KVL4000KeyVariableLoaderASTRO25UserGuide
ProcedureSteps
1ConnectoneendoftheACLineCordtothepowersource.
2ConnecttheotherendoftheACLineCordtothepowersupply.
3ConnectthepowersupplytotheKVLthroughtheChargingPortontheSecurityAdapter.
Stepresult:TheKVLstartscharging.ThemiddleLEDonthePDAisblinkingtoindicatetheKVLisbeing
charged.Oncethedeviceisfullycharged,theLEDbecomessolid.
Figure1-17KVL4000-Charging
1-22
6871018P37-F-January2013
