Motorola ATS 3000 User Manual

9.5-40 900MHz Schematics, Board Overlays, and Parts Lists
February 14, 2012 6816985H01-F
C704 2113946F01
CAP CER CHP 2.2UF 6.3V 10%
C705 2113946F01
CAP CER CHP 2.2UF 6.3V 10%
C706 2113945A09
CAP CER CHP 1000PF 50V
10%
C708 2113944A31
CAP CER CHP 33.0PF 50V 5%
C709 2113944A31
CAP CER CHP 33.0PF 50V 5%
C710 2113946J03
CAP CER CHP 10.0UF 16V
10%
C711 2113946E02
CAP CER CHP 1.0UF 16V 10%
C712 2113946E02
CAP CER CHP 1.0UF 16V 10%
C713 2314030F03
CAP,FXD,22UF,+10%, -10%,
16V
C714 2113945A09
CAP CER CHP 1000PF 50V
10%
C715 2314030F03
CAP,FXD,22UF,+10%, -10%,
16V
C716 2113946F01
CAP CER CHP 2.2UF 6.3V 10%
C717 2113946E02
CAP CER CHP 1.0UF 16V 10%
C718 2113946F01
CAP CER CHP 2.2UF 6.3V 10%
C719 2113946E02
CAP CER CHP 1.0UF 16V 10%
C720 2113946G01
CAP CER CHP 2.2UF 16V 10%
C721 2113946E02
CAP CER CHP 1.0UF 16V 10%
C722 2113946E02
CAP CER CHP 1.0UF 16V 10%
C723 2113946E02
CAP CER CHP 1.0UF 16V 10%
C724 2113946E02
CAP CER CHP 1.0UF 16V 10%
C725 2113945Y02
CAP,FXD,.1UF,+10%, -10%,
16V-DC,0402
C726 2113944F07
CAP,CHIP,1000PF,+5%, -5%,
50V-DC,0805
C727 2113944A31
CAP CER CHP 33.0PF 50V 5%
C728 2113944A32
CAP CER CHP 39.0PF 50V 5%
C729 2314030V06
CAP,FXD,68UF,+10%, -10%,
16V-DC,SM
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C730 2113944A31
CAP CER CHP 33.0PF 50V 5%
C731 2113946G01
CAP CER CHP 2.2UF 16V 10%
C732 2113944A31
CAP CER CHP 33.0PF 50V 5%
C734 2113945C31
CAP,FXD,.1UF,+10%, -10%,
50V-DC,0603
C735 2113946E02
CAP CER CHP 1.0UF 16V 10%
C736 2113946J03
CAP CER CHP 10.0UF 16V
10%
C737 2113945C31
CAP,FXD,.1UF,+10%, -10%,
50V-DC,0603
C738 2113945Y02
CAP,FXD,.1UF,+10%, -10%,
16V-DC,0402
C742 2113945A05
CAP CER CHP 470PF 50V 10%
C743 2113944A25
CAP CER CHP 10.0PF 50V
+/- 0.5PF
C750 2113946J03
CAP CER CHP 10.0UF 16V
10%
C751 2113946J03
CAP CER CHP 10.0UF 16V
10%
C752 2113944A31
CAP CER CHP 33.0PF 50V 5%
C753 2113944A31
CAP CER CHP 33.0PF 50V 5%
C754 2113946E02
CAP CER CHP 1.0UF 16V 10%
C755 2113946E02
CAP CER CHP 1.0UF 16V 10%
C756 2113944A31
CAP CER CHP 33.0PF 50V 5%
C757 2113944A31
CAP CER CHP 33.0PF 50V 5%
C758 2113946E02
CAP CER CHP 1.0UF 16V 10%
C759 2113946E02
CAP CER CHP 1.0UF 16V 10%
C760 2113944A31
CAP CER CHP 33.0PF 50V 5%
C761 2113944A31
CAP CER CHP 33.0PF 50V 5%
C762 2113945C31
CAP,FXD,.1UF,+10%, -10%,
50V-DC,0603
C763 2113944A31
CAP CER CHP 33.0PF 50V 5%
C764 2113946B03
CAP CER CHP 0.068UF 10V 10
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C765 2113946B03
CAP CER CHP 0.068UF 10V 10
C766 2113944A31
CAP CER CHP 33.0PF 50V 5%
C767 2113944A31
CAP CER CHP 33.0PF 50V 5%
C768 2113944A31
CAP CER CHP 33.0PF 50V 5%
C769 2113944A31
CAP CER CHP 33.0PF 50V 5%
C770 2113945C31
CAP,FXD,.1UF,+10%, -10%,
50V-DC,0603
C771 2113945C31
CAP,FXD,.1UF,+10%, -10%,
50V-DC,0603
C773 2113945Y02
CAP,FXD,.1UF,+10%, -10%,
16V-DC,0402
C790 2113946A02
CAP CER CHP 0.022UF 16V 10
C791 2113945Y02
CAP,FXD,.1UF,+10%,-10%,
16V-DC,0402
C792 2113945Y02
CAP,FXD,.1UF,+10%, -10%,
16V-DC,0402
C796 2113944A31
CAP CER CHP 33.0PF 50V 5%
C800 2113955D31
CAP,FXD,1UF,+10%, -10%,
16V-DC,1206
C801 2113944A32
CAP CER CHP 39.0PF 50V 5%
C802 2113945C20
CAP,FXD,.016UF,+10%,
-10%,50V-DC,0603
C803 2113944A32
CAP CER CHP 39.0PF 50V 5%
C804 2113946E02
CAP CER CHP 1.0UF 16V 10%
C805 2113945C20
CAP,FXD,.016UF,+10%, -10%,
50V-DC,0604
C806 2113945Y02
CAP,FXD,.1UF,+10%, -10%,
16V-DC,0402
C807 2113945Y02
CAP,FXD,.1UF,+10%, -10%,
16V-DC,0402
C808 2113945Y02
CAP,FXD,.1UF,+10%, -10%,
16V-DC,0402
C809 2113945C20
CAP,FXD,.016UF,+10%, -10%,
50V-DC,0605
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C810 2113946E02
CAP CER CHP 1.0UF 16V 10%
C811 2113945Y02
CAP,FXD,.1UF,+10%, -10%,
16V-DC,0402
C812 2113945Y02
CAP,FXD,.1UF,+10%, -10%,
16V-DC,0402
C813 2113945Y02
CAP,FXD,.1UF,+10%,-10%,
16V-DC,0402
C814 2113945Y02
CAP,FXD,.1UF,+10%,-10%,
16V-DC,0402
C815 2113945Y02
CAP,FXD,.1UF,+10%,-10%,
16V-DC,0402
C816 2113945Y02
CAP,FXD,.1UF,+10%,-10%,
16V-DC,0402
C817 2113945Y02
CAP,FXD,.1UF,+10%, -10%,
16V-DC,0402
C818 2113945Y02
CAP,FXD,.1UF,+10%, -10%,
16V-DC,0402
C830 2113945Y02
CAP,FXD,.1UF,+10%, -10%,
16V-DC,0402
C840 2113946F03
CAP CER CHP 4.7UF 6.3V 10%
C850 2113945A03
CAP CER CHP 330PF 50V 10%
C851 2113944A31
CAP CER CHP 33.0PF 50V 5%
C852 2113944A18
CAP CER CHP 5.1PF 50V
+/- 0.5PF
C853 2113944A32
CAP CER CHP 39.0PF 50V 5%
C855 NOT PLACED
–
C856 NOT PLACED
–
C857 NOT PLACED
–
C858 2113945B02
CAP CER CHP 10,000PF 25V
10%
C859 2113945B02
CAP CER CHP 10,000PF 25V
10%
C860 2113945B02
CAP CER CHP 10,000PF 25V
10%
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
