KVL4000KeyVariableLoaderASTRO25UserGuide
•SecureASTRO
®
25MultipleKeyTargetRadio
•AnotherKVLunit(see1.4.4.2ConnectingTwoKVLUnits,page1-16)
•RadioNetworkController(RNC)
•DigitalInterfaceUnit(DIU)
•MotorolaGoldEliteGateway(MGEG)
•MCC7500DispatchConsole
•PDEGEncryptionUnit
•CAIDataEncryptionModule(CDEM)
•KeyManagementFacility(KMF)(see1.4.4.3ConnectingtheKVLtotheKMF,page1-16)
•KMFCryptR
•CRYPTRmicro(usedwithMCC7100IPDispatchConsoleandAME1500/2000)(see1.4.4.4Connecting
theKVLtotheCRYPTRmicro,page1-21)
ProcedureSteps
1Forinformationonwhatcables/adaptorstousewithparticulartargetdevices,seeTableB-5InterfaceCablesin
BKVL4000–OrderableParts,pageB-1.
2ConnecttheKVLandtheTargetDeviceusinganappropriatekeyloadcableandanadaptor(ifrequired).
Figure1-8KVLandRadios–Connected(Example)
1-14
6871018P37-F-January2013
