Motorola R-2001D User Manual

SIGNALING SEQUENCE MODE SEL) 3
0) MENU 1) START 2) END
SEQ SEL) I
2) MODIFIED ZVEI
4) CCIR (lOOMS)
SELECT V DECODE
1) ZVEI
3) CCIR (70MS)
5) EEA
CODE:
2
2 5 3
• GENERAL ENCODE
Figure 3-29 shows the general encode display on page 6.
Select
one of the ten possible sequences. Enter the pro-
grammable tone frequency from 0 to 20,000 Hz and the
time duration from 0 to 10,000 milliseconds. Press a
code synthesizer key to select Tone Sequence Mode.
Place the MODULATION switch in burst or continu-
ous position to initiate the sequence. Each of the ten-
tone frequencies will be generated in sequence for its
duration before the generator proceeds to the next tone.
FREQ:
HZ
TIME:
SEC
1080
.070
1160
.070
2600
.070
1530
.070
1270
.070
SIGNALING SEQUENCE MODE SEL) 6
0) MENU I) START 2) END
GENERAL SEQ DECODE
• MOBILE TELEPHONE SIGNALING
The Analyzer simulates base to mobile and mobile to
base sequences. It generates the appropriate signaling
sequence, verifies
mobile radiotelephone response, de-
codes
and displays tone frequencies and telephone num-
bers. An error message during a sequence indicates
radio failure. To reset the mobile telephone decoder and
initiate a new sequence, press" I" for "START" again.
FIGURE 3-30. GENERAL DECODE DISPLAY
• GENERAL DECODE
Figure 3-30 shows a display for the general ten-tone se-
quence decode table on page 6. Frequencies and time
durations are derived from the input signal. Frequency
is displayed up to a maximum value of 9999 Hz (I Hz
resolution). No display in a FREQ field with a time
duration in the TIME field indicates that a space oc-
curred between the preceding tone burst and the follow-
ing
tone burst. Time is displayed up to a maximum
value of 9999 milliseconds (I ms resolution).
TIME
MSEC
FIGURE 3-28. SELECT V DECODE DISPLAY
• SELECT V DECODE
Figure 3-28 shows a decode display on page 3. Select one
of the five sequences to display the decoded access code
for Select V. If an invalid frequency is detected within
the sequence, a dash replaces that digit. The display
shows
decoded tone frequencies for each code digit, to a
maximum 10,000 Hz with 1 Hz resolution. The display
shows the time duration that the tone for each digit was
present, to a 1 second maximum with I millisecond
resolution.
SIGNALING SEQUENCE MODE SEL) 6
ENTER 0 FOR MENU
GENERAL SEQ ENCODE
FREQ
TIME FREQ
TIME
HZ MSEC HZ
MSEC
I) 10531.0 0030 2) 02000.0
0030
3) 03561.0
0030
4) 01876.0 0030
5) 11532.0
0030
6) 08471.0
0030
7) 00000.0
0000
8) 00000.0
0000
9) 00000.0 0000 to) 00000.0
0000
SCOPE TRIG DL Y) 0.000 SEC
FIGURE 3-29. GENERAL ENCODE DISPLAY
3-15
FREQ
HZ
1)----
3) - - - -
5) - - - -
7) - - - -
9) - - - -
FREQ
HZ
2) - - - -
4) - - - -
6) - - - -
8) - - - -
to) - - - -
- NO INPUT SIGNAL -
TIME
MSEC
