NPort 5100A Series Web Console Configuration
5-25
UDP Multicast
A multicast is a packet sent by one host to multiple hosts. In multicast, each host that belongs to a specific
multicast group will receive multicast packets for that group. To configure a host as a multicast receiver over
the Internet, it must inform the routers on its LAN. The Internet Group Management Protocol (IGMP) is used to
communicate group membership information between hosts and routers on a LAN. The NPort 5100A supports
IGMP version 2.
You could type the IP address (e.g., 239.1.1.1) of the assigned multicast group into the Destination IP address
column, after which the NPort will automatically add the Group and start receiving all packets from the group
in accordance with the multicast function.
Pair Connection Mode
Pair Connection Master Mode
When you select Pair Connection Master Mode for the Operation mode of one of the NPort 5100A device
servers this NPort 5100A will be acting as a TCP client.
TCP alive check time
Setting Factory Default Necessity
0 to 99 min 7 min Required
0 min: TCP connection is not closed due to an idle TCP connection.
1 to 99 min: The NPort 5100A closes the TCP connection automatically if there is no TCP activity for the given
time.
Destination IP address
Setting Factory Default Necessity
IP address or Domain
Name
(E.g., 192.168.1.1)
blank Optional
TCP port No. 4001 Required
The Pair Connection “Master” will contact the network host that has this IP address. Data will be transmitted
through the port No. (4001 by default). Note that you must configure the same TCP port No. for the device
server acting as the Pair Connection “Slave.”
