Network Setup
4-60
• Undecr Pkts
• RXPkts per sec
• RX Tput (Mbps)
• Avg Retries
• Avg SNR (dB)
• # Radios
3. Select any of the above listed parameters by clicking on the checkbox associated with it.
4. Click the Close button to exit the screen.
4.5.2.3 Viewing WLAN Switch Statistics
The Switch Statistics screen is recommended for displaying individual WLAN packet data rate and retry
information. The Switch Statistics screen is optimal for determining whether data traffic within each WLAN
meets its intended throughput speed based on the WLAN’s MU traffic requirements. Use this information to
discern if WLAN’s require modification to meet network throughput expectations.
To view detailed statistics for a WLAN:
1. Select a Network > Wireless LANs from the main menu tree.
2. Click the Statistics tab.
NOTE You cannot select (and trend) more than four parameters at any given time.
