Motorola ATS 3000

900MHz Schematics, Board Overlays, and Parts Lists 9.5-43
6816985H01-F February 14, 2012
R118 0613952R32
CER CHIP RES 200K OHM 5
0402
R119 0613952R01
CER CHIP RES 10K OHM 5%
0402
R199 0613952H71
CER CHIP RES 820 OHM
5 0603
R200 0613952Q49
CER CHIP RES 100 OHM
5 0402
R201 0613952Q53
CER CHIP RES 150 OHM
5 0402
R202 0613952Q53
CER CHIP RES 150 OHM
5 0402
R204 0613952R66
CER CHIP RES 0.0
+/-0.050 OHM
R205 0613952Q87
CER CHIP RES 3900 OHM 5
0402
R206 0613952Q48
CER CHIP RES 91.0 OHM
5 0402
R207 0613952Q56
CER CHIP RES 200 OHM
5 0402
R208 0613952Q73
CER CHIP RES 1000 OHM 5
0402
R210 0613952Q70
CER CHIP RES 750 OHM
5 0402
R211 0613952R66
CER CHIP RES 0.0
+/-0.050 OHM
R212 0613952Q61
CER CHIP RES 330 OHM
5 0402
R213 0613952R66
CER CHIP RES 0.0
+/-0.050 OHM
R214 0613952R03
CER CHIP RES 12K OHM 5%
0402
R215 0613952R08
CER CHIP RES 20K OHM
5 0402
R216 0613952R17
CER CHIP RES 47K OHM 5%
0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R217 0613952Q49
CER CHIP RES 100 OHM
5 0402
R220 0613952Q61
CER CHIP RES 330 OHM
5 0402
R222 0613952Q70
CER CHIP RES 750 OHM
5 0402
R225 0613952Q37
CER CHIP RES 33.0 OHM
5 0402
R227 0613952R18
CER CHIP RES 51K OHM
5 0402
R229 0613952R07
CER CHIP RES 18K OHM 5%
0402
R230 0613952R08
CER CHIP RES 20K OHM
5 0402
R231 0613952Q31
CER CHIP RES 18.0 OHM
5 0402
R232 0613952R18
CER CHIP RES 51K OHM
5 0402
R233 0613952Q57
CER CHIP RES 220 OHM
5 0402
R234 0613952R07
CER CHIP RES 18K OHM 5%
0402
R235 0613952R08
CER CHIP RES 20K OHM
5 0402
R236 0613952Q33
CER CHIP RES 22.0 OHM
5 0402
R237 0613952Q58
CER CHIP RES 240 OHM
5 0402
R238 0613952Q53
CER CHIP RES 150 OHM
5 0402
R239 0613952R10
CER CHIP RES 24K OHM
5 0402
R241 0613952R66
CER CHIP RES 0.0
+/-0.050 OHM
R243 0613952R12
CER CHIP RES 30K OHM
5 0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R244 0613952R18
CER CHIP RES 51K OHM
5 0402
R250 0613952R66
CER CHIP RES 0.0
+/-0.050 OHM
R251 0613952R66
CER CHIP RES 0.0
+/-0.050 OHM
R252 0613952R66
CER CHIP RES 0.0
+/-0.050 OHM
R261 0613952R18
CER CHIP RES 51K OHM
5 0402
R262 0613952Q91
CER CHIP RES 5600 OHM 5
0402
R285 0613952Q80
CER CHIP RES 2000 OHM 5
0402
R286 0613952Q45
CER CHIP RES 68.0 OHM
5 0402
R289 0613952Q47
CER CHIP RES 82.0 OHM 5%
0402
R290 0613952R13
CER CHIP RES 33K OHM 5%
0402
R291 0613952R14
CER CHIP RES 36K OHM
5 0402
R292 0613952Q37
CER CHIP RES 33.0 OHM
5 0402
R293 0613952Q95
CER CHIP RES 8200 OHM 5
0402
R294 0613952R66
CER CHIP RES 0.0
+/-0.050 OHM
R295 0613952R17
CER CHIP RES 47K OHM 5%
0402
R297 0613952R66
CER CHIP RES 0.0
+/-0.050 OHM
R298 NOT PLACED
–
R401 0613952Q49
CER CHIP RES 100 OHM
5 0402
R402 0613952R10
CER CHIP RES 24K OHM
5 0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R403 0613952Q94
CER CHIP RES 7500 OHM
5 0402
R404 0613952C81
CER CHIP RES 681 OHM 1%
0603
R405 0613952Q80
CER CHIP RES 2000 OHM 5
0402
R406 0613952Q61
CER CHIP RES 330 OHM
5 0402
R407 0613952R10
CER CHIP RES 24K OHM
5 0402
R408 0613952Q41
CER CHIP RES 47.0 OHM
5 0402
R409 0613952R25
CER CHIP RES 100K OHM 5%
0402
R410 0613952R01
CER CHIP RES 10K OHM 5%
0402
R411 0613952Q63
CER CHIP RES 390 OHM
5 0402
R412 0613952R01
CER CHIP RES 10K OHM 5%
0402
R413 0613952R66
CER CHIP RES 0.0 +/-0.050
OHM
R414 0613952R25
CER CHIP RES 100K OHM 5%
0402
R415 0613952R66
CER CHIP RES 0.0 +/-0.050
OHM
R416 NOT PLACED
–
R503 0613952Q63
CER CHIP RES 390 OHM
5 0402
R504 0613952Q66
CER CHIP RES 510 OHM
5 0402
R505 0613952Q93
CER CHIP RES 6800 OHM 5
0402
R507 0613952Q49
CER CHIP RES 100 OHM
5 0402
R508 0613952Q49
CER CHIP RES 100 OHM
5 0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
