Switch Security
6-31
6.5.4.1 Adding or Editing a New ACL WLAN Configuration
After creating an ACL, it can be applied to one or more WLANs on the switch. To attach an ACL to a WLAN:
1. Select Security > ACLs from the main menu tree.
2. Click on the Attach-WLAN tab.
3. Click the Add button.
4. Define a WLAN Index between 1 and 256. If editing the ACL configuration, the index is read only
and cannot be modified.
5. Use the IP ACL drop-down menu to select an IP ACL to configure for the WLAN interface.
6. Use the MAC ACL drop-down menu to select the MAC ACL to configure for the WLAN interface.
7. Select either the Inbound or Outbound radio button to define which direction the ACL applies.
8. Refer to the Status field for the current state of the requests made from applet. This field displays
error messages if something goes wrong in the transaction between the applet and the switch.
9. Click OK to use the changes to the running configuration and close the dialog.
10. Click Cancel to close the dialog without committing updates to the running configuration.
6.5.5 Reviewing ACL Statistics
Use the Statistics tab to view set of statistics for those ACLs defined for use with the switch. The Statistics
tab only displays data for router ACLs.
To review ACL statistics:
1. Select Security > ACLs from the main menu tree.
NOTE ACL statistics are only displayed for router ACLs.
