHIP RES 2.0M OHM 5
0402
R746 0613952R56
CER CHIP RES 2.0M OHM 5
0402
R747 0613952Q73
CER CHIP RES 1000 OHM 5
0402
R748 0613952R41
CER CHIP RES 470K OHM 5%
0402
R749 0613952R41
CER CHIP RES 470K OHM 5%
0402
R750 0613952Q63
CER CHIP RES 390 OHM
5 0402
R751 0613952Q63
CER CHIP RES 390 OHM
5 0402
R752 0613952Q81
CER CHIP RES 2200 OHM 5
0402
R753 0613952Q81
CER CHIP RES 2200 OHM 5
0402
R756 0613952R66
CER CHIP RES 0.0 +/-0.050
OHM
R757 0613952R08
CER CHIP RES 20K OHM
5 0402
R758 0613952R19
CER CHIP RES 56K OHM 5%
0402
R759 0613952R01
CER CHIP RES 10K OHM 5%
0402
R760 0613952Q93
CER CHIP RES 6800 OHM 5
0402
R763 NOT PLACED
–
R764 NOT PLACED
–
R765 NOT PLACED
–
R767 0613952R66
CER CHIP RES 0.0 +/-0.050
OHM
R768 NOT PLACED
–
R771 NOT PLACED
–
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R772 0613952Q49
CER CHIP RES 100 OHM
5 0402
R773 0613952Q49
CER CHIP RES 100 OHM
5 0402
R774 0613952Q49
CER CHIP RES 100 OHM
5 0402
R775 0613952Q49
CER CHIP RES 100 OHM
5 0402
R776 NOT PLACED
–
R777 0613952R01
CER CHIP RES 10K OHM 5%
0402
R778 0613952R01
CER CHIP RES 10K OHM 5%
0402
R779 0613952R01
CER CHIP RES 10K OHM 5%
0402
R780 0613952Q89
CER CHIP RES 4700 OHM 5
0402
R781 0613952R01
CER CHIP RES 10K OHM 5%
0402
R782 0613952R01
CER CHIP RES 10K OHM 5%
0402
R783 0613952R01
CER CHIP RES 10K OHM 5%
0402
R784 NOT PLACED
–
R785 0613952Q49
CER CHIP RES 100 OHM
5 0402
R786 0613952R17
CER CHIP RES 47K OHM 5%
0402
R790 0613952R19
CER CHIP RES 56K OHM 5%
0402
R791 0613952R66
CER CHIP RES 0.0 +/-0.050
OHM
R792 0613952R66
CER CHIP RES 0.0 +/-0.050
OHM
R793 0613952R66
CER CHIP RES 0.0 +/-0.050
OHM
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
