Motorola ATS 3000 User Manual

900MHz Schematics, Board Overlays, and Parts Lists 9.5-41
6816985H01-F February 14, 2012
C861 2113945B02
CAP CER CHP 10,000PF 25V
10%
C862 2113945B02
CAP CER CHP 10,000PF 25V
10%
C863 2113945B02
CAP CER CHP 10,000PF 25V
10%
C864 2113945B02
CAP CER CHP 10,000PF 25V
10%
C865 2113945B02
CAP CER CHP 10,000PF 25V
10%
C866 2113945B02
CAP CER CHP 10,000PF 25V
10%
C867 NOT PLACED
–
C868 NOT PLACED
–
CR101 4815897H01
PIN DIODE
CR102 4815897H01
PIN DIODE
CR800 4813978A25
SCHOTTKY 30V SOD-323 T&R
PB FREE
CR801 4813978A25
SCHOTTKY 30V SOD-323 T&R
PB FREE
D103 4813974A05
DIODE,SWG,MMBD301,SM,
SOT-23,30V,.2W,SHTK,
PB-FREE
D104 4816487H01
SWITCHING DIODE,
MINIBLOC
D105 4813974A05
DIODE,SWG,MMBD301,SM,
SOT-23,30V,.2W,SHTK,
PB-FREE
D201 4815011H01
DIODE TRIPLE
D202 4815011H01
DIODE TRIPLE
D211 4805656W87
DIODE,VCTR, @
15V,1SV279,SOD-523/SC-79
D212 4805656W87
DIODE,VCTR, @
15V,1SV279,SOD-523/SC-79
D401 4815096H01
VARACTOR DIODE 1SV305
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
D402 4885055Y01
DIODE VARACTOR
PB-FREE
D501 4809118D02
LED BICOLOR
LNJ115W8POMT
D510 NOT PLACED
–
D511 4813978M15
DIODE,RECT,RM140,SM,1A,
40V,SHTK,PB-FREE
D600 4813978B18
DIODE,SWG,BAT54,SM,
SOT-23,200MA,30V,.2W,
SHTK,PB-FREE
D603 4813978A25
SCHOTTKY 30V SOD-323 T&R
PB FREE
D662 4813978A25
SCHOTTKY 30V SOD-323 T&R
PB FREE
D700 4813978B18
DIODE,SWG,BAT54,SM,
SOT-23, 200MA,30V,.2W,
SHTK,PB-FREE
D800 4813974A19
DIODE ARRAY,MXR,SM,
SOT-323,7V,.2W,SHTK,2,
PB-FREE
E101 2415954H02
INDUCTOR BEAD CHIP EPP
WITH EPOXY
E102 2405688Z01
INDUCTOR FERRITE BEAD
E401 2480640Z01
SURFACE MOUNT FERRITE
BEAD
E402 2480640Z01
SURFACE MOUNT FERRITE
BEAD
E403 2480640Z01
SURFACE MOUNT FERRITE
BEAD
E404 2480640Z01
SURFACE MOUNT FERRITE
BEAD
E405 2480640Z01
SURFACE MOUNT FERRITE
BEAD
E406 2480640Z01
SURFACE MOUNT FERRITE
BEAD
E407 2480640Z01
SURFACE MOUNT FERRITE
BEAD
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
E408 2480640Z01
SURFACE MOUNT FERRITE
BEAD
E409 2480640Z01
SURFACE MOUNT FERRITE
BEAD
E500 2405688Z01
INDUCTOR FERRITE BEAD
E501 2405688Z01
INDUCTOR FERRITE BEAD
E800 2480574F01
IND FERRITE CHIP 60OHM
0603
E801 2480574F01
IND FERRITE CHIP 60OHM
0603
E802 0613952G67
CER CHIP RES 0.0 +/-0.050
OHM
F500 6515076H01
FUSE CHIP SMT TR/1608FF
3A
FL1 9116138H01
CERAMIC FILTER
FL2 9116138H01
CERAMIC FILTER
FL3 4885631B01
XTAL FILT 3 POLE 109.65
MOTORO
FL200 9116848H01
FLTR SW CAP 3 POLE
BUTTERW, W18
J101 2880658Z08
CONNECTOR SMA
J601 0916287H01
CONN VERT 45 PIN ZIF
J650 0916287H02
CONN 20 PIN ZIF
L1 2414017N23
IDCTR,CHIP,82NH,5%,300MA,
1.8OHM,0603
L2 2415429H38
CHIP INDUCTOR, 120nH
+/-5%
L4 2488090Y09
INDUCTOR,MULTILAYER,
4.7NH
L5 2414017P13
IDCTR,CHIP,10NH,5%,300MA
L6 2488090Y11
INDUCTOR,MULTILAYER,6.8N
H
L7 2414017N14
IDCTR,CHIP,15NH,5%
L10 2415429H32
CHIP INDUCTOR, 56nH
+/-5%
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
L11 2414017N22
IDCTR,CHIP,68NH,5%
L12 2414017K29
IND CER CHIP 330.0 NH 5%
L13 2414032F42
IDCTR,WW,470NH,10%,170M
A,2.5OHM,CER
L14 2414032F38
IDCTR,WW,220NH,5%
L15 2415429H43
CHIP INDUCTOR, 220nH
+/-5%
L101 2414032F36
IDCTR,WW,150NH,5%
L102 2414017G12
IDCTR,CHIP,27NH,5%,
300MA,.6OHM
L103 2460591C03
COIL AIR WOUND INDUC
11.87
L107 2414017G19
IDCTR,CHIP,100NH,5%,
300MA,2.5OHM
L108 2414017G19
IDCTR,CHIP,100NH,5%,
300MA,2.5OHM
L110 2414017G05
IDCTR,CHIP,6.8NH,5%,
300MA, 0603
L111 2414017N23
IDCTR,CHIP,82NH,5%
L114 2460591A11
COIL AIR WOUND INDUC 7.66
L115 2460591A11
COIL AIR WOUND INDUC 7.66
L117 2460591B22
COIL AIR WOUND INDUC 8.67
L200 2414017Q20
IDCTR,FXD,2.2UH,20%, 30MA,
.65OHM,FER
L201 2414017Q20
IDCTR,FXD,2.2UH,20%, 30MA,
.65OHM,FER
L203 2414017Q47
IDCTR,FXD,1UH,10%,50MA,
.45OHM,FERR
L204 2414032F21
IDCTR,WW,6.8NH,5%, 600MA,
.11OHM,CER
L205 2414017Q20
IDCTR,FXD,2.2UH,20%, 30MA,
.65OHM,FER
L206 2414017Q20
IDCTR,FXD,2.2UH,20%,
30MA,.65OHM,FER
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
