Motorola ATS 3000 User Manual

9.5-38 900MHz Schematics, Board Overlays, and Parts Lists
February 14, 2012 6816985H01-F
C230 2113944A32
CAP CER CHP 39.0PF 50V 5%
C231 NOT PLACED
–
C232 2113955C33
CAP,FXD,2.2UF,+10%, -10%,
16V-DC,0805,X7R
C233 2113945Y02
CAP,FXD,.1UF,+10%, -10%,
16V-DC,0402
C234 2113944A32
CAP CER CHP 39.0PF 50V 5%
C235 2113945L41
CAPACITOR,FIXED,4700PF
+/- 5% 0603
C236 2113944A32
CAP CER CHP 39.0PF 50V 5%
C237 2113944A62
CAP,FXD,.75PF,.25PF+/-,
50V-DC
C238 2113944A32
CAP CER CHP 39.0PF 50V 5%
C239 2113945B02
CAP CER CHP 10,000PF 25V
10%
C240 2175522M01
CAPACITOR,FIXED,10UF,+10
%,-10%,6.3V
C241 2113945Y02
CAP,FXD,.1UF,+10%, -10%,
16V-DC,0402
C242 2113944A32
CAP CER CHP 39.0PF 50V 5%
C243 2113945B02
CAP CER CHP 10,000PF 25V
10%
C244 2113945B02
CAP CER CHP 10,000PF 25V
10%
C245 2113945B02
CAP CER CHP 10,000PF 25V
10%
C246 2113945B02
CAP CER CHP 10,000PF 25V
10%
C247 2113945B02
CAP CER CHP 10,000PF 25V
10%
C248 2113944A13
CAP CER CHP 3.3PF 50V
+/- 0.25PF
C250 2113944A32
CAP CER CHP 39.0PF 50V 5%
C251 2113944A32
CAP CER CHP 39.0PF 50V 5%
C253 2113944A32
CAP CER CHP 39.0PF 50V 5%
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C256 2113944A32
CAP CER CHP 39.0PF 50V 5%
C260 NOT PLACED
–
C261 2113944A32
CAP CER CHP 39.0PF 50V 5%
C262 2114036E93
CAP,FXD,1PF,.05PF+/-,
25V-DC,C0G
C263 2113951C25
CAP,FXD,4.3PF,.05PF+/-,
250V-DC,0603
C264 2113944A10
CAP CER CHP 2.4PF 50V
+/- 0.25PF
C265 2188881Y12
CAPACITOR,CERAMIC
CHIP,1.8PF,.1PF+/-,16V-DC
C266 2113944A32
CAP CER CHP 39.0PF 50V 5%
C267 2113944A32
CAP CER CHP 39.0PF 50V 5%
C268 2113944V11
CAP,FXD,2.2PF,.1PF+/-,5
0V-DC,0402
C269 2113944M02
CAP,FXD,2.2PF,.1PF+/-,
50V-DC,0603
C270 2114036E93
CAP,FXD,1PF,.05PF+/-,
25V-DC,C0G
C271 2113944M03
CAP CER CHIP 2.4PF
+-0.1PF
C272 2113944V11
CAP,FXD,2.2PF,.1PF+/-,
50V-DC,0402
C273 2188881Y12
CAPACITOR,CERAMIC CHIP,
1.8PF,.1PF+/-,16V-DC
C274 2113944A32
CAP CER CHP 39.0PF 50V 5%
C275 2188881Y12
CAPACITOR,CERAMIC
CHIP,1.8PF,.1PF+/-,16V-DC
C276 2113944A32
CAP CER CHP 39.0PF 50V 5%
C277 2113944A32
CAP CER CHP 39.0PF 50V 5%
C278 2113944A32
CAP CER CHP 39.0PF 50V 5%
C279 2113944A05
CAP CER CHP 1.5PF 50V
+/- 0.25PF
C280 2113944A08
CAP CER CHP 2.0PF 50V
+/- 0.25PF
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C285 2113945Y02
CAP,FXD,.1UF,+10%, -10%,
16V-DC,0402
C286 2113945A09
CAP CER CHP 1000PF 50V
10%
C289 2113945Y02
CAP,FXD,.1UF,+10%, -10%,
16V-DC,0402
C290 2113945A09
CAP CER CHP 1000PF 50V
10%
C291 2185419D06
CAP,CHIP,.1UF,+10%, -10%,
25V-DC
C292 2185419D06
CAP,CHIP,.1UF,+10%, -10%,
25V-DC
C293 2113944A40
CAP CER CHP 100.0PF 50V
5%
C295 2185419D06
CAP,CHIP,.1UF,+10%, -10%,
25V-DC
C296 2113944A32
CAP CER CHP 39.0PF 50V 5%
C297 2113944A32
CAP CER CHP 39.0PF 50V 5%
C298 2185419D06
CAP,CHIP,.1UF,+10%, -10%,
25V-DC
C401 2113955E37
CAPACITOR,FIXED,10UF,
+10%,-10%,16V-DC,1210
C402 2113945Y02
CAP,FXD,.1UF,+10%, -10%,
16V-DC,0402
C403 2113945Y02
CAP,FXD,.1UF,+10%, -10%,
16V-DC,0402
C404 2113944C37
CAP CER CHP 39.0PF 50V 5%
C405 2113944A79
CAP,FXD,16PF,+5%, -5%,
50V-DC
C406 2113944A79
CAP,FXD,16PF,+5%, -5%,
50V-DC
C407 2113944A25
CAP CER CHP 10.0PF 50V +/-
0.5PF
C408 2113945B02
CAP CER CHP 10,000PF 25V
10%
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C409 2113945L49
CAP,FXD,.01UF,+5%,-5%,
50V-DC,0604
C410 2113944A32
CAP CER CHP 39.0PF 50V 5%
C411 2113945C31
CAP,FXD,.1UF,+10%, -10%,
50V-DC,0603
C412 2113945C31
CAP,FXD,.1UF,+10%, -10%,
50V-DC,0603
C413 2113945B02
CAP CER CHP 10,000PF 25V
10%
C414 2113945B02
CAP CER CHP 10,000PF 25V
10%
C415 2113945L37
CAP,FXD,3300PF,+5%, -5%,
50V-DC,0603
C416 2189705V01
CAP,CER,.1UF,+5%,-5%,
50V-DC
C417 2113945C31
CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603
C418 2113944A32
CAP CER CHP 39.0PF 50V 5%
C419 NOT PLACED
–
C420 NOT PLACED
–
C421 2113945B02
CAP CER CHP 10,000PF 25V
10%
C422 2113945C31
CAP,FXD,.1UF,+10%, -10%,
50V-DC,0603
C423 2113944C01
CAP CER CHP 180.0PF 50V
5%
C424 2113945C31
CAP,FXD,.1UF,+10%, -10%,
50V-DC,0603
C425 2113945B02
CAP CER CHP 10,000PF 25V
10%
C426 2113944A40
CAP CER CHP 100.0PF 50V
5%
C427 2113944A40
CAP CER CHP 100.0PF 50V
5%
C428 2113945C31
CAP,FXD,.1UF,+10%, -10%,
5 0V-DC,0603
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
