Motorola ATS 3000 User Manual

900MHz Schematics, Board Overlays, and Parts Lists 9.5-35
6816985H01-F February 14, 2012
R794 0613952R66
CER CHIP RES 0.0 +/-0.050
OHM
R795 0613952R01
CER CHIP RES 10K OHM 5%
0402
R796 0613952R66
CER CHIP RES 0.0 +/-0.050
OHM
R797 0613952Q41
CER CHIP RES 47.0 OHM
5 0402
R798 0613952Q61
CER CHIP RES 330 OHM
5 0402
R799 0613952R01
CER CHIP RES 10K OHM 5%
0402
R801 0613952Q93
CER CHIP RES 6800 OHM 5
0402
R802 0613952Q49
CER CHIP RES 100 OHM
5 0402
R803 0613952Q49
CER CHIP RES 100 OHM
5 0402
R804 0613952Q66
CER CHIP RES 510 OHM
5 0402
R805 0613952R01
CER CHIP RES 10K OHM 5%
0402
R806 0613952Q66
CER CHIP RES 510 OHM
5 0402
R807 0613952R01
CER CHIP RES 10K OHM 5%
0402
R808 0613952R66
CER CHIP RES 0.0 +/-0.050
OHM
R809 0613952R17
CER CHIP RES 47K OHM 5%
0402
R810 0613952R01
CER CHIP RES 10K OHM 5%
0402
R811 0613952Q66
CER CHIP RES 510 OHM
5 0402
R812 0613952R25
CER CHIP RES 100K OHM 5%
0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R813 0613952R66
CER CHIP RES 0.0 +/-0.050
OHM
R814 NOT PLACED
–
R815 0613952R66
CER CHIP RES 0.0 +/-0.050
OHM
R816 0613952R17
CER CHIP RES 47K OHM 5%
0402
R820 0613952R01
CER CHIP RES 10K OHM 5%
0402
R829 NOT PLACED
–
R837 0613952Q37
CER CHIP RES 33.0 OHM
5 0402
R838 0613952Q37
CER CHIP RES 33.0 OHM
5 0402
R839 0613952R01
CER CHIP RES 10K OHM 5%
0402
R840 0613952Q66
CER CHIP RES 510 OHM
5 0402
R841 0613952R01
CER CHIP RES 10K OHM 5%
0402
R842 0613952R01
CER CHIP RES 10K OHM 5%
0402
R843 0613952R41
CER CHIP RES 470K OHM 5%
0402
R844 0613952Q61
CER CHIP RES 330 OHM
5 0402
S500 4085131E04
SWITCH FREQ DUAL
FUNCTION
S501 1880619Z06
POTENTIOMETER, VOLUME
S502 4016618H01
SWITCH SURFACE MOUNT
S503 4070354A01
LIGHT TOUCH SWITCH-SMD
S504 4070354A01
LIGHT TOUCH SWITCH-SMD
S505 4070354A01
LIGHT TOUCH SWITCH-SMD
S506 4070354A01
LIGHT TOUCH SWITCH-SMD
SH001 2616071H01
SHIELD MIXER
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
SH002 2616550H01
SHLD FITLER
SH101 2616559H01
SHLD PCIC
SH102 2616557H01
SHLD HARMONIC BOT
SH103 2616558H01
SHLD HARMONIC TOP
SH104 2616555H01
SHLD PA
SH201 2616560H01
SHLD SYN
SH202 2616556H01
SHLD FRAN N
SH203 2616553H01
SHLD VCO BOT
SH204 2616551H01
SHLD DAC
SH205 2616554H01
SHLD VCO TOP
SH401 2616552H01
SHLD ABACUS
SH402 2616518H01
SHLD 2ND LO FLTR
SH500 NOT PLACED
–
T1 2516149H01
XFMR JEDI MIXER 4:1
T2 2516372H01
TRANSFORMER, BALUN,
MIXER ,25:1
U1 5164015H81
IC,MXR,DBL BAL GILBERT,
CELL,SM
U101 5115678H01
VHF/UHF/800/900 MHZ
LDMOS DRIVER IC
U102 5185765B26
IC PWR CTRL IN MOS20
U103 5115022H01
IC TEMPERATURE SENSOR
U106 5185368C84
DIRECTIONAL CPLR
7/800MHZ
U201 5116245H01
CC LVFRACN
U202 5185941F40
IC, 12 BIT DAC
U205 5116411H01
IC,OP AMP
U250 5171121L01
CUSTOM LOW VOLTAGE VCO
BUFFER IC
U401 5185963A85
IC-ABACUS III-LP
U500 5188493T01
IC,VREG/SWG,LP2989, SM,IC
MINI SO-8 HI PRCN REG 5V
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
U501 5185941F35
IC, VREG, NOPB
U502 5185941F35
IC, VREG, NOPB
U601 5185941F22
IC,OPAMP,SGL,OPA237,
SOT23,NOPB
U602 5185941F22
IC,OPAMP,SGL,OPA237,
SOT23,NOPB
U701 5185143E77
IC, MAKO ASIC, CMOS PWR
MGMT
U702 5185941F22
IC,OPAMP,SGL,OPA237,
SOT23,NOPB
U705 5114000B39
IC,BFR,1PER PKG,SM,
SOT-353,PB-FREE
U712 5188691V01
IC,MUX/DEMUX,
NC7SB3157P6X,SM,
SC70-6,1PER PKG, BUS,
PB FREE
U713 5115453H01
RAIL TO RAIL OUTPUT,
8 PIN BGA
U714 5115453H01
RAIL TO RAIL OUTPUT,
8 PIN BGA
U800 5185941F04
IC, PATRIOT BRAVO,
1.2.2,256BGA, PB-FREE
U801 5114000B39
IC,BFR,1PER PKG,SM,
SOT-353,PB-FREE
U802 5114000B39
IC,BFR,1PER PKG,SM,
SOT-353,PB-FREE
U803 5185956E69
IC,DRAM,64MB,60NS,IC 1.8V
64
U804 5185941F03
IC,SRAM,8M,512KX16,
70NS,SM,FBGA48,1.95V
U807 5185941F45
ATTEN,VAR,14.4DBMIN,
15.6DBMAX,0-2000 MHZ
FREQ,50OHM,PCMT
U809 5116349H01
DUAL INVERTER IC
VR500 4802245J51
ZENER DIODE; BZX284-C6V8
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
