NPort P5150A
Connecting the Hardware
This section describes how to connect the NPort 5100A to serial devices for first time testing purposes.
Connecting the Power
NPort P5150A
Connect the NPort P5150A’s Ethernet port to a PoE switch. The P5150A will receive power from the switch.
NPort 5150A/5130A/5150A
Connect the 12 to 48 VDC power cord to the NPort 5100A’s power input. If the power is properly supplied, the
“Ready” LED will glow a solid red color until the system is ready, at which time the “Ready” LED will change to
a green color.
