Motorola ATS 3000 User Manual

900MHz Schematics, Board Overlays, and Parts Lists 9.5-37
6816985H01-F February 14, 2012
C105 2113945B02
CAP CER CHP 10,000PF 25V
10%
C106 2113944A77
CAP,FXD,11PF,+5%, -5%,
50V-DC,0402,C
C107 2113944A33
CAP CER CHP 47.0PF 50V 5%
C108 2113945Y02
CAP,FXD,.1UF,+10%, -10%,
16V-DC,0402
C110 2113944M25
CAP,FXD,20PF,+2%, -2%,
50V-DC,0603,C
C111 NOT PLACED
–
C112 NOT PLACED
–
C113 2113945C31
CAP,FXD,.1UF,+10%, -10%,
50V-DC,0602
C114 2113951D37
CAP,FXD,15PF,+1%, -1%,
250V-DC,0805
C115 NOT PLACED
–
C116 2113951C16
CAP,FXD,1.8PF,.05PF+/-,
250V-DC,0603
C117 2113944M28
CAP,FXD,27PF,+2%, -2%,
50V-DC,0603
C118 2113944C37
CAP CER CHP 39.0PF 50V 5%
C119 2113944A33
CAP CER CHP 47.0PF 50V 5%
C120 2113944A32
CAP CER CHP 39.0PF 50V 5%
C121 2313960C26
CAP TANT 1.0 UF 10% 35V
C122 2113945Y02
CAP,FXD,.1UF,+10%, -10%,
16V-DC,0402
C123 2113944A32
CAP CER CHP 39.0PF 50V 5%
C124 2113944A77
CAP,FXD,11PF,+5%, -5%,
50V-DC,0402,C
C125 2113944C37
CAP CER CHP 39.0PF 50V 5%
C126 2113944C37
CAP CER CHP 39.0PF 50V 5%
C127 2113944C69
CAP,FXD,1.8PF,.1PF+/-
C129 2113944C62
CAP,FXD,.75PF,.1PF+/-,
50V-DC,0603
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C130 2113944M01
CAP,FXD,2PF,.1PF+/-,
50V-DC,0603
C131 2113944M01
CAP,FXD,2PF,.1PF+/-,
50V-DC,0603
C132 2113944C62
CAP,FXD,.75PF,.1PF+/-,50V-
DC,0603
C133 2113944M02
CAP,FXD,2.2PF,.1PF+/-,50V-
DC,0603
C134 2113944C62
CAP,FXD,.75PF,.1PF+/-,50V-
DC,0603
C135 2113944C61
CAP,FXD,.5PF,.1PF+/-,
50V-DC
C136 2113944C31
CAP CER CHP 12.0PF 50V 5%
C137 2113944C37
CAP CER CHP 39.0PF 50V 5%
C138 2113945L49
CAP,FXD,.01UF,+5%, -5%,
50V-DC,0603
C139 2113944A32
CAP CER CHP 39.0PF 50V 5%
C140 2113944A32
CAP CER CHP 39.0PF 50V 5%
C141 2113944A33
CAP CER CHP 47.0PF 50V 5%
C142 2113944A33
CAP CER CHP 47.0PF 50V 5%
C143 2113944A32
CAP CER CHP 39.0PF 50V 5%
C144 2113945A07
CAP CER CHP 680PF 50V 10%
C145 2113945A07
CAP CER CHP 680PF 50V 10%
C146 2113945B02
CAP CER CHP 10,000PF 25V
10%
C147 2113945Y02
CAP,FXD,.1UF,+10%, -10%,
16V-DC,0402
C148 2113944A33
CAP CER CHP 47.0PF 50V 5%
C149 2113944A32
CAP CER CHP 39.0PF 50V 5%
C150 2113944A33
CAP CER CHP 47.0PF 50V 5%
C151 2113944A33
CAP CER CHP 47.0PF 50V 5%
C152 2113945Y02
CAP,FXD,.1UF,+10%, -10%,
16V-DC,0402
C153 2113944A33
CAP CER CHP 47.0PF 50V 5%
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C154 2113945Y02
CAP,FXD,.1UF,+10%,
-10%,16V-DC,0402
C155 2113944A32
CAP CER CHP 39.0PF 50V 5%
C156 2113944A32
CAP CER CHP 39.0PF 50V 5%
C157 2113945Y02
CAP,FXD,.1UF,+10%,
-10%,16V-DC,0402
C161 2113944F44
CAP,FXD,12PF,+5%,
-5%,50V-DC,0805,
C162 2113951D36
CAP,FXD,12PF,+1%, -1%,
250V-DC,0805
C163 NOT PLACED
–
C164 2113944F44
CAP,FXD,12PF,+5%,
-5%,50V-DC,0805,
C170 NOT PLACED
–
C171 NOT PLACED
–
C172 NOT PLACED
–
C173 NOT PLACED
–
C174 NOT PLACED
–
C200 2113945Y02
CAP,FXD,.1UF,+10%, -10%,
16V-DC,0402
C201 2113955C33
CAP,FXD,2.2UF,+10%, -10%,
16V-DC,0805,X7R
C202 2113945B02
CAP CER CHP 10,000PF 25V
10%
C203 2113945B02
CAP CER CHP 10,000PF 25V
10%
C204 2113945B02
CAP CER CHP 10,000PF 25V
10%
C205 2113945B02
CAP CER CHP 10,000PF 25V
10%
C206 2113944A31
CAP CER CHP 33.0PF 50V 5%
C207 2313960D07
CAP,FXD,10,+/-10%
C208 2313960D07
CAP,FXD,10,+/-10%
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C209 2113945Y02
CAP,FXD,.1UF,+10%, -10%,
16V-DC,0402
C210 2113944A32
CAP CER CHP 39.0PF 50V 5%
C211 NOT PLACED
–
C212 2113945Y02
CAP,FXD,.1UF,+10%, -10%,
16V-DC,0402
C213 2113945B02
CAP CER CHP 10,000PF 25V
10%
C214 2113955C33
CAP,FXD,2.2UF,+10%, -10%,
16V-DC,0805,X7R
C215 2113945Y02
CAP,FXD,.1UF,+10%, -10%,
16V-DC,0402
C216 2113944A32
CAP CER CHP 39.0PF 50V 5%
C217 2113955C33
CAP,FXD,2.2UF,+10%, -10%,
16V-DC,0805,X7R
C218 2185419D06
CAP,CHIP,.1UF,+10%, -10%,
25V-DC
C219 2113945Y02
CAP,FXD,.1UF,+10%, -10%,
16V-DC,0402
C220 2113944A32
CAP CER CHP 39.0PF 50V 5%
C221 2185419D06
CAP,CHIP,.1UF,+10%, -10%,
25V-DC
C222 2113944A32
CAP CER CHP 39.0PF 50V 5%
C223 2113945A01
CAP CER CHP 220PF 50V 10%
C224 2113945Y02
CAP,FXD,.1UF,+10%, -10%,
16V-DC,0402
C225 2113945Y02
CAP,FXD,.1UF,+10%, -10%,
16V-DC,0402
C226 2113944A32
CAP CER CHP 39.0PF 50V 5%
C227 2113945Y02
CAP,FXD,.1UF,+10%, -10%,
16V-DC,0402
C228 2113945C03
CAP CER CHP 15,000PF 50V
10%
C229 2113945C03
CAP CER CHP 15,000PF 50V
10%
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
