Motorola ATS 3000

9.5-42 900MHz Schematics, Board Overlays, and Parts Lists
February 14, 2012 6816985H01-F
L207 0613952G67
CER CHIP RES 0.0
+/-0.050 OHM
L210 2414032F36
IDCTR,WW,150NH,5%
L211 0613952G67
CER CHIP RES 0.0
+/-0.050 OHM
L212 2414032F36
IDCTR,WW,150NH,5%
L215 2414032F34
IDCTR,WW,100NH,5%, 400MA,
.46OHM,CER
L216 2414032F34
IDCTR,WW,100NH,5%, 400MA,
.46OHM,CER
L217 2414032F34
IDCTR,WW,100NH,5%, 400MA,
.46OHM,CER
L218 2414032F34
IDCTR,WW,100NH,5%, 400MA,
.46OHM,CER
L219 2414032F36
IDCTR,WW,150NH,5%
L220 2414032F27
IDCTR,WW,27NH,5%,
500MA,.25OHM,CER
L221 2414032F25
IDCTR,WW,18NH,5%,
600MA,.2OHM,CER
L230 2414032F25
IDCTR,WW,18NH,5%,
600MA,.2OHM,CER
L290 2414017Q47
IDCTR,FXD,1UH,10%,
50MA,.45OHM,FERR
L299 NOT PLACED
–
L401 2414032D17
IDCTR,WW,150NH,5%,
750MA,.31OHM,CER
L402 2466505A01
COIL INDUCTOR
L403 2466505A01
COIL INDUCTOR
L405 2414032B76
IDCTR,WW,4.7UH,5%,
330MA,4OHM
L406 2414032F73
IDCTR,WW,820NH,5%,
180MA,2.23OHM,CER
L407 2414032F73
IDCTR,WW,820NH,5%,
180MA,2.23OHM,CER
L500 2414017Q42
IDCTR,FXD,390NH,10%,
200MA,.65OHM,FE
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
L503 2489669V01
IDCTR,WW,100UH,5%
L511 2489669V01
IDCTR,WW,100UH,5%
L651 2414032F75
IDCTR,WW,270NH,2%, 350MA,
1OHM
L652 2414032F75
IDCTR,WW,270NH,2%, 350MA,
1OHM
L701 2486085A01
COIL, POWER INDUCTOR
L702 2486085A01
COIL, POWER INDUCTOR
L703 2464675H01
IDCTR,WW,560NH,5%, 550MA
L704 2464675H01
IDCTR,WW,560NH,5%, 550MA
L705 2464675H01
IDCTR,WW,560NH,5%, 550MA
L708 2416307H01
IDCTR,WW,680NH,5%,0603
L710 2416307H01
IDCTR,WW,680NH,5%,0603
M101 3916333H01
GROUND CONTACT
M701 0985888K02
SKT RTC BTTY LEAP
Q1 4802247J01
BJT, RF AMP, BFS505
Q101 4816698H01
MOD,XSTR,FET RF PWR,
7/800
Q212 4813972A15
N-Ch TMOS FET, '6Z', SOT23
T&R
Q213 4885061Y01
XSTR NPN 6V 30UA 12GHZ
PB-FREE
Q214 4813972A15
N-Ch TMOS FET, '6Z', SOT23
T&R
Q215 4885061Y01
XSTR NPN 6V 30UA 12GHZ
PB-FREE
Q216 4885061Y01
XSTR NPN 6V 30UA 12GHZ
PB-FREE
Q217 4813972A15
N-Ch TMOS FET, '6Z', SOT23
T&R
Q218 4813972A15
N-Ch TMOS FET, '6Z', SOT23
T&R
Q401 4805585Q27
TRANSISTOR RF NPN,
BFQ67W NOPB
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
Q501 4805921T28
XSTR, DUAL NOPB
Q698 4813973A81
XSTR,BIP GP SS,DIG,NPN
AND PNP,SOT-363,50V,
.25W,100MA,BIAS
Q700 4813970A62
XSTR,FET GP PWR, MOSFET,
P-CH,ENHN, CF,-20V, 1.3W,
PB-FREE
Q701 4813973M07
XSTR,BIP GP SS,NPN,T3904,
SM,SOT-23,SMT, 40V,.225W,
200MA,300MHZ
Q702 5185956E76
IC,CONV,SM,SO16,0-30
VINPUT RANGE,6.5A,3.8V, HI
SPD SWTH DR
Q703 4813970A62
XSTR,FET GP PWR, MOSFET,
P-CH,ENHN,CF, -20V,1.3W,
PB-FREE
Q704 NOT PLACED
–
Q705 NOT PLACED
–
Q706 NOT PLACED
–
Q709 4885061Y01
XSTR NPN 6V 30UA 12GHZ
PB-FREE
Q801 4813973A42
XSTR,BIP GP SS,NPN,SM,
SC-59,SMT,50V,.23W, 100MA,
PB-FREE
Q804 4813973A81
XSTR,BIP GP SS,DIG,NPN
AND PNP,SOT-363,50V,
.25W,100MA,BIAS
R1 0613952Q55
CER CHIP RES 180 OHM
5 0402
R2 0613952Q96
CER CHIP RES 9100 OHM
5 0402
R3 0613952Q83
CER CHIP RES 2700 OHM
5 0401
R4 0613952Q83
CER CHIP RES 2700 OHM
5 0402
R5 0613952Q54
CER CHIP RES 160 OHM
5 0402
R6 NOT PLACED
–
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R7 0613952Q39
CER CHIP RES 39.0 OHM
5 0402
R8 0613952G67
CER CHIP RES 0.0
+/-0.050 OHM
R10 0613952R66
CER CHIP RES 0.0 +/-0.050
OHM
R100 0613952H47
CER CHIP RES 82.0 OHM
5 0603
R101 0613952H47
CER CHIP RES 82.0 OHM
5 0603
R102 0613952H42
CER CHIP RES 51.0 OHM 5%
0603
R103 0613952H47
CER CHIP RES 82.0 OHM
5 0603
R104 0613952H42
CER CHIP RES 51.0 OHM 5%
0603
R105 0613952H68
CER CHIP RES 620 OHM
5 0603
R106 0613952H56
CER CHIP RES 200 OHM
5 0603
R107 0613952Q53
CER CHIP RES 150 OHM
5 0402
R108 0613952R04
CER CHIP RES 13K OHM
5 0402
R109 0613952R15
CER CHIP RES 39K OHM 5%
0402
R110 0613952Q73
CER CHIP RES 1000 OHM 5
0402
R111 NOT PLACED
–
R113 NOT PLACED
–
R114 0613952R66
CER CHIP RES 0.0 +/-0.050
OHM
R115 0613952R01
CER CHIP RES 10K OHM 5%
0402
R117 0613952R24
CER CHIP RES 91K OHM
5 0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
