NPort 5100A Series Web Console Configuration
5-23
UDP Mode
Packing length
Setting Factory Default Necessity
0 to 1024 0 Optional
Default = 0: The Delimiter Process will be followed, regardless of the length of the data packet. If the data
length (in bytes) matches the configured value, the data will be forced out. The data length can be configured
for 0 to 1024 bytes. Set to 0 if you do not need to limit the length.
Delimiter 1
Setting Factory Default Necessity
00 to FF None Optional
Delimiter 2
Setting Factory Default Necessity
00 to FF None Optional
Once the NPort 5100A receives both delimiters through its serial port, it immediately packs all data currently
in its buffer and sends it out the NPort 5100A’s Ethernet port.
ATTENTION
Delimiter 2 is
optional. If left blank, then Delimiter 1 alone trips clearing of the buffer.
If the size of the serial
data received is greater than 1 KB, the NPort 5100A
will automatically pack the data and send it to the
Ethernet.
However, to use the delimiter function, you must at least enable Delimiter 1. If Delimiter 1 is left
blank and Delimiter 2 is enabled, the delimiter function will not work properly.
Delimiter process
Setting Factory Default Necessity
Do Nothing,
Delimiter + 1,
Delimiter + 2,
Strip Delimiter
Do Nothing Optional
[Delimiter + 1] or [Delimiter + 2]: The data will be transmitted when an additional byte (for Delimiter +1), or
an additional 2 bytes (for Delimiter +2) of data is received after receiving the Delimiter.
