NPort 5100A Series Introduction
Overview
NPort 5100A series device servers, which include the NPort 5110A, 5130A, 5150A, and P5150A, are designed
to make your industrial serial devices Internet ready instantly. The compact size of NPort 5100A device servers
makes them the ideal choice for connecting your RS-232/422/485 serial devices, such as card readers and
payment terminals, to an IP-based Ethernet LAN, making it possible for your software to access serial devices
located anywhere on a local LAN, or the Internet.
The NPort 5100A supports several operation modes, including TCP Server, TCP Client, UDP Server/Client, Pair
Connection, and Ethernet Modem, ensuring the compatibility of network software that uses a standard network
API (Winsock, BSD Sockets). In addition, NPort’s Real COM / TTY drivers allow you to set up your COM/TTY port
software to work over a TCP/IP network in no time. This excellent feature preserves your software investment
and lets you enjoy the benefits of networking your serial devices instantly.
NPort 5100A device servers support automatic IP configuration protocols (DHCP, BOOTP) and manual
configuration via the handy web browser console. Both methods ensure quick and effective installation. And
with NPort 5100A’s Windows Utility, installation is very straightforward, since all system parameters can be
stored and then copied to other device servers simultaneously.
Package Checklist
The NPort 5100A Series products are shipped with the following items:
Standard Accessories
• 1 NPort 5100A serial device server
• Quick Installation Guide
• 4 stick-on pads
• Document & Software CD
• Product Warranty Statement
Optional Accessories
• DK-35A DIN-Rail Mounting Kit (35 mm)
• PWR-12150-USJP-SA-T: 100 to 240 VAC input, 12 VDC/1.5A output, -40 to 75°C, screw type, US/JP Plug
• PWR-12150-EU-SA-T: 100 to 240 VAC input, 12 VDC/1.5A output, -40 to 75°C, screw type, EU Plug
• PWR-12150-UK-SA-T: 100 to 240 VAC input, 12 VDC/1.5A output, -40 to 75°C, screw type, UK Plug
• PWR-12150-CN-SA-T: 100 to 240 VAC input, 12 VDC/1.5A output, -40 to 75°C, screw type, CN Plug
• PWR-12150-AU-SA-T: 100 to 240 VAC input, 12 VDC/1.5A output, -40 to 75°C, screw type, AU Plug
NOTE: Notify your sales representative if any of the above items are missing or damaged.
Product Features
The NPort 5100A have the following features:
Low cost, credit card size
Makes your serial devices Internet ready
Easy wall and DIN-Rail mounting
Real COM / TTY driver for Windows and Linux
Fixed TTY driver for SCO OpenServer, SCO
Unixware 7, SCO Unixware 2.1
Versatile socket operation modes: TCP Server,
TCP Client, UDP, and Ethernet Modem
Pair Connection mode for connecting two serial
devices over a network without a PC
Easy-to-use Windows Utility for mass installation
Auto-detecting 10/100 Mbps Ethernet
Built-in 15 KV ESD protection for all serial signals
Supports SNMP MIB-II for network management
Configuration via web/Telnet/serial console
Configuration utility automatically finds NPort
devices on the network
Supports RFC 2217 and Reverse Telnet modes
IEEE 802.3af compliant PoE (P5150A only)
