Motorola KVL 4000 - Connecting the KVL to the KMF; Connecting the KVL to the KMF - Direct Connection; Connecting Two KVL Units; Figure 1-11 Two KVL Units - Connected

KVL4000KeyVariableLoaderASTRO25UserGuide
1.4.4.2ConnectingTwoKVLUnits
Prerequisites:
EnsureyouhavetheKVLtoKVLcable.
ProcedureSteps
1TaketheKVLtoKVLcable(TKN8209).
2ConnecttwoKVLsthroughtheirkeyloadports.
Figure1-11TwoKVLUnits–Connected
TheKVL4000isalsocompatiblewiththepreviousmodelsoftheKVL.
1.4.4.3ConnectingtheKVLtotheKMF
1.4.4.3.1ConnectingtheKVLtotheKMF–DirectConnection
Prerequisites:
EnsureyouhaveaNullModemCable.
Whenandwheretouse:
UsethesestepstodirectlyconnecttheKVLtotheKMF.
